CHARGE MODES

The table explains the different charge mode:
Mode
NORMAL
Use to charge GEL, WET and MF batteries.
Use to charge most AGM batteries including AGM START/STOP types.
AGM
Some AGM should use lower voltage (NORMAL Mode), check battery manual if unsure.
Use to charge Ca/Ca batteries including AGM START/STOP types.
Ca/Ca
Use Ca/Ca program to maximize charge with minimum loss of fluid.
LITHIUM
Use to charge Lithium batteries.
TECHNICAL SPECIFICATION - PRO60
Model number 1089
INPUT 220–240VAC, 50–60Hz, 9.2A
OUTPUT 60A, 12V
2.0V Lead Acid batteries
Start voltage
8.0V LiFePO batteries
4
Back current drain* Less than 2Ah/month
Ripple** Less than 4% voltage
Ambient -20°C to +50°C
temperature (-4°F to +122°F)
All types of 12V Lead Acid batteries
(WET, Ca/Ca, MF, AGM, GEL)
Battery types
12V (4cells) LiFePO
4
10–1800Ah, Lead Acid battery types
Battery capacity
15–600Ah, LiFePO
4
Insulation class IP40
Warranty 2 years
*) Back current drain is the current that drains the battery if the charger is not connected
to the mains. CTEK chargers have a very low back current.
**) The quality of the charging voltage and charging current is very important. A high
current ripple heats up the battery which has an aging effect on the positive electrode.
High voltage ripple could harm other equipment that is connected to the battery. CTEK
battery chargers produce very clean voltage and current with low ripple.
8 • EN
Explanation
TECHNICAL SPECIFICATION - PRO120
Model number
INPUT
OUTPUT
Start voltage
Back current drain* Less than 2Ah/month
Ripple**
Ambient
temperature
Battery types
batteries
Battery capacity
battery types
Insulation class
Warranty
*) Back current drain is the current that drains the battery if the charger is not connected
to the mains. CTEK chargers have a very low back current.
**) The quality of the charging voltage and charging current is very important. A high
current ripple heats up the battery which has an aging effect on the positive electrode.
High voltage ripple could harm other equipment that is connected to the battery. CTEK
battery chargers produce very clean voltage and current with low ripple.
1092
220–240VAC, 50–60Hz, 9.2A
120A, 12V
2.0V Lead Acid batteries
8.0V LiFePO batteries
4
Less than 4% voltage
-20°C to +50°C
(-4°F to +122°F)
All types of 12V Lead Acid batteries
(WET, Ca/Ca, MF, AGM, GEL)
12V (4cells) LiFePO batteries
4
10–3600Ah, Lead Acid battery types
15–1200Ah, LiFePO battery types
4
IP40
2 years
