015
WELLS MANUFACTURING
265 Hobson Street, Smithville, Tennessee 37166
telephone: 314-678-6314
fax: 314-781-2714
www.wells-mfg.com
OPERATION MANUAL
WELLS
BUILT-IN
HW-Series
COOK 'N HOLD
Model HW-106D
WARMERS
with
THERMOSTAT
CONTROL
Models
HW-106D
HW/SMP-6D
Includes
INSTALLATION
Model HW/SMP-6D
USE & CARE
IMPORTANT: DO NOT DISCARD THIS MANUAL
This manual is considered to be part of the appliance and is to be given to the OWNER or
MANAGER of the restaurant, or to the person responsible for TRAINING OPERATORS of
this appliance. Additional manuals are available from your WELLS DEALER.
THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR
INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any
questions concerning installation, operation or maintenance of this equipment.
03/18
Rev .E
303740
2M-
Advertisement
Table of Contents
Related Manuals for Wells HW Series
Summary of Contents for Wells HW Series
- Page 1 Additional manuals are available from your WELLS DEALER. THIS MANUAL MUST BE READ AND UNDERSTOOD BY ALL PERSONS USING OR INSTALLING THIS APPLIANCE. Contact your WELLS DEALER if you have any questions concerning installation, operation or maintenance of this equipment.
- Page 2 Wells’ discretion have the parts replaced or codes, including incorrect gas or electrical connection. Wells is not liable repaired by Wells or a Wells-authorized service agency.
-
Page 3: Table Of Contents
PARTS & SERVICE CUSTOMER SERVICE DATA INTRODUCTION Thank You for purchasing this Wells Manufacturing Co. appliance. Proper installation, professional operation and consistent maintenance of this appliance will ensure that it gives you the very best performance and a long, economical service life. -
Page 4: Features & Operating Controls
TEMPERATURE CONTROL KNOB. The knob has a numeric scale, where higher numbers correspond to higher temperature. WELLS 3. On warmers equipped with an INDICATOR LIGHT, the light will glow when the thermostat is calling for heat (i.e. the element is energized). -
Page 5: Precautions & General Information
Damage to the Do not operate this appliance if the control panel is damaged. Call appliance will result if these your Authorized Wells Service Agent for service. instructions are not followed. The technical content of this manual, including any wiring diagrams,... -
Page 6: Installation
INSTALLATION NOTE: DO NOT discard UNPACKING & INSPECTION the carton or other packing Carefully remove the appliance from the carton. Remove all materials until you have protective plastic film, packing materials and accessories from the inspected the appliance for Appliance before connecting electrical power or otherwise performing hidden damage and tested it any installation procedure. - Page 7 INSTALLATION (continued) For Cook ‘N Hold warmers: a. Verify that provided sealants are applied to the underside of the warmer top flange prior to setting the unit into the cutout. b. After installation, verify that the tabs on the Wellsloks are turned out to lock the warmer into the counter c.
-
Page 8: Operation
OPERATION WET OPERATION ONLY CAUTION: Hot Surface 1. Carefully read the description of the warmer operation on the specification sheet. Exposed surfaces can be hot 2. The warmer is to be used for WET operation ONLY. Add to the touch and may cause approximately 1”... -
Page 9: Cleaning Instructions
Contact your Authorized Wells Service Agency to inspect warmer if water or grease contamination is suspected. Close drain valve. Add proper amount of warm water. Turn control... - Page 10 Weekly, or whenever lime or scale is seen water for 15 minutes and accumulating on the sides of the warmer pans. consult a physician TOOLS: Wells Delime Cleaner (1 package per pan) SKIN: Wash with soap and Plastic Scouring Pad water Clean Cloth or Sponge INHALATION: Relocate to 1.
-
Page 11: Troubleshooting Suggestions
Internal damage Contact your Authorized Wells Service Agency for repairs Warmer slow to heat Mineral deposits on pan acting as Clean pan(s) with Wells Delime a insulator Cleaner Wired to wrong voltage Verify supply voltage - must match voltage on warmer... -
Page 12: Maintenance Instructions
Never use metal implements, wire brushes, abrasive scratch pads or steel wool to clean stainless steel. Warmer pans, insets and other vessels are subject to a harsher environment. Wells Manufacturing uses an very high quality stainless steel (#304DDQ) for our food warmer pans. - Page 13 NOTES...
-
Page 14: Parts List 12
PARTS LIST: HW-106D 5P-21709 2N-35693UL, 120V 2N-35967UL, 240V WS-55992 D8-30291 Part of WS55984 2B-37946 WS-8706-109 Fitting Only 2I-Z12311 D8-35994 2I-Z12311 D8-37256 DD-35996 2C-35736 2J-35966 (Green) 2K-31040 2E-33068 2R-35972 WS-55984 2J-35687 (Red) IL2027, Rev. a HW-106D COMPONENTS... - Page 15 D8-30291 2N-40457UL 208/240V 5P-21709 2B-37946 D8-44802 D8-40516 make from 2H-36196 (sold by the sq foot) make from 2H-36050 (sold by the sq foot) 2K-33996X (CONDUIT FITTING ONLY) 2I-Z12311 P2-40629 2C-35736 2J-35687 2K-31040 2R-35972 WELLS WELLS 2T-40509 I7-Z12221 IL2273-PL015, Rev. A...
- Page 16 NOTES...
- Page 17 NOTES...
-
Page 18: Parts & Service
PARTS & SERVICE DESCRIPTION PART NO. Always use an inset. DO NOT place food directly INSETS into the warmer pan. 4 QT. ROUND INSET w/ lid 5D-20774 7 QT. ROUND INSET w/ lid 5D-20587 11 QT. ROUND INSET w/ lid 5D-20908 11 QT. -
Page 19: Customer Service Data
WELLSLOK EXTENSION KIT, for UL LISTED authorized replacement 12” x 20” warmers only, adapt to wood counter parts, contact your Wells up to 1¾” thick 5P-22593* authorized service agency, Wellslok Extension Kits for UL Listed units approved for... - Page 20 Wells Manufacturing 265 Hobson Street Smithville, Tennessee 37166 telephone: 800-264-7827 fax: 314-781-2714 www.wells-mfg.com...
