Safety and Reference
Please read this manual carefully before operating your set and
retain it for future reference.
OLED65W7P
OLED77W7P
*MFL69707607*
www.lg.com
P/NO : MFL69707607 (1701-REV00)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OLED65W7P and is the answer not in the manual?

Questions and answers

Related Manuals for LG SIGNATURE OLED65W7P

Summary of Contents for LG SIGNATURE OLED65W7P

  • Page 1 Safety and Reference Please read this manual carefully before operating your set and retain it for future reference. OLED65W7P OLED77W7P *MFL69707607* www.lg.com P/NO : MFL69707607 (1701-REV00)
  • Page 2 Warning! Important Safety • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with instructions the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Read these instructions.
  • Page 3 • To reduce the risk of fire or electrical shock, • Antenna grounding according to the National Electrical Code, ANSI/NFPA 70 do not expose this product to rain, moisture or other liquids. Do not touch the TV with • Moving wet hands.
  • Page 4 Preparing • Never disassemble the AC adapter or power cord. This may result in fire or electric shock. • Handle the adapter carefully to avoid dropping • When the TV is turned on for the first time after or striking it. An impact could damage the being shipped from the factory, initialization of adapter.

  • Page 5: Lifting And Moving The Tv

    • When attaching the stand to the TV set, place • Use at least two people to move the screen facing down on a cushioned table or a large TV. flat surface to protect the screen from scratches. • When transporting the TV by (Depending upon model) hand, hold the TV as shown in the •...

  • Page 6: Basic Functions

    Basic Functions Provided Item Power On (Press) Power Off (Press and Hold) Volume Control Punching Guide Wall-mount Channels Control 1 : All running apps will close. Wall mounting screw Wall mounting anchor Adjusting the Menu Tools you will need When the TV is turned on, press the button one •...
  • Page 7 • When installing the product on wall material 4 Set the wall mount on the wall by aligning to not designated, install the product so that each the location of the hole. And, set the angle location can withstand the pull out load of 70 adjusting part to face upward.

  • Page 8: Connections (Notifications)

    If noise is present, change the PC output to another resolution, change the refresh rate to another rate or adjust the brightness (For OLED65W7P) and contrast on the PICTURE menu until the The Kensington security system connector is picture is clear.

  • Page 9: Other Connections

    Other Connections Connect your TV to external devices. For the best picture and audio quality, connect the external device and the TV with the HDMI cable. > General > • > > HDMI ULTRA HD Deep Color: - On : Support 4K @ 60 Hz (4:4:4, 4:2:2, 4:2:0) - Off : Support 4K @ 60 Hz 8bit (4:2:0) •...

  • Page 10: Battery Installation

    Battery Installation • DO NOT INGEST BATTERY. CHEMICAL BURN HAZARD. • The battery used in this device may present a fire or chemical burn hazard if mistreated. Do not recharge, disassemble, incinerate, or heat above 100 °C (212 °F). Replace the battery part no.

  • Page 11: Registering Magic Remote

    Streaming Service buttons Connects to the Video Streaming Service. (Input) Changes the input source. Adjusts the volume level. • Pressing and holding the (Input) button (Mute) Mutes all sounds. displays all the lists of external inputs. (Voice recognition) Control buttons for media contents Network connection is required to use the voice * Provides content related to the program you are currently watching.

  • Page 12: Troubleshooting

    Licenses Troubleshooting • Cannot control the TV with the remote control. Supported licenses may differ by model. - Check if anything such as tape has been placed For more information about licenses, over the receiver. visit www.lg.com. - Check if there is any obstacle between the product and the remote control.

  • Page 13: Specifications

    Television System • Abnormal Display - If the TV feels cold to the touch, there may be a ATSC, NTSC-M, 64 & 256 QAM small flicker when it is turned on. This is normal; there is nothing wrong with TV. Some minute Program Coverage dot defects may be visible on the screen, appearing as tiny red, green, or blue spots.
  • Page 14 Regulatory should be installed and operated with minimum distance 20 cm (7.8 inches) between the radiator and your body. Users must follow the specific operating instructions for satisfying RF exposure FCC NOTICE compliance. (For USA) Industry Canada Statement This equipment has been tested and found to (For Canada) comply with the limits for a Class B digital device, [For having wireless function (WLAN, Bluetooth,...)]...
  • Page 15 and 5650–5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. NOTE TO CABLE/TV INSTALLER (For USA and Canada) This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close...

  • Page 19: Child Safety

    CHILD SAFETY: PROPER TELEVISION PLACEMENT MATTERS THE CONSUMER ELECTRONICS INDUSTRY CARES • Manufacturers, retailers and the rest of the consumer electronics industry are committed to making home entertainment safe and enjoyable. • As you enjoy your television, please note that all televisions – new and old- must be supported on proper stands or installed according to the manufacturer’s recommendations.
  • Page 20 Declaration of Conformity LG Customer Information Center Trade Name: LG For inquires or comments, visit www.lg.com or call; Model: OLED65W7P-U, OLED77W7P-U 1-800-984-6306 Responsible Party: LG Electronics Inc. 1-888-542-2623 CANADA Address: 1000 Sylvan Ave. Englewood Cliffs NJ 07632 U.S.A Register your product Online! TEL: 201-266-2534 www.lg.com...

  • Page 21: External Control Device Setup

    OWNER’S MANUAL EXTERNAL CONTROL DEVICE SETUP Please read this manual carefully before operating the set and retain it for future reference. www.lg.com...

  • Page 22: Key Codes

    KEY CODES KEY CODES • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) CH +, PR + R/C Button List R/C Button CH -, PR - R/C Button Exit R/C Button Volume + R/C Button PIP(AD) R/C Button...
  • Page 23 EXTERNAL CONTROL DEVICE SETUP EXTERNAL CONTROL DEVICE SETUP • Image shown may differ from your TV. Connect the USB to Serial converter/RS-232C input jack to an external control device (such as a computer or an A/V control system) to control the product’s functions externally. Note: The type of control port on the TV can be different between model series.
  • Page 24 EXTERNAL CONTROL DEVICE SETUP (TV) (PC) (TV) (PC) Phone jack Type RS-232C IN • You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and (CONTROL & SERVICE) (PC) (TV) the TV, which is specified in the manual. RS-232C IN (CONTROL &...

  • Page 25: Communication Parameters

    EXTERNAL CONTROL DEVICE SETUP Communication Parameters • Baud rate : 9600 bps (UART) • Stop bit : 1 bit • Data length : 8 bits • Communication code : ASCII code • Parity : None • Use a crossed (reverse) cable. Command reference list (Depending on model) DATA...

  • Page 26: Transmission / Receiving Protocol

    EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV. (j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu. Adjustment range in TV is 1 to 99.
  • Page 27 EXTERNAL CONTROL DEVICE SETUP * Commands may work differently depending on model and signal. 01. Power (Command: k a) Ack [d][ ][Set ID][ ][OK/NG][Data][x] ► To control Power *On or Off of the set. * In case of video mute on only, TV will display On Transmission[k][a][ ][Set ID][ ][Data][Cr] Screen Display(OSD).
  • Page 28 EXTERNAL CONTROL DEVICE SETUP Data Min : 00 to Max : 64 Data Min : 00 to Max : 64 Ack [i][ ][Set ID][ ][OK/NG][Data][x] Ack [r][ ][Set ID][ ][OK/NG][Data][x] 09. Tint (Command: k j) * (Depending on model) ► To adjust the screen tint. 14.
  • Page 29 EXTERNAL CONTROL DEVICE SETUP Data 02 : Input Source (Digital) Step Frequency - 10 : Antenna TV (DTV) 0(decimal) - 20 : Antenna Radio (Radio) 1st Band - 40 : Satellite TV (SDTV) 1(decimal) 2nd Band - 50 : Satellite Radio (S-Radio) 3rd Band - 90 : Cable TV (CADTV) - a0 : Cable Radio (CA-Radio)
  • Page 30 EXTERNAL CONTROL DEVICE SETUP * Digital Antenna/Cable * Digital Antenna/Satellite Data 00: xx (Don't care) Data 00 : xx (Don't care) [Data 01][Data 02]: Major Channel Number [Data 01][Data 02]: Major Channel Number Data 01: High byte Channel Data Data 01 : High byte Channel Data Data 02: Low byte Channel Data Data 02 : Low byte Channel Data - 00 01 ~ 27 0F (Decimal: 1 ~ 9999)
  • Page 31 11 11 EXTERNAL CONTROL DEVICE SETUP 22. Key (Command: m c) 25. 3D(Command: x t) (only 3D models) (Depending on model) ► To send IR remote key code. ► To change 3D mode for TV. Transmission [m][c][ ][Set ID][ ][Data][Cr] Transmission [x][t][ ][Set ID][ ][Data 00][ ][Data 01] Data Key code - p.2.
  • Page 32 EXTERNAL CONTROL DEVICE SETUP 26. Extended 3D(Command: x v) (only 3D models) 27. Auto Configure (Command: j u) (Depending on model) (Depending on model) ► To change 3D option for TV. ► To adjust picture position and minimize image shaking automatically. It works only in RGB (PC) Transmission [x][v][ ][Set ID][ ][Data 00][ ] mode.
  • Page 33 EXTERNAL CONTROL DEVICE SETUP Network IP Control (For USA only) How to connect 1. Connect your TV to a wired or wireless network. 2. Press and hold the (Settings) button on the remote control for at least 5 seconds on the Live TV screen.
  • Page 34 EXTERNAL CONTROL DEVICE SETUP Command reference list COMMAND NOTE 01. Power POWER off ex) POWER off ASPECT_RATIO [4by3 /16by9 / 02. Aspect Ratio ASPECT_RATIO 4by3 setbyoriginal] SCREEN_MUTE [screenmuteon / 03. Screen Mute SCREEN_MUTE screenmuteon videomuteon / allmuteoff] 04. Volume Mute VOLUME_MUTE [on / off] VOLUME_MUTE on 0 to 100 (Decimal)
  • Page 35 EXTERNAL CONTROL DEVICE SETUP COMMAND NOTE KEY_ACTION [exit / channelup / channeldown / volumeup / volumedown / arrowright / arrowleft / volumemute / deviceinput / sleepreserve / livetv / previouschannel / favoritechannel / teletext / teletextoption / returnback / avmode / captionsubtitle / arrowup / arrowdown / myapp / settingmenu / ok / quickmenu / videomode / audiomode / channellist / bluebutton /...
  • Page 36 EXTERNAL CONTROL DEVICE SETUP COMMAND NOTE 0 : Right to Left 1 : Left to Right PICTURE_3D_EXTENSION * Precondition : picturecorrection [0 / 1] 1) PICTURE_3D on X X X ex) PICTURE_3D_EXTENSION picturecorrection 0 0 : off 1 : on * Colorcorrection, Sound Precondition : 1) PICTURE_3D on X X X PICTURE_3D_EXTENSION...
  • Page 37 OLED TV ENGLISH Easy Setup Guide OLED65W7P Please read this manual carefully before operating your set and retain it for future reference. OLED77W7P ESPAÑOL Guía Rápida de Configuración Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.
  • Page 38 ENGLISH Read Safety & Reference. ESPAÑOL Leer Seguridad y Consultas. FRANÇAIS Lisez Sécurité et références.
  • Page 40 OLED65W7P OLED77W7P...
  • Page 51 Current value / Power consumption Corriente de MODELS consumo MODELOS / Consumo de MODÈLES potencia Valeur courante / Consommation électrique OLED65W7P 1,450 1 450 3.85 3,85 1,260 1 260 5.2 A / 5,2 A / (OLED65W7P-U) 520 W 520 W (57.0)
