1 SR-1910 REPEATER INTRODUCTION

The SR-1910 GSM1900 Band Adjustable Repeater is used where small-scale signal coverage for city
structures is desired (e.g., hotels, department stores and shopping malls, underground parking lots and
tunnels, convention centers, arenas, airports, etc.)
The SR-1910 is designed for indoor operation in the GSM1900 band. The band-specific linear amplifier
amplifies the desired BTS band and IF filtering effectively provides superior out-of-band rejection.
Local and remote configuration and surveillance is possible through laptop by using Comba's OMT/OMC
softwares. Internal Li-ion backup battery ensures alarm signals can be sent out in the event of power
failure.
The SR-1910 comes in a completely sealed, well-ventilated cast aluminum enclosure and is suitable for
indoor and sheltered outdoor environment.
Main Features
Downlink output power options of 0.05W and 0.5W that provides extended indoor cell coverage.
Band adjustable from 15M to 60M and customized 15M fixed bandwidth.
Adjustable centre frequency within 60M of the 1900MHz frequency band.
Superior filtering and amplification designed for both uplink and downlink signals
Low noise amplifier improves overall system noise figure for better voice quality and reduced drop call.
Can be configured as Master Unit (MS) or Slave Unit (SU) in a centralized monitoring system.
Local / remote control and monitoring function: operating status and parameters can be set or
monitored by the OMT PC.
OMC is available for remote operation and maintenance via an integrated wireless modem. (Optional)
Internal back-up Li-ion battery keeps the equipment running for up to two hours in case of power
failure.
The enclosure is designed for indoor and sheltered outdoor environment – waterproof, damp-proof
and omni-sealed (IP55).
Two product variants exist with SR-1910 – please refer to the product label for the identifier code to confirm
exact product variant.
Identifier Code
SR-1910-C2
SR-1910-C1
SR-1910 QI
ENU Status : 1-1-1
INSTALLATION GUIDE FOR SR-1910
Main Features
With integrated wireless modem. Function as Master or Slave Unit in
centralized monitoring system.
Without integrated wireless modem. Function as Slave Unit in centralized
monitoring system.
Table 1: SR-1910 variants
