4.5.4 PROPERTIES INFORMATION

[Properties Info] is equipment specific. For the SR-1910, it includes Equipment ID, Firmware Info.,
Equipment Info., Site Location, Comm. Config and Trigger Report. Click on the specific property
information node to view details.
The following table provides descriptions of the [Properties Info.]
Parameter Name
Equipment ID
Firmware Info
Equipment Info
Site Location
Comm. Config
Trigger Report
Refer to OMT v3.20 product manual for detailed information (Ref. 0.6.3).

4.6 FAULT MANAGEMENT

Fault management involves inspecting and changing the thresholds and managing alarm conditions.
Generally, failure is due to poor radio signal, equipment (module failure) and site issues power, over
temperature).
The alarm is colour-coded to indicate its status and alarm levels. The alarm level is equipment specific. It
could be Alarm, Warning, Error or Critical.
Green: Normal, no alarm is generated.
Red: Alarm is generated; the alarm level could be Alarm, Warning, Error, or Critical.
On the tool bar of the main OMT screen, there is an "Alarm Indicator" showing the alarm level in real-time.
If a critical alarm occurs, the alarm indicator will remain at 'red'.
SR-1910 QI
ENU Status : 1-1-1
INSTALLATION GUIDE FOR SR-1910
Description
Displays the equipment Site ID and Site Sub ID information.
Displays the MCU firmware information, including detailed product
information, such as the platform on which the product is developed, the
working frequency, output power, etc., and firmware version number.
Displays information such as equipment type, equipment model and
equipment manufacture serial number. The equipment information cannot
be configured.
Displays the longitude and latitude of the equipment installation site. It refers
to the geographic co-ordinates provided by the operator during site
installation.
Displays the remote control information in groups, such as Checking Control,
Phone Number, SMSC Number, Alarm Report Mode, etc. The Comm.
Config information must be manually entered by the user after successful
connection to the equipment.
The [Checking Control] parameter group includes only one parameter –
Enable Phone No Checking. Phone Number Authentication feature is
enabled or disabled by selecting "Enable" or "Disable" from the drop down
menu in the "Enable Phone No Checking" field.
Using OMT v3.20, user can send a [New Site Report] request to the [Report
Number] specified in the window above, which usually is the SIM card
number of the modem installed in the OMC Server computer. The [Trigger
Report] parameter is used to indicate the status of sending the [New Site
Report] request. There are three statuses: Unreported, Waiting and
Reported.
Table 10: Properties Info descriptions
