- Page 1 USB•400 U S E R M A N U A L www.gefen.com...
- Page 2 Chatsworth, CA 91311 support@gefen.com www.gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. USB•400 is a trademark of Gefen Inc. ExtremeUSB is a trademark of Icron Inc.
-
Page 3: Table Of Contents
Introduction Operation Notes USB Series Installation USB•400 Panel Layout USB•400 Function Description Wiring Diagram Link Cable Diagram Check List Troubleshooting Hints Warranty TABLE OF CONTENTS... -
Page 4: Introduction
Thank you for purchasing the ex•tend•it USB•400 Series. The new USB•400 incorporates ExtremeUSB™ technology, which allows users the benefi ts of USB technology beyond the desktop. Extending your USB peripherals (i.e. computer keyboard, mouse or trackball) up to 330 feet away from the location of your Macintosh or PC computer are done easily with the USB•400. -
Page 5: Operation Notes
OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE USB•400 SYSTEM. * The USB•400 send and receive were designed to operate on USB enabled computers. DO NOT attempt to use this equip ment with any other type of computer. * Use the computer's USB port when using a local keyboard that is not extended with the USB•400 sender unit. - Page 6 USB•400 SERIES INSTALLATION 1. Place the USB•400R unit close to the USB devices at the re mote end. 2. Connect the USB devices to the USB•400R unit. 3. Connect the power adapter to a suitable AC source wall outlet. 4. Connect the power adapter to the USB•400R unit using the supplied cable. 5.
-
Page 7: Usb•400 Panel Layout
USB•400 PANELS LAYOUT USB•400S USB In Link Power USB•400R Link Power USB•400R 12 11 12 11 12 11 12 11... -
Page 8: Usb•400 Function Description
USB•400 FUNCTION DESCRIPTION USB LED - Indicates if a USB connection is made properly USB In - USB cable (A-B) cable from computer to sender Link LED - Indicates if a link between the USB•400S send and the USB•400R Receive units Link - CAT-5 Modular Jack which connects to the USB•400S send and the USB•400R Receive units Power LED - Indicates the unit is plugged in and powered up. -
Page 9: Wiring Diagram
WIRING DIAGRAM... -
Page 10: Link Cable Diagram
LINK CABLE - WIRING DIAGRAM... -
Page 11: Check List
CHECK LIST 1. On the USB•400S send unit, check that the power in di ca tor is GREEN. 2. On the USB•400S send unit, check that the link indicator is GREEN. 3. On the USB•400R receiver unit, check that the power in di ca tor is GREEN. 4. -
Page 12: Troubleshooting Hints
TROUBLESHOOTING HINTS Power Indicator is not lit. -- Make certain the power supply unit is properly con nect ed to the USB•400R unit and to a proper local power sup ply outlet. Link Indicators are Green. -- Make certain that the host computer is operating and responding to commands. If re- quired, reset the com put er. -
Page 13: Warranty
Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
