Features:
• 35 Watt Acoustic Amp
• 1– XLR and 2– 1/4" Inputs
• Master Volume
• Tilt-back Cabinet Design
• Master 3-Band EQ with Sweepable Mid
PRODUCT DESCRIPTION
an XLR balanced microphone input (with phantom power). The 2 inputs on channel 1 are summed (mixed) together
at a 1:1 ratio. Both channels are mixed together and pass through a 3 band equalizer with a sweepable midrange
frequency control. Equalization centers were carefully selected for use with acoustic instruments. Each channel also
contains individual send controls to the on-board Alesis® 15 program digital effects circuit. The channel signals are
The back panel contains an XLR balanced output with ground lift switch, unbalanced line output, and a 1/4" speaker
jack.
OWNERS MANUAL
– The Shenandoah™ JR
• 2 Channel with separate Volume and Effects Controls
• XLR Direct Out
• 10" Speaker and Compression Tweeter
• Phantom Power
• Alesis® Digital Effects with 15 presets
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Genz Benz Shen Jr
Summary of Contents for Genz Benz Shen Jr
-
Page 1: Owners Manual
OWNERS MANUAL Features: • 35 Watt Acoustic Amp • 1– XLR and 2– 1/4” Inputs • Master Volume • Tilt-back Cabinet Design • Master 3-Band EQ with Sweepable Mid PRODUCT DESCRIPTION an XLR balanced microphone input (with phantom power). The 2 inputs on channel 1 are summed (mixed) together at a 1:1 ratio. - Page 2 Phantom power is 13.6 volts, compatible with virtually all commonly used condenser microphones. Dynamic microphones can be used with no ill effect. COMBINING XLR & ¼” INPUTS microphone input and then adjusting the level control on the instrument itself (assuming that it has one) to blend levels between the 2 inputs.
- Page 3 – An internal phantom power source (13.6 volts) is provided for use with condenser mics. This power source is on at all times and does not affect the standard operation of the amp, even when a condenser mic is not used. We use the DIN 45-596-P12 volt standard which will operate virtually all of the live sound reinforcement condenser microphones on the market.
-
Page 4: Power Input
Only persons familiar with the operation of high powered audio equipment should attempt to operate this device. • In addition, by use of this device, the user agrees to hold Genz Benz, Inc. and it’s designers, sales agents and such use. - Page 5 XLR Balanced input sensitivity: ¼” Unbalanced input impedance: ¼” Unbalanced input sensitivity: AMPLIFIER OUTPUT Power at 4 ohm load: THD + N (preamp): THD + N (power amp): Frequency response: CHANNEL EQUALIZATION Low frequency: Mid frequency (sweep): High frequency: DIRECT OUTPUTS...
- Page 6 Operating Power Condition: Effective Date: Conforms to the Following Standards: REV 3 Declaration of Conformity (89/336 EEC-EMC Directive) Genz Benz, a division of Kaman Music 7811 East Pierce Street Scottsdale, AZ 85287, U.S.A. Shenandoah™ JR 115/230 V, 50/60 Hz 01-01-2006...
