  • Page 1 High Resolution Camera User Manual HCD-7010RA/7020RA/7030RA HCV-7010RA/7020RA/7030RA HCO-7010RA/7020RA/7030RA...
  • Page 2 High Resolution Camera User Manual Copyright ©2017 Hanwha Techwin Co., Ltd. All rights reserved. Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
  • Page 3 Before operating the camera, confirm the camera model and correct input power voltage. To help you understand this manual thoroughly, we'll introduce our model description. ■ HCD-70X0RA/HCV-70X0RA/HCO-70X0RA SERIES • NTSC MODEL • PAL MODEL HCD-70X0RAN HCD-70X0RAP HCV-70X0RAN HCV-70X0RAP HCO-70X0RAN HCO-70X0RAP ■...
  • Page 4 safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
  • Page 5 6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers filled with water on top of the camera. doing so may cause personal injury due to fire, electric shock, or falling objects. 7. Do not install the unit in humid, dusty, or sooty locations. doing so may cause fire or electric shock.
  • Page 6 safety information FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : 1) This device may not cause harmful interference, and 2) This device must accept any interference received including interference that may cause undesired operation.
  • Page 7 important safety instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers) that produce heat.
  • Page 8 important safety instructions 17. Do not install the product in a place where chemical substances or oil mist exists or may be generated. As edible oils such as soybean oil may damage or warp the product, do not install the product in the kitchen or near the kitchen table. This may cause damage to the product.

  • Page 9: Table Of Contents

    Component names and functions INSTALLATION Before installation Installation Adjusting the monitoring direction for the camera CONNECTION Connecting to Monitor Connecting to Power Using Coaxial Communications CAMERA OPERATION Menu Configuration Menu Setup TROUBLESHOOTING Troubleshooting SPECIFICATIONS Specifications (HCD-7010RA/7020RA/7030RA) Specifications (HCV-7010RA/7020RA/7030RA) Specifications (HCO-7010RA/7020RA/7030RA) Dimension English_9...

  • Page 10: Introduction

    FEATURES y High Resolution Use of a 4.1 mega pixel CMOS device provides clear pictures with a resolution of 2560x1440. y Excellent Sensitivity - HCD-7010RA/HCV-7010RA/HCO-7010RA Color : 0.26Lux (F1.8, 1/30sec) B/W : 0Lux(IR LED on) - HCD-7020RA/HCV-7020RA/HCO-7020RA HCD-7030RA/HCV-7030RA/HCO-7030RA Color : 0.27Lux (F2.0, 1/30sec)
  • Page 11 COMPONENTS AND ACCESSORIES Check if the following items are included in the product package. <HCD-7010RA/7020RA/7030RA> Camera Quick Manual Screws Template Video Output Cable English_11...
  • Page 12 introduction <HCV-7010RA/7020RA/7030RA> Camera Quick Manual Template Tapping Screw Machine Screws L Wrench Card-type moisture Video Output Cable absorbent 12_ introduction...
  • Page 13 <HCO-7010RA/7020RA/7030RA> Camera Quick Manual Screws Card-type moisture Template Wrench absorbent Video Output Cable English_13...
  • Page 14 Dome Cover Shield Case Rotate base : control rotating angle of camera. Vari-focal Lens Module : HCD-7010RA : 2.8mm(F1.8) HCD-7020RA : 4.0mm(F2.0) HCD-7030RA : 6.0mm(F2.0) Function Setup switch : Display the menu on the screen and move the cursor to four directions to confirm status or after changing a selected item.
  • Page 15 HCV-7010RA/7020RA/7030RA ❿ Dome Cover Rotate base : control rotating angle of camera. Vari-focal Lens Module : HCV-7010RA : 2.8mm(F1.8) HCV-7020RA : 4.0mm(F2.0) HCV-7030RA : 6.0mm(F2.0) Function Setup switch : Display the menu on the screen and move the cursor to four directions to confirm status or after changing a selected item.
  • Page 16 introduction HCO-7010RA/7020RA/7030RA Camera Sunshield Knob Sunshield : Fixing the sunshield onto the camera. Front cover Function Setup Switch : Display the menu on the screen and move the cursor to four directions to confirm status or after changing a selected item. ...

  • Page 17: Installation 17

    Before installing your camera, you have to adjust the lens focus, zoom, and switch settings. y When installing your camera, don’t allow any person to approach the installation site. INSTALLATION Disassembling(HCD-7010RA/7020RA/7030RA) 1. Use one hand to hold the camera’s bottom part and turn the cover counterclockwise with another hand to separate it.
  • Page 18 Installation Disassembling(HCV-7010RA/-7020RA/-7030RA) Using the L-wrench provided, loosen 3 screws by turning them counterclockwise and separate the dome cover. L Wrench Dome Cover 18_ Installation...
  • Page 19 Installation(HCD-7010RA/7020RA/7030RA) 1. Attach the installation template to the selected area and punch 2 holes as shown in the fi gure. 케이블 구멍 2. Use the 2 supplied screws to fix the camera to the 2 punched holes. y Set the <TOP FRONT> mark imprinted on the camera to face the direction of camera monitoring.
  • Page 20 Installation Installing the camera on a ceiling or wall(HCV-7010RA/-7020RA/-7030RA) 1. Drill holes on the ceiling by matching to the holes on the case bed, and insert plastic anchors (HUD 5) (not included) fully into the holes. Fix the case bed on the ceiling by using screws .
  • Page 21 3. Adjust the lens in a desired direction by referring to the “Adjusting the monitoring direction for the camera”section. 4. Close the dome cover. To ensure waterproofing, tight up the fixing bolts using the L-wrench. Dome Cover L Wrench The installation should be done by qualified service personnel or system installers. If the ceiling material is not strong enough to hold the installation screws, the camera may fall off.
  • Page 22 Installation ADJUSTING THE MONITORING DIRECTION FOR THE CAMERA <HCD-7010RA/7020RA/7030RA> Tilt Lens rotation <HCV-7010RA/7020RA/7030RA> Tilt Lens rotation 22_ Installation...
  • Page 23 ` Adjusting the monitoring direction You can adjust the camera direction only when the camera is fixed on the ceiling. Where, rotating the camera unit to the left or right is called Pan, adjusting the tilt is called Tilt, and turning the lens on its axis is called Rotation. - The effective range of pan is a total of 350 degrees.

  • Page 24: Connection

    CONNECTING TO MONITOR Connect the Video OUT port on the rear panel of the camera to a AHD DVR. ALARM NETWORK BACKUP POWER AHD DVR HCD-7010RA/7020RA/7030RA Monitor ALARM NETWORK BACKUP POWER AHD DVR HCV-7010RA/7020RA/7030RA Monitor 24_ connection...
  • Page 25 This product supports 4 video output formats of AHD, CVBS. The default is AHD. Select the video output appropriate for your DVR. CONNECTING TO POWER You can connect power as shown in the following figure. Power Input Terminal ALARM NETWORK BACKUP POWER HCD-7010RA/7020RA/7030RA English_25...
  • Page 26 connection Power Input Terminal ALARM NETWORK BACKUP POWER HCV-7010RA/7020RA/7030RA HCO-7010RA/7020RA/7030RA Power Input Terminal When the resistance value of copper wire is at [20°C(68°F)] Copper wire size (AWG) #24 (0.22mm #22 (0.33mm #20 (0.52mm #18 (0.83mm Resistance value(Ω/m) 0.078 0.050 0.030 0.018 Voltage Drop (V/m) 0.028...
  • Page 27 USING COAXIAL COMMUNICATIONS y Coaxial Communications System y OSD Control method CAMERA MENU/ENTER UP KEY DOWN DOWN KEY LEFT LEFT KEY RIGHT RIGHT KEY : BNC ● HCD-7010RA/7020RA/7030RA HCV-7010RA/7020RA/7030RA HCO-7010RA/7020RA/7030RA English_27...
  • Page 28 connection - Video Cable The camera's video output port is connected to the DVR with a BNC coaxial cable, shown below. Recommended Cable Distance Specification 500m 5C2V It is recommended that pure copper coax cable is used and not copper coated steel, as this will cause issues with the communication over the coaxial cable.

  • Page 29: Camera Operation

    camera operation MENU CONFIGURATION MAIN SETUP VIDEO FORMAT ◦ ◦ CVBS ◦ ◦ D-WDR ◦ ◦ ◦ INDOOR OUTDOOR WHITE BAL ◦ ◦ AWC → SET MANUAL ◦ ◦ ◦ BRIGHTNESS SHUTTER EXPOSURE ◦ ◦ RETURN BACKLIGHT ◦ ◦ ◦ USER BLC ◦...
  • Page 30 camera operation MAIN SETUP  1. VIDEO FORMAT Select the Change the status function using 2. D-WDR using the Function the Function Setup switch. 3. WHITE BAL Setup switch. 4. EXPOSURE 5. BACKLIGHT 6. SPECIAL 7. EXIT SAVE 1. Press the Function Setup switch. y Main SETUP menu is displayed on the monitor screen.
  • Page 31 D-WDR If an object has a large variance between bright and dark areas, it will keep bright areas bright and make selected dark areas bright, so that the overall brightness can be maintained. 1. When the SETUP menu screen is MAIN SETUP displayed, select ‘D-WDR’...
  • Page 32 camera operation y INDOOR : Select this when the color temperature is between 4,500K and 8,500K. Automatically adjusts the camera color for optimization to the indoor environment. y MANUAL : Select this to fine-tune White WB MANUAL Balance manually. Set White ...
  • Page 33 The greater the shutter value the brighter the screen is but the more the residual images of objects there are. If the min shutter value is large, it can cause noise, spots and white areas but still operate normally. If you do not use the AGC mode on the exposure menu, it cannot be set above 1/60sec.
  • Page 34 camera operation y HLC (High Light Compensation) : This function masks the strong light to minimize HLC SETUP white out due to over exposure and preserve much ▶ LEVEL M I D D L E of the on-screen details when the camera aims a LIMIT NIGHT ONLY strong light source.
  • Page 35 SPECIAL 1. When the SETUP menu screen is MAIN SETUP displayed, select ‘SPECIAL’ by using 1. VIDEO FORMAT the Function Setup switch so that the 2. D-WDR arrow indicates ‘SPECIAL’ . 3. WHITE BAL 2. Select a desired mode using the 4.
  • Page 36 camera operation - SHARPNESS : Select a mode to adjust the thickness of an image’s sharpness. Increase or decrease the level of each mode to adjust the level of sharpness. y OFF : Released state y ON : The setting range is 1 ~ 32. - RETURN : Return to the SPECIAL menu.
  • Page 37 - COLOR : The picture is always displayed in color. - B/W : The picture is always displayed in black and white. You can turn on or off the burst signal on B/W mode. y PRIVACY: Mask an area you want to hide on the screen. If the SPECIAL menu screen is ➊...
  • Page 38 camera operation ` MASK : Under Motion Detection, If you don’t want to see mosaic image on the screen, you may turn MASK OFF. If you wants to see mosaic image, please turn it on. ` TRANSPARENCY: Adds or removes transparency from the masking area. ` TOP/BOTTOM/LEFT/RIGHT : Area location can be adjusted.
  • Page 39 EXIT Select a desired EXIT mode using the Function Setup switch depending on the camera purpose. y SAVE : Save the current settings and exit the MAIN SETUP menu. y NOT SAVE : Do not save the current settings and exit the MAIN SETUP menu. y RESET : Revert camera to factory settings.

  • Page 40: Troubleshooting

    troubleshooting TROUBLESHOOTING If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. Problems Troubleshooting Nothing appears on the screen. y Check that the power cord and line connection between the camera and monitor are properly connected.
  • Page 41 SPECIFICATIONS (HCD-7010RA/7020RA/7030RA) HCD-7010RAN/ HCD-7020RAN/ HCD-7030RAN/ HCD-7010RAP HCD-7020RAP HCD-7030RAP Video Imaging Device 1/3” 4M CMOS Total Pixels 2720(H) x 1536(V) Effective Pixels 2688(H) x 1520(V) Scanning System Progressive Scan Color : 0.26Lux (F1.8, 1/30sec) Color : 0.27Lux (F2.0, 1/30sec) Color : 0.27Lux (F2.0, 1/30sec) Min.

  • Page 42: Specifications

    specifications HCD-7010RAN/ HCD-7020RAN/ HCD-7030RAN/ HCD-7010RAP HCD-7020RAP HCD-7030RAP White Balance ATW / Outdoor / Indoor(4,500K° ~ 8,500K°) / Manual / AWC (1,800K° ~ 10,500K°) Electronic Shutter Speed 1/30 sec ~ 1/12,000 sec(N), 1/25sec~ 1/12,000sec(P) Reverse Off / H-Rev / V-Rev Remote control interface Coaxial Protocol AHD : ACP (AHD Coax Protocol), CVBS : Pelco-C (Coaxitron)
  • Page 43 SPECIFICATIONS (HCV-7010RA/7020RA/7030RA) HCV-7010RAN/ HCV-7020RAN/ HCV-7030RAN/ HCV-7010RAP HCV-7020RAP HCV-7030RAP Video Imaging Device 1/3” 4M CMOS Total Pixels 2720(H) x 1536(V) Effective Pixels 2688(H) x 1520(V) Scanning System Progressive Scan Color : 0.26Lux (F1.8, 1/30sec) Color : 0.27Lux (F2.0, 1/30sec) Color : 0.27Lux (F2.0, 1/30sec) Min.
  • Page 44 specifications HCV-7010RAN/ HCV-7020RAN/ HCV-7030RAN/ HCV-7010RAP HCV-7020RAP HCV-7030RAP White Balance ATW / Outdoor / Indoor(4,500K° ~ 8,500K°) / Manual / AWC (1,800K° ~ 10,500K°) Electronic Shutter Speed 1/30 sec ~ 1/12,000 sec(N), 1/25sec~ 1/12,000sec(P) Reverse Off / H-Rev / V-Rev Remote control interface Coaxial Protocol AHD : ACP (AHD Coax Protocol), CVBS : Pelco-C (Coaxitron)
  • Page 45 SPECIFICATIONS (HCO-7010RA/7020RA/7030RA) HCO-7010RAN/ HCO-7020RAN/ HCO-7030RAN/ HCO-7010RAP HCO-7020RAP HCO-7030RAP Video Imaging Device 1/3” 4M CMOS Total Pixels 2720(H) x 1536(V) Effective Pixels 2688(H) x 1520(V) Scanning System Progressive Scan Color : 0.26Lux (F1.8, 1/30sec) Color : 0.27Lux (F2.0, 1/30sec) Color : 0.27Lux (F2.0, 1/30sec) Min.
  • Page 46 specifications HCO-7010RAN/ HCO-7020RAN/ HCO-7030RAN/ HCO-7010RAP HCO-7020RAP HCO-7030RAP Reverse Off / H-Rev / V-Rev Remote control interface Coaxial Protocol AHD : ACP (AHD Coax Protocol), CVBS : Pelco-C (Coaxitron) IR Distance 20m(65.62ft) 25(82.02ft) 30m(98.43ft) Video Transmission 500m(5C2V) Distance Environmental Operating Temperature / -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH Humidity * Start up should be done at above -10°C...

  • Page 47: Hcd-7010Ra/7020Ra/7030Ra

    DIMENSION Unit: mm (inch) <HCD-7010RA/7020RA/7030RA> English_47...

  • Page 48: Hcv-7010Ra/7020Ra/7030Ra

    Unit: mm (inch) <HCV-7010RA/7020RA/7030RA> 48_ specifications...

  • Page 49: Hco-7010Ra/7020Ra/7030Ra

    Unit: mm (inch) <HCO-7010RA/7020RA/7030RA> English_49...
  • Page 50 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwha-security.com Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom...
