- Page 1 Oper ator ′ s manual Rider 112C Rider 112C5 Please r ead the operator’s manual carefully and make sure you understand the instructions before using the machine. E E E E n n n n g g g g l l l l i i i i s s s s h h h h...
-
Page 2: Table Of Contents
CONTENTS Contents Checking the blades ............. Replacing the blades ............ CONTENTS Removing the BioClip plug ........... Contents ..............Lubrication INTRODUCTION Checking the engine’s oil level........Dear Customer, ............Replacing the engine oil ..........Driving and transport on public roads ......Lubricating the front wheel bearings ...... -
Page 3: Introduction
Dear Customer, Thank you for choosing a Husqvarna Rider. Husqvarna Riders are built to a unique design with a front-mounted cutting unit and a patented articulated steering. Riders are designed for maximum efficiency even in small or confined areas. The closely grouped controls and pedal-operated hydrostatic transmission also contribute to the performance of this machine. -
Page 4: Service Journal
Service journal Pre-delivery service 1 Charge the battery for 4 hours at max. 3 amp. 2 Fit steering wheel, seat and any optional equipment. 3 Check and adjust tyre pressure. (60 kPa, 0.6 bar, 9 psi). 4 Check that the right amount of oil is in the engine. 5 Make sure the battery is connected. -
Page 5: Key To Symbols
KEY TO SYMBOLS Symbols Clutch out These symbols are on the machine and in the instructions. Parking brake WARNING! Careless or incorrect use can result in serious or fatal injury to the operator or others. Brake Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS Safety instructions • Stop the engine and prevent the engine from being started until you have cleaned the outlet channel. These instructions are for your safety. Read them carefully. • Look out for the ejector and do not direct it towards anyone. -
Page 7: Driving On Slopes
SAFETY INSTRUCTIONS Driving on slopes • Never use the machine in bad weather, for instance in fog, in rain, damp or in wet locations,strong winds, intense cold, risk of lightning, etc. Driving on slopes is one of the operations where the risk of the driver losing control of the machine or of it overturning is •... -
Page 8: Children
SAFETY INSTRUCTIONS Maintenance • Do not try to stabilize the machine by putting your foot on the ground. • Stop the engine. Prevent starting by removing the ignition • When cleaning the chassis, the machine may never be cable from the spark plug or remove the ignition key driven near verges or ditches. -
Page 9: Transport
SAFETY INSTRUCTIONS • Be especially careful when handling battery acid. Acid on • Reduce the risk of fire by removing grass, leaves and the skin can cause serious corrosive injuries. In the event other debris that may have fastened on the machine. of spillage on the skin wash immediately with water. -
Page 10: What Is What
WHAT IS WHAT? Location of the controls Rider 112C 1 Product and serial number plate 8 Speed limiter for driving forward 2 Lever to disengage the drive 9 Cutting height adjustment lever 3 Battery 10 Parking brake 4 Throttle control/choke control 11 Lock button for parking brake 5 Ignition lock 12 Seat adjustment. -
Page 11: What Is What
WHAT IS WHAT? Location of the controls Rider 112C5 1 Product and serial number plate 8 Parking brake 2 Battery 9 Cutting height adjustment lever 3 Throttle control/choke control 10 Clutch pedal 4 Gear shift lever 11 Seat adjustment. 5 Ignition lock 12 Fuel cap 6 Lifting lever for the cutting unit 13 Cover lock... -
Page 12: Presentation
PRESENTATION Presentation Speed limiter Rider 112C The speed of the machine is steplessly regulated with two Congratulations on your choice of an excellent quality product pedals. Pedal (1) is used to drive forwards, and pedal (2) to that will give you great pleasure for many years. drive backwards. -
Page 13: Cutting Height Adjustment Lever
PRESENTATION Cutting height adjustment lever Release lever (112C) The cutting height can be adjusted to 5 (1-5) different The release control must be pulled out in order for the positions with the cutting height lever. machine to be moved when the engine is shutoff. Pull the controls to the end positions, do not use an intermediate position. -
Page 14: Driving
Driving Before starting Check the safety system • Read the safety instructions and information concerning The machine is equipped with a safety system that prevents the placement of controls and functions before starting. starting or driving under the following conditions. •... -
Page 15: Starting The Engine With A Weak Battery
Driving Rider 112C5 has the brake pedal and lock button on the right 8 When the engine starts release the ignition key hand side. The engine can not be started if the parking brake immediately back to neutral position. is not pressed down. 9 Move the choke lever gradually back once the engine has 4 For Rider 112C5 started. -
Page 16: Driving The Rider
Driving Connecting the jump leads Driving the Rider 1 Rider 112C Release the parking brake by first pressing down the parking brake pedal and then releasing it. Carefully press down one of the pedals until the required speed is obtained. Pedal (1) is used to drive forwards, and pedal (2) to drive backwards. -
Page 17: Starting On A Slope, Manual Gearbox
Driving Stop the engine 2 Select the required cutting height (1-5) using the cutting height lever. Always park the machine on a level surface with the engine OFF. Avoid idling the engine for long periods, as there is a risk of carbon build-up on the spark plugs. -
Page 18: Maintenance
Maintenance Maintenance schedule The following is a list of the maintenance which should be conducted on the machine. For those points not described in this manual, visit an authorised service workshop. Daily maintenance At least once a Maintenance interval Maintenance before starting year in hours... -
Page 19: Cleaning
Maintenance Cleaning Belt Guard Release the clip and lift off the belt guard. Clean the machine directly after use. It is much easier to wash off grass cuttings before they dry. Checking and adjusting the steering wires IMPORTANT INFORMATION Always park the machine on The steering is controlled by means of wires. -
Page 20: Checking The Parking Brake
Maintenance Checking the parking brake Adjusting the throttle wire Check that the brake is correctly adjusted by placing the The throttle cable may need to be adjusted, if the engine does machine on a slight downhill slope with the clutch disengaged not respond as it should when accelerating, if it produces and activating the brake. -
Page 21: Replacement Of Fuel Filter
Maintenance Checking the tyre pressure IMPORTANT INFORMATION Do not use compressed air to clean the paper filter. The tyre pressure should be 60 kPa / 0.6 bar / 8,7 PSI on all wheels. In order to improve drive power, the pressure in the Do not oil the paper filter. -
Page 22: Fuses
Maintenance Fuses Checking the engine’s cooling air intake The main fuse is placed in a detachable holder behind the battery under the protective cover. Clean the air intake grille in the engine cover behind the driver’s seat. Open the engine cover. Type: Flat pin, 15 A. - Page 23 Maintenance 4 Check that the lever for setting the cutting height is in the Fitting the cutting head S position. 1 Push the cutting deck in and make sure the guide bolts fit into the grooves on the deck frame, one on each side. 2 Fit the cutting deck's pipe together with the deck frame's 5 Put the lifting lever in the mowing position.
-
Page 24: Checking The Blades
Maintenance Checking the blades • The blade must be mounted with the angled ends pointing up towards the cover. To achieve the best mowing results it is important that the blades are undamaged and well-sharpened. Check that the blades’ attachment screws are tight. •... -
Page 25: Lubrication
Lubrication Checking the engine’s oil level. 5 Fill the oil slowly. The oil is topped up through the hole the dipstick sits in. See Checking the engine’s oil level for filling instructions. Check the oil level in the engine when the Rider stands horizontal with the engine switched off. -
Page 26: Troubleshooting Schedule
Troubleshooting schedule Problem Cause There is no fuel in the fuel tank Faulty spark plug. Defective ignition cable. Engine does not start Dirt in the carburettor or fuel line Starter motor does not turn over the engine Defect safety switch Battery flat Bad contact between the cable and battery Lift lever for cutting unit in wrong position... -
Page 27: Storage
Storage Winter storage Guard At the end of the season, or if the machine is going to stand There is a cover to protect your machine during storage or idle for more than 30 days, it should immediately be made transport. -
Page 28: Technical Data
TECHNICAL DATA Rider 112C5 Rider 112C Dimensions Length without cutting unit, mm/ft 1781/5.84 1781/5.84 Length with cutting unit, mm/ft 2100/6.89 2100/6.89 Width without cutting unit, mm/ft 797/2.61 793/2.60 Width with cutting unit, mm/ft 883/2.90 883/2.90 Height, mm/ft 1084/3.56 1084/3.56 Machine without cutting unit, with empty tanks, kg/lb 154/340 154/340 Wheel base, mm/ft... -
Page 29: Ec Declaration Of Conformity
EC Declaration of Conformity (Applies to Europe only) Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel.: +46-36-146500, hereby declares that Husqvarna Rider 112C and Rider 112C5 from 2014’s serial numbers and onwards (the year is clearly stated in plain text on the rating plate with subsequent serial number), complies with the requirements of the COUNCIL’S DIRECTIVE:... - Page 32 Original instructions 1156981-26 ´®z+X§,¶66¨ ´®z+X§,¶66¨ 2016-01-13 Rev.2...
