- Page 1 Mini USB Extender U S E R M A N U A L www.gefen.com...
- Page 2 Chatsworth, CA 91311 support@gefen.com www.gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. Mini USB Extender is a trademark of Gefen Inc. ExtremeUSB is a trademark of Gefen Inc.
-
Page 3: Table Of Contents
Introduction Operation Notes USB Series Installation Mini USB Extender Panel Layout Troubleshooting Troubleshooting Link Cable Diagram Warranty TABLE OF CONTENTS... -
Page 4: Introduction
USB devices by buff ering the USB signal through the send and receive line driv ers and the signal is extended by using standard Category 5 (CAT-5) cabling. You can connect additional Mini USB Extenders to the same computer, allowing you to access the computer from multiple locations up to 150 feet apart. -
Page 5: Operation Notes
OPERATION NOTES READ THESE NOTES BEFORE INSTALLING OR OPERATING THE MINI USB EXTENDER SYSTEM. * The Mini USB Extender sender and receiver were designed to operate on USB type computers. DO NOT attempt to use this equip ment with any other type of device. * Use the computer's USB port when using a local keyboard that is not extended with the Mini USB Extender sender unit. - Page 6 MINI USB EXTENDER SERIES INSTALLATION 1. Place the Mini USB Extender receiver unit close to the USB devices at the re mote end. 2. Connect the USB devices to the Mini USB Extender receiver unit 3. Place the Mini USB Extender sender unit close to the host computer. 4.
-
Page 7: Mini Usb Extender Panel Layout
MINI USB EXTENDER PANELS LAYOUT MINI USB EXTENDER SENDER USB In from computer MINI USB-2 RECEIVER 2 port USB Hub connects to USB devices MINI USB-1 RECEIVER 1 port USB Hub connects to USB devices Device LED (green) Link LED (yellow) -
Page 8: Troubleshooting
6. If the second device does not operate, the extender may be malfunctioning. Contact Ge- fen technical support for assistance. 7. If the second device does operate properly, the fi rst device may not be compatible with the extender. Contact Gefen technical support for assistance. -
Page 9: Troubleshooting
Sender unit to the computer. 5. If the second device does not oper- ate, the extender may be malfunctioning. Contact Gefen technical support for assis- tance. 6. If the second device does operate prop- erly, the fi rst device may not be compatible with the extender. -
Page 10: Link Cable Diagram
LINK CABLE - WIRING DIAGRAM... -
Page 11: Warranty
If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
