Assembly Instructions and User Manual DIN EN 1004-2
Mobile scaffold tower in accordance with EN 1004-1 • Version 1.0 © 2022 KRAUSE-Werk
ClimTec
ClimTec
Scaffold Tower
Scaffold Tower
® ®

Table of Contents

GB
1. General ............................................................................................................. 36
1.1 Owner's responsibilities ............................................................................... 36
1.2 Manufacturer ............................................................................................... 36
1.3 Applicable standards .................................................................................... 36
1.4 Warranty ...................................................................................................... 36
1.5 Intellectual property rights ........................................................................... 36
1.6 Publication date ........................................................................................... 36
2. Product information ......................................................................................... 37
2.1 Intended use ................................................................................................ 37
2.2 Improper use ............................................................................................... 37
3. Safety instructions ........................................................................................... 37
3.1 Applicable regulations .................................................................................. 37
3.2 Safety instructions for assembly and use ..................................................... 37
or changing its configuration ....................................................................... 38
4. Assembly .......................................................................................................... 38
4.1 General ........................................................................................................ 38
4.2 Assembling the basic scaffold ..................................................................... 39
4.7 Fitting the outriggers (accessory) ................................................................ 60
4.9 Labelling after assembly ............................................................................. 64
4.10 Accessories ............................................................................................... 65
6. Technical data .................................................................................................. 66
7. Inspection, spare parts .................................................................................... 66
8. General safety information ............................................................................ 643
The information presented in this document is subject to changes, printing errors and omissions.
EXTRAS and work equipment are not included with the scaffold tower! • We do not accept any liability for improper
................................................. 38
®
on stairs ................................................................ 56
®
................................................................. 60
®
to a wall ................................................................. 64
®
.................................................................................. 66
®
use of the scaffold tower. • Only use original KRAUSE spare parts.
®
