- Page 1 HDMI Super Booster Plus U S E R M A N U A L www.gefen.com...
- Page 2 20600 Nordhoff St. Chatsworth, CA 91311 support@gefen.com www.gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying The HDMI Super Booster Plus is a trademark of Gefen Inc. ASKING FOR ASSISTANCE (818) 772-9100...
-
Page 3: Table Of Contents
Introduction Features Panel Descriptions Connecting and Operating the HDMI Super Booster Plus Auto Equalization Specifi cations Warranty TABLE OF CONTENTS... -
Page 4: Introduction
INTRODUCTION The Gefen HDMI Super Booster Plus is an attractive alternative to the traditional sender/receiver solutions for HD extension. The HDMI Super Booster Plus enables your standard “off the shelf” HDMI cable to transmit HDTV video plus multichannel digital audio in a single cable way beyond the limited HDMI specifi cation of 15-feet. -
Page 5: Features
Features • Perfect digital high defi nition video sent over long stretches of HDMI cables • Locate an HDMI display up to 200 feet away from any HDTV source • Supports resolutions up to 1080p, 2K, and 1920 x 1200 •... - Page 6 PANEL LAYOUT Front Panel Power LED Manual EQ Indicator Adjustment HDMI In Back Panel +5V DC In HDMI Out...
-
Page 7: Connecting And Operating The Hdmi Super Booster Plus
CONNECTING AND OPERATING THE HDMI SUPER BOOSTER PLUS Connect the long HDMI cable from the source into the “HDMI In” on the front of the HDMI Super Booster Plus. The HDMI Super Booster Plus is placed next to your display to regenerate the HDMI signal. Connect a short HDMI cable from the “HDMI Out”... -
Page 8: Auto Equalization
Manual EQ Long Cable Manual EQ Long Cable Auto EQ ON Auto EQ ON Manual EQ Short Cable Manual EQ Short Cable Dip Switch 2 can be used to turn on the automatic equalization function. Use this setting for ease of setup as this mode will automatically tune out unwanted video noise. -
Page 9: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ... 165 MHz Input Video Signal ...1.2 Volts p-p Input DDC Signal ... 5 Volts p-p (TTL) Maximum Single Link Range ... 1920 x 1200 x 60hz HDMI Input/Output Connector Type ... HDMI Type A Power Consumption ...
