Error Displays; Error Codes; Limited Warranty - CTEK PRO60 User Manual

ERROR DISPLAYS

Lights red to indicate error
ERROR
Wrong polarity
+/-
Reversed polarity, short circuit in charge
!
cables or power supply overload error.
Action: Connect the charger according to "how
OK to operate" or reduce in power supply.
ERROR
Overvoltage
!
The charger is connected to a 24V battery.
Action: Connect the charger to a 12V battery.
OK
ERROR
Overtemperature
!
The battery is too hot to charge.
Action: Let the battery cool down or the battery
is damaged and may need to be replaced.
OK
ERROR
Broken battery
!
Action: Check connections and settings, and
retry charging, before replacing the battery.
OK

ERROR CODES

Very occasionally, an error code may appear on the PRO60/PRO120 LCD
display screen which will be displayed as a number only.
73, 74 These error codes will appear when you first power up the
unit and indicate that the main control switch cannot start
communication with other internal hardware.
71, 72, These error codes will appear when the unit is in
75, 76, operation and indicate that the main control switch cannot
77 communicate with other internal hardware.
78 This error code will appear when the unit is in operation
and indicates that an internal hardware component has a
problem.
79 This error code will appear if a software update has not
been successful.
In addition to the error codes there are few error text strings which may
appear. These will appear just after a software update or hardware
replacement and indicate hardware or software incompatibility.
• 'Module hardware mismatch. Service needed!'
• 'Module firmware mismatch. Service needed!'
• 'Loaded firmware is not compatible with module hardware.'
• 'Module bootloader did not start. Service needed!'
If any of these error codes are displayed on the screen, you could try to
reset the operating system by disconnecting the PRO60/PRO120 from
its power source, and then turning it back on again. If the error code is still
displayed on the screen after this, please follow the warranty procedures
outlined in this user guide.

LIMITED WARRANTY

CTEK, issues this limited warranty to the original purchaser of this
product. This limited warranty is not transferable. The warranty applies to
manufacturing faults and material defects. The customer must return the
product together with the receipt of purchase to the point of purchase. This
warranty is void if the product has been opened, handled carelessly or
repaired by anyone other than CTEK or its authorised representatives. One
of the screw holes in the bottom of the product may be sealed. Removing or
damaging the seal will void the warranty. CTEK makes no warranty other
than this limited warranty and is not liable for any other costs other than
those mentioned above, i.e. no consequential damages. Moreover, CTEK is
not obligated to any other warranty other than this warranty.
SUPPORT
For support, FAQ, latest revised manual and more information about CTEK
products: www.ctek.com.
EN • 9
