Grape Solar CS-S-175-DJ Installation & User Manual

Solar module
Hide thumbs Also See for CS-S-175-DJ:

Advertisement

Quick Links

Download this manual
Installation User Manual
CS-S-175-DJ, CS-S-180-DJ
CS-P-220-DJ, CS-P-230-DJ, CS-P-270-P, CS-P-280-DJ
4723 Pacific Ave. Eugene Oregon 97402 USA *
Technical Support & Customer Service: 1-877-264-1014 * Fax: 1-541-343-9000
Solar Module
For Module Model Number:
©Copyright 2009, Grape Solar Inc. All Right Reserved
www.GrapeSolar.com
Rev. 04
INSTALLATION
MANUAL
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CS-S-175-DJ and is the answer not in the manual?

Questions and answers

Related Manuals for Grape Solar CS-S-175-DJ

Summary of Contents for Grape Solar CS-S-175-DJ

  • Page 1 For Module Model Number: CS-S-175-DJ, CS-S-180-DJ CS-P-220-DJ, CS-P-230-DJ, CS-P-270-P, CS-P-280-DJ Rev. 04 ©Copyright 2009, Grape Solar Inc. All Right Reserved Page 1 4723 Pacific Ave. Eugene Oregon 97402 USA * www.GrapeSolar.com Technical Support & Customer Service: 1-877-264-1014 * Fax: 1-541-343-9000...

  • Page 2: Table Of Contents

    INSTALLATION MANUAL Table of Contents Thank you for selecting solar modules from Grape Solar. In order to use the modules properly, please read this Installation Manual carefully and completely before beginning work or installing the panels. About Solar Modules .................. 3 Characteristics and Names of Components ...........

  • Page 3: About Solar Modules

    Theory Grape Solar can supply monocrystalline solar modules. Under the sunlight, the cells in mono modules will produce electrons and cavities by photo-emission which is influenced by an internal electrical field. The electrons will go towards and assemble at Negative-silicon and cavities will go towards and assemble at Positive-silicon.
  • Page 4 INSTALLATION MANUAL Cell Function Diagram Internal electrode solar energy Exterior electrical polarity Anti-reflectance coating N-silicon P-silicon Page 4 4723 Pacific Ave. Eugene Oregon 97402 USA * www.GrapeSolar.com Technical Support & Customer Service: 1-877-264-1014 * Fax: 1-541-343-9000...

  • Page 5: Characteristics And Names Of Components

    INSTALLATION MANUAL Characteristics and Names of Components Key Factors • The module is highly efficient due to adopting a high-efficency cell • The module is highly reliable due to adopting highly transparent tempered glass • The structure of module is wind-resistant. Component Names (Front of Solar Module Example) Page 5...
  • Page 6 INSTALLATION MANUAL (Back of Solar Module Example) Page 6 4723 Pacific Ave. Eugene Oregon 97402 USA * www.GrapeSolar.com Technical Support & Customer Service: 1-877-264-1014 * Fax: 1-541-343-9000...
  • Page 7 STC, Voltage, (V STC, STC, (V dc) STC, Fuse, Model (V dc) (A dc) (A dc) (Watts) CS-S-180-DJ 44.2 36.2 4.97 5.36 CS-S-175-DJ 44.2 35.8 4.89 5.25 CS-P-220-DJ 35.87 29.40 7.48 8.40 CS-P-230-DJ 36.23 29.70 7.74 8.70 CS-P-270-DJ 43.65 35.20 7.67...

  • Page 8: Safety Warnings

    INSTALLATION MANUAL Safety Warning In order to use the modules properly, avoid property losses, and avoid injury to the operater or anyone else, warnings and some other caution signss are printed on the solar modules and Manuals. Sign Introduction Sign Introduction Means “Misoperation will cause a risk of lethal or personal serious injury ”...
  • Page 9 INSTALLATION MANUAL General warnings Warning Solar module installation, maintenance, removal and resetting shall only be done by ！ ！ ！ ！ distributor or professionals • If there were defects, there is a risk of electrical shock or fire. When installing, wiring, operating, removing and maintaining modules, pay attention to the risk of electrical shock •...
  • Page 10 INSTALLATION MANUAL Installation Warnings Warning Don’t stand or step on the solar Installing, maintaining, removing and modules Because glass resetting modules shall only be done by face of the module will be distributor or professionals. damaged and it is slippery which injure someone.
  • Page 11 INSTALLATION MANUAL Warning Grounding • Don’t install solar modules on movable If not connected properly, it will cause a • risk of electrical shock. Please don’t connect the cable objects such as doors or vehicles. with any other pipes such as gas pipe, water pipe, The glass may be damaged and cause thunder-avoiding rod etc.
  • Page 12 INSTALLATION MANUAL Caution don’t touch solar modules The module will reach high temperatures under sunshine, and may cause a risk of scalding Maintenance Warning warning Don’t open cover of junction box and clean inside with liquid, it may result in Don’t immerse the solar modules in electrical shock.

  • Page 13: Installation

    INSTALLATION MANUAL Don’t touch the cable of the solar module (cont’d) since DC electricity will be produced when solar module is under sunlight, please pay attention to this to avoid electrical shock. Specification for bypass diode Rated current Max reversing voltage Installation warning Installing, repairing, removing and resetting solar modules shall only be done by distributor and professionals...
  • Page 14 INSTALLATION MANUAL If you want to know the design for tilt angle of a support structure in a heavy snow area or littoral area please contact distributor Installation direction The module should face south to get sufficient sunlight and to optimize the output of the power generation. Tilt angle Irradiation each day will be different according to different latitudes all over the country.
  • Page 15 INSTALLATION MANUAL PV module installation Caution! Use the long side of module frame as the top. Use the side with 4 installation holes as the bottom. The modules shall be mounted so that the junction box is in the uppermost position to minimize the ingress of water. If PV modules are blow away, it will be very dangerous.
  • Page 16 Wiring and Connection Wiring Grape Solar modules come with pre-wired and terminated connectors ready for most grid-tie and off-grid wiring connection applications. Each module has two #10 AWG type of sunlight resistant output cables each terminated with Multi-Contact locking connectors. The positive connector has (+) for male terminal and the negative connector has (-) for female terminal.
  • Page 17 INSTALLATION MANUAL Grounding All module frames and mounting racks must be properly grounded in accordance with the National Electrical Code. Proper grounding is achieved by connecting the module frame(s) and structural members contiguously one to another using a suitable grounding conductor. The grounding conductor or strap may be copper, copper alloy, or other material acceptable for use as an electrical conductor per NEC.
  • Page 18 INSTALLATION MANUAL PV modules can be wired in parallel to in increase the current as shown in figure 2. In the case of parallel connection, please take proper measure to block the reverse current flow, not to exceed maximum series fuse rating per specified on the back label of each module (also indicated in Table 1) Page 18 4723 Pacific Ave.

  • Page 19: Maintenance & Inspection

    Since compliance with this guide and the conditions and methods of installation, operation, use and maintenance of the modules are not checked or monitored by Grape Solar Inc. Grape Solar accepts no liability for damage arising through improper use or incorrect installation, operation, use or maintenance.

  • Page 20: After-Sale Services

    If there was anything you want to know more please contact distributor. GRAPE SOLAR reserve the right to revise the models/contents without notice. Grape Solar reserves the right to revise the models/ contents without notice. Please see product warranty documentation for more details. Website: www.GrapeSolar.com...
