OWNER'S MANUAL
PRODUCT DESCRIPTION – The SHUTTLE 6.0® bass amplifier has been designed with our unique ULTRA LIGHT
unified design process, yielding a 600 watt professional, high powered, tour-class, bass guitar amplifier weighing
less than 3.75 lbs! This compact design blends the best of analog and digital platforms to produce the ultimate in
warmth, punch, and power.
The SHUTTLE 6.0® is equipped with a ¼" unbalanced instrument input, input stage clip detector, mute switch with
LED indicator, 12AX7 tube preamp with extended range variable input gain, 3 switched signal shape filters with LED
indicators, 3 band active equalization with sweepable midrange frequency, master volume control, proprietary output
limiter, ¼" tuner output, aux. input, effects loop, balanced direct out with ground lift/pre-post/mic-line switches,
headphone output, and 2 Neutrik NL-4 "Speak-On"™ speaker jacks.
The power amp is a powerful, lightweight Class D design and is supported by a state-of-the-art digital Switch Mode
Power Supply (SMPS), which does away with the weight of a traditional power transformer. The SHUTTLE 6.0®'s
power supply is usable from 100-240 volts, lending itself well to international touring players.
1
