Genz Benz Shen 300LT Owner's Manual

Genz benz shen 300lt: user guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

FEATURES:

• New Lightweight 51 lb. Design
• 300 Watt Stereo Output
• Two Identical Pre Amp Channels
• Two Stereo DSP Processors

PRODUCT DESCRIPTION

tic instrument amplifier with 2 separate digital effects engines, full stereo DSP algorithms and 2 x 10" speakers and
compression tweeters.
Each channel is equipped with both a ¼" unbalanced line input and an XLR balanced microphone input (with
phantom power). The 2 inputs on each channel are summed (mixed) together at a 1:1 ratio. Each channel then
passes through independent 4 band equalizers with 2 sweep-able midrange frequency bands. This powerful
equalizer circuitry was developed specifically for use with acoustic instruments and offers maximum flexibility in tone
shaping.
Each channel also contains 2 individual send controls to the dual on-board 16 program digital effects processors.
Flexible signal routing allows full exploitation of the lush stereo programs. The channel signals are then summed
and panned, mixed with the digital effects returns and passed on to the internal 300 watt stereo power amplifier.
The back panel contains 4 direct balanced outputs with ground lift switch, 4 unbalanced line outputs, 2 effects loops,
tuner out, effects cancel jack, and 4-1/4" speaker jacks.

OWNERS MANUAL

– The Shenandoah 300-LT™ is a 2 channel – 4 input, 300 watt true stereo acous-
• Stereo Pan Control on Each Channel
• Class D Power Amplification Technology
• Neodymium, High Efficiency 10" Loudspeakers
• Bottom-Mounted Tilt Back Kick Stand
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Shen 300LT and is the answer not in the manual?

Questions and answers

Related Manuals for Genz Benz Shen 300LT

Summary of Contents for Genz Benz Shen 300LT

  • Page 1: Owners Manual

    FEATURES: • New Lightweight 51 lb. Design • 300 Watt Stereo Output • Two Identical Pre Amp Channels • Two Stereo DSP Processors PRODUCT DESCRIPTION – The Shenandoah 300-LT™ is a 2 channel – 4 input, 300 watt true stereo acous- tic instrument amplifier with 2 separate digital effects engines, full stereo DSP algorithms and 2 x 10”...
  • Page 2 - An internal phantom power source (13.6 volts) is provided for use with condenser mics. This power source is on at all times and does not affect the standard operation of the amp, even when a condenser mic is not used. We use the DIN 45-596-P12 volt standard, which will operate virtually all of the live sound reinforcement condenser microphones on the market.

  • Page 3: Program Descriptions

    (long lush reverbs for example) may be the perfect program for jazz guitar, sax or flute. To accommodate the wide range of sum & difference effects in the stereo decay envelope software, effects volume differences are normal when switching between different effects programs.
  • Page 4 MASTER STATUS LED INDICATORS clipping. The green LED monitors the pre master molume output signal from the preamp before the power amp section. The red LED indicates clip/limit and shows that the maximum power threshold has been crossed and the internal “soft-clip”...
  • Page 5 CHANNEL INSERTS / EFFECTS LOOP – The Shenandoah 300-LT™ is equipped with insert points on each channel AND on the left and right main signal paths. These points are handy for inserting compressors and dedicated digital effects processors. Signal is line level and unbalanced. POWER AMPLIFIER –...
  • Page 6 ¼” Unbalanced aux input sensitivity: Phantom power (XLR Inputs) AMPLIFIER OUTPUT (each channel) Power at 8 ohm load: Power at 4 ohm load: THD + N (preamp): THD + N (power amp): Frequency response: CHANNEL EQUALIZATION Low frequency: Low-Mid frequency (sweep): High-Mid frequency (sweep):...
  • Page 7 • In addition, by use of this device, the user agrees to hold Genz Benz Enclosures, Inc. and its designers, sales agents and all other affiliates and related parties harmless in the event of any accident, injury, damage or loss resulting from such use.

  • Page 8: Declaration Of Conformity

    Operating Power Condition: Effective Date: Conforms to the Following Standards: REV 1 Declaration of Conformity (89/336 EEC-EMC Directive) Genz Benz, a division of Kaman Music 7811 East Pierce Street Scottsdale, AZ 85287, U.S.A. Audio Amplifier Shenandoah 300-LT 115/230 V, 50/60 Hz...
