Gestetner F540 Getting Started

Gestetner f540: install guide
Hide thumbs Also See for F540:
Table of Contents

Advertisement

Quick Links

Download this manual
Before You
Use This
Machine
Before you send or receive fax messages,
take about 30 minutes to set up your machine.
Set up your machine using the following procedures.
Operating Instructions
Before You Use This Machine
(this manual)
Paper size decals
Key layout sheet *1
Harness set *2
Handset bracket assembly
(bracket and four screws)
Bland plaque
Bland plaque Installation
Instructions
First,
check the supplies.
Type 2 (Color NIC FAX Unit standard) only:
CD-ROM
(LAN-Fax driver & Operating Instructions)
End-User License Agreements
NIC FAX UNIT CD-ROM Operating
Instractions
Ferrite core (for LAN)
*1:Attach this if you want to use the ABC
layout.
*2:Used by your service representative to
install the second optional paper tray unit.
Keep going...

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F540 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gestetner F540

Summary of Contents for Gestetner F540

  • Page 1 Before You Use This Machine Before you send or receive fax messages, take about 30 minutes to set up your machine. Set up your machine using the following procedures. First, check the supplies. Operating Instructions Type 2 (Color NIC FAX Unit standard) only: Before You Use This Machine CD-ROM (this manual)

  • Page 2: Preparing The Toner Cartridge

    R WARNING: • Disconnect the power (by pulling the plug, not the cable) if the power cable or plug becomes frayed or otherwise damaged. • To avoid electric shock or laser radiation exposure, do not remove any covers or screws other than those specified in this manual.
  • Page 3 Remove the protective material from the axis. ZHMX050E Close the ADF and make sure it locks securely into place. Open the front cover. ZHMH310E Remove the shipping tape. ZHMX190E Push the lever ( ) and pull out the toner cartridge holding ZHMT030E Remove the shipping tapes.
  • Page 4 Remove the tape from the toner cartridge. ZFWT030E Re-position the toner cartridge. Push the toner cartridge in until it locks securely into place. ZHMT040E Pull the two red tags to remove the plastic strips. ZHMX080E ZHMX090E Close the front cover. ZHMH320E Important •...
  • Page 5 Preparing the Main Paper Tray Pull the paper tray out of the main unit. ZHMY010E If necessary, adjust the paper size. As default, the paper size in the tray is set as 8 ” x 11”. Reference T To change the paper size in the paper tray, see Chapter 9 “Changing the Paper Size in the Main Paper Tray”, Advanced Features.

  • Page 6: Paper Tray Unit

    Installing the Optional Paper Tray Unit These instructions are for installing the first optional paper tray unit for Type 2 (Color NIC FAX Unit standard). If your machine is Type 1 (Color NIC FAX Unit optional), it is already installed. If you install the optional paper tray unit for Type 2 later, read the following WARNING, CAUTION and “Impor- tant”, and then perform...
  • Page 7 There are two pins on the top of the paper tray unit that point straight up. On the bottom of the machine there are two holes. Align the holes over the pins and lower the machine gently onto the paper tray unit. Note •...
  • Page 8 Installing the Optional 40MB Memory Card If you install the optional 40MB memory card later, read the following “Important”, and then perform Important • Turn the power switch off before installing cards, otherwise they could be damaged. • Fax files stored in memory will not be deleted while the optional 40MB memory card is installed.

  • Page 9: Installing The Optional Handset

    Installing the Optional Handset Remove the information card from the holder. ZFWP100E Attach the holder to the bracket with the two screws provided. Note • You can use a coin-like object to fix the screw. Continued on next page ZFWP110E Replace the information card.

  • Page 10: Connecting The Power And Switching On

    Connecting the Power and Switching On R WARNING: • Connect the power cord directly into a wall outlet. Never use an extension cord. Plug the cable into the outlet. Important • Power requirements : 120 V, 60 Hz • Insert the power plug securely into the outlet. •...
  • Page 11 Press the OK key. The following display appears. Make sure the current year setting is correct. If it is not, enter the year with the number keys. Press the OK key. Press the key to select the month. Press the OK key. Enter the date with the number keys (1 to 31) .

  • Page 12: Connecting The Telephone Line

    After Initial Settings • You can check and adjust these settings using function keys. TDate & Time : See Chapter 6, "Date/Time", Ad- vanced Features. TLine Type : See Chapter 7, "G3 Analog Line - Line Type", Advanced Features. TOwn Name, Fax Header, Fax Number : See Chap- ter 3, "Own Name/Fax Header"...
