Aes/Ebu Input - Genelec 7260A Operating Manual

Stereo Pair with a Subwoofer (AES/EBU Dual-Wire)
This setup has two AES/EBU cables. Each carries one audio channel.
This mode assumes the source uses the Dual-wire mode of transmission. In this mode the AES/EBU
interface is operating at double speed (96 kHz) but consecutive audio samples use both subframes,
resulting in quad sample rate (19 kHz).
Run two AES/EBU cables from the source to the subwoofer AES/EBU Inputs 1 and . Run two audio
cables from the subwoofer AES/EBU outputs 1 and  to the digital audio inputs of the left and right
loudspeakers. The correct subframe must be selected in each loudspeaker.
Cable number Subframe
1
A+B
2 A+B
10
Audio channel Subwoofer Input
Connector
Left

AES/EBU INPUT 1

Right AES/EBU INPUT
Loudspeaker
Input Connector
DIGITAL IN
DIGITAL IN
