Grape Solar Photovoltaic Modules
This document applies to Grape Solar photovoltaic modules with model number GS-P60-265-Fab1, GS-P60-265-Fab2, GS-
S60LSQ-285-PR, GS-M60-285-Fab1-US, and GS-M60-300-Fab1-US. Carefully read through this manual in its entirety
before installing, operating or servicing the photovoltaic (PV) system. Failure to comply with the instructions described in
this manual may cause bodily injury or damage to property, and invalidate Grape Solar's limited warranty for photovoltaic
modules!
th
2635 W. 7
Place, Eugene, Oregon 97402, USA
www.grapesolar.com
User Manual
©Copyright 2017, Grape Solar, Inc. All Rights Reserved
1
1 Tel: 1-877-264-1014 (toll free), 1-541-349-9000, Fax: 1-541-343-9000
PHOTOVOLTAIC MODULES SAFETY
AND INST ALLATION MANUAL Rev. P
VALID IN NORTH AMERICA ONLY
Valid from February 2017

Advertisement

loading
Need help?

Need help?

Do you have a question about the GS-P60-265-Fab1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Grape Solar GS-P60-265-Fab1

  • Page 1 S60LSQ-285-PR, GS-M60-285-Fab1-US, and GS-M60-300-Fab1-US. Carefully read through this manual in its entirety before installing, operating or servicing the photovoltaic (PV) system. Failure to comply with the instructions described in this manual may cause bodily injury or damage to property, and invalidate Grape Solar’s limited warranty for photovoltaic modules! ©Copyright 2017, Grape Solar, Inc.
  • Page 2: Table Of Contents

    PHOTOVOLTAIC MODULES SAFETY AND INST ALLATION MANUAL Rev. P VALID IN NORTH AMERICA ONLY Table of Contents I. General Information ........................3 II. Safety Precautions ........................4 III. Module Installation ........................7 IV. Maintenance ..........................11 V. Disclaimer of Liability ......................... 12 2635 W.
  • Page 3: General Information

    10. Follow all safety precautions of other equipment and components used in the PV system. 11. Retain this manual for future reference. 12. Grape Solar recommends that the customer makes a note of the serial numbers of modules in order to keep a record of the system.
  • Page 4: Safety Precautions

    Do not disassemble, modify or adapt the module such as drilling holes in the frame or glass. Do not apply paint or adhesive to the module rear surface. Do not remove any part or labeling installed by Grape Solar from the module. Doing so will void the module warranty.
  • Page 5 PHOTOVOLTAIC MODULES SAFETY AND INST ALLATION MANUAL Rev. P VALID IN NORTH AMERICA ONLY 2.10 Do not leave a module unsupported or unsecured. 2.11 There are no user serviceable parts within the module. Do not attempt to repair any part of the module.
  • Page 6 4. Fire Safety Grape Solar’s PV modules are non-explosion-protected equipment and fire rated Type 1 or Type 2 (see panel spec sheet). Building fire safety may be affected by installing a PV system. Improper installation may lead to hazards in the event of fire.
  • Page 7: Module Installation

    MODULE INSTALLATION 1. Installation Site Selection The site for PV module installation shall have an environment temperature within Grape Solar’s PV module operating temperature range -40°C to +85°C (-40°F to +185°F). The site shall allow all modules to be exposed to sunlight without obstruction all year round (shadows generated by trees or buildings, even partial shading, on the module array will result in reduction of PV system yield).
  • Page 8 To prevent untrained personnel from disconnecting the modules when under load, which may cause serious bodily injury or death, all Grape Solar PV modules are equipped with factory- installed PV wires and MC-4-comparable connectors with locking safety clips. Once connected, the connector requires the use of a special tool to disconnect module-to-module connections.
  • Page 9 PV system installation must be integrated in the lightning protection system. Each PV module has 2 holes on back frame with grounding sign . Grape Solar recommends the following three methods of grounding the module frame: 4.3.1 Facing the back of the module, attach an ILSCO GBL-4DBT ground lug to either grounding hole at the back of the module.
  • Page 10 PHOTOVOLTAIC MODULES SAFETY AND INST ALLATION MANUAL Rev. P VALID IN NORTH AMERICA ONLY 1 Stainless steel M5 nut 2 Stainless steel cupped M5 washer 34 Stainless steStainless steeel l flat M5 M5 serrated washerwasher Grounding lead Stainless steel M5 bolt Figure-1 Grounding panel frame with stainless steel grounding &...
  • Page 11: Maintenance

    IV. MAINTENANCE No routine maintenance is required. Grape Solar recommends that periodic inspection of the PV system for tight electrical and mechanical connection and free of corrosion should be performed. Periodic cleaning of modules is not required, but is recommended, as periodic cleaning can result in better performance of the PV system, especially in regions with low levels of annual precipitation.
  • Page 12: Disclaimer Of Liability

    Furthermore, Grape Solar assumes no responsibility for any infringement of patents or other rights of third parties that may result from use of the module. No license is granted by implication or otherwise under any patent or patent rights.
