Acu Box (Including Components Kit) - Intellian v100NX Installation & Operation User Manual

Planning Installation

ACU Box (Including Components Kit)

Before beginning installation, make sure you have all the included components.
Description
Antenna Control Unit (ACU)
Quick Installation Guide (QIG)
RF Hazard Sticker
Mounting Template
ACU Rack Mount Bracket
Flat Head Screw
USB Cable (A-A)
AC Power Cord (CEEE7/7)
RG-6 RF Cable
Modem Interface Cable
(For iDirect Modem)
Ethernet Cable (RJ45/LAN)
Wi-Fi Dongle
Hex Bolt (BUMAX)
Flat Washer
Spring Washer
Hex Head Wrench Bolt
Spring Washer and Flat Washer
Sems Bolt
Radome Door Key
Waterproof Foam
Q'ty Size
431 mm x 350 mm x
1
44.3 mm
1
1
1
2
10 M4 x 12 L
1 1.8 m
1 1.5 m
2 1 m
1 1.5 m
2 1 m
1
5 M12 x 80 L
5 M12
5 M12
5 M6 x 40 L
5 M6
2 M4 x 8 L
2
1
16
Planning Installation
Remarks
Antenna Control Unit (ACU)
Radiation Safety Distance (15 m) Label
To fix ACU to 19inch Rack Frame
Bolt Kit for Rack Type Mount Bracket
ACU (Front Panel) to PC
ACU Power (220 V)
ACU to Modem
ACU to Modem (iDirect Modem)
ACU to PC/Intellian M&C
Bolt Kit for Antenna - Deck (Mast)
Assembly (1 spare set included)
Spare Bolt Kit for Radome Assembly
Two Door Keys
X-shape Cable Hole Type
