Summary of Contents for Clevo W970SUW

  • Page 1 W970SUW...
  • Page 3 Preface Notebook Computer W970SUW Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W970SUW series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup º...

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Part List Illustration Location ............A-2 Top ....................A-3 Overview ..................1-1 Bottom ................... A-4 Specifications ..................1-2 LCD ....................A-5 External Locator - Top View with LCD Panel Open ......1-4 HDD ....................A-6 External Locator - Front & Right Side Views .........1-5 Combo ...................
  • Page 12 Preface 3G, WLAN, MSATA ..............B-24 HDD, CCD, TPM, Power Con ............. B-25 USB3.0, LED, USB Charger ............B-26 Card Reader / LAN RTL8411B ........... B-27 TP/Audio Con, G-Sensor ............. B-28 HDMI, RJ45, Fan ................. B-29 Audio Codec VT1802S ..............B-30 KBC-ITE IT8587 .................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W970SUW series notebook computer. Informa- tion about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Storage Intel® Core™ i7 Processor (Factory Option) One Changeable 9.5mm(h) Optical Device Type Drive (Super Multi Drive Module or Blu-Ray Combo i7-4702MQ (2.20GHz) Drive Module) 6MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 37W  (Factory Option) Dummy ODDor Caddy Bay i7-4600M (2.9GHz) Latest Specification Information One Changeable 2.5"...
  • Page 15 Introduction Pointing Device Environmental Spec Built-in Clickpad Temperature ° ° Operating: 5 C - 35 Interface Non-Operating: -20°C - 60°C Relative Humidity Two USB 3.0 Ports Two USB 2.0 Ports Operating: 20% - 80% One HDMI-Out Port Non-Operating: 10% - 90% One External Monitor Port Power One Headphone-Out Jack...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red. 3. Built-In Microphone 4. LCD 5.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator FRONT VIEW Figure 3 Right Side View 1. Microphone-In RIGHT SIDE VIEW Jack 2. Headphone-Out Jack 3. USB 2.0 Ports 4. Optical Device Drive Bay 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor LEFT SIDE VIEW Port 4. Vent 5. HDMI-Out Port 6. USB 3.0 Ports 7. Multi-in-1 Card Reader Figure 5 REAR VIEW...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery Location 2. Vent 3. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector (mSATA module) 2. CPU 3. Memory Slots DDR3L SO-DIMM 4. Mini-Card Connector (WLAN Module) 5. Intel PCH 6. CMOS Battery Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. HDMI-Out Port 2. USB 3.0 Ports 3. Keyboard Cable Connector 4. Audio Board Cable Connector 1 - 10 Mainboard Overview - Top (Connectors)

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. ODD Connector 2. HDD Connector 3. External Monitor Port 4. RJ-45 LAN Jack 5. DC-In Jack 6. CCD Connector 7. LCD Cable Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W970SUW series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Keyboard: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn off the computer, turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a in place.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 or 7.0mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as HDD Assembly outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 3. Lift the bottom cover from point (Figure 3b Figure 3 4. Remove the bottom cover (Figure 3c HDD Assembly 5. Slightly lift and pull the hard disk assembly in the direction of arrow (Figure 3d Removal (cont’d.) 6. Lift the hard disk assembly out of the bay (Figure 3e 7.
  • Page 32 Disassembly Hard Disk Size Note (Foam Rubber Insert) Note that the hard disks pictured on the following pages are all 9.5mm(H) hard disk drives. In some cases 7mm(H) hard disk drives will be installed. For more information contact your distributor/supplier, and bear in mind your warranty terms.

  • Page 33: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 5 Optical Device 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - Removal 2. The optical device will be visible at point on the mainboard (Figure 5a 3.
  • Page 34 Disassembly 6. Reverse the process to attach the front bezel with the new optical device at point (Figure 6e). Figure 6 7. Insert the new optical device and carefully slide it into the computer (the device only fits one way. DO NOT Optical Device FORCE IT;...

  • Page 35: Removing The 2Nd (7Mm) Hdd From The Caddy Bay

    Disassembly Removing the 2nd (7mm) HDD from the Caddy Bay Figure 7 1. Turn off the computer, turn it over to remove the battery (page 2 - 5), bottom cover (page 2 - 6) and ODD (page 2 2nd (7mm) HDD Removal 2.

  • Page 36: Removing And Installing A Processor

    Disassembly Removing and Installing a Processor Figure 8 Processor Removal Processor Removal Procedure 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and the component bay cover (page 2 - a. Locate the CPU heat sink.
  • Page 37 Disassembly 6. Carefully (it may be hot) remove the heat sink unit off the computer (Figure 9e Figure 9 7. Turn the release latch towards the unlock symbol to release the CPU (Figure 9f). Processor Removal 8. Carefully (it may be hot) lift the CPU up and out of the socket (Figure 9g).
  • Page 38 Disassembly Processor Installation Procedure Figure 10 Processor 1. Insert the CPU (Figure 10a), pay careful attention to the pin alignment, it will fit only one way (DO NOT Installation FORCE IT!), and turn the release latch towards the lock symbol (Figure 10b).

  • Page 39: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 11 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal single or dual channel DDR3L depending on the CPU. The main memory can be expanded up to 16GB. The SO-DIMM modules supported are 1024MB and 2048MB DDR3L Modules.
  • Page 40 Disassembly 4. Pull the latches to release the second module if necessary. 5. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 6. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot as it will go.

  • Page 41: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 12 Keyboard Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 2. Press at point to release the keyboard (Figure 12a). a. Release the keyboard by 3. Turn the computer over, remove the keyboard (Figure 12c).
  • Page 42 Disassembly 6. Connect the keyboard ribbon cable from the locking collar socket , and be careful not to bend the keyboard rib- Figure 13 bon cable (Figure 13f). Keyboard Assembly 7. Replace and tighten the screws (Figure 12a). d. Connect the keyboard ribbon cable to the lock- ing collar socket.

  • Page 43: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 14 Wireless LAN 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 14a).

  • Page 44: Wireless Lan And Combo Module Cables

    Disassembly Wireless LAN and Combo Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, LTE and 3G modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 45: Removing The Msata Module

    Disassembly Removing the mSATA Module Figure 15 mSATA Module 1. Turn off the computer, turn it over, remove the battery (page 2 - 12) and bottom cover (page 2 - Removal 2. The mSATA module will be visible at point on the mainboard (Figure 15a).

  • Page 46: Removing The Ccd

    Disassembly Removing the CCD Figure 16 CCD Removal 1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - 2. Remove screws and disconnect cables & from the bottom assembly (Figure 16a).
  • Page 47 Disassembly 6. Remove the LCD front cover (Figure 16c). Figure 17 7. Disconnect the cable CCD Removal 8. Remove the CCD module (Figure 17f). (cont’d) 9. Reverse the process to install a new CCD module. e. Remove the LCD front cover.
  • Page 48 Disassembly 2 - 24...

  • Page 49: Part Lists

    Appendix A:Part Lists This appendix breaks down the W970SUW series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 50: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 page A - 6 page A - 7 Combo page A - 8...

  • Page 51: Top

    Figure A - 1 Top A - 3...

  • Page 52: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 53: Lcd

    Figure A - 3 LCD A - 5...

  • Page 54: Hdd

    Figure A - 4 A - 6 HDD...

  • Page 55: Combo

    Combo Figure A - 5 Combo Combo A - 7...

  • Page 56: Dvd Dual

    DVD DUAL Figure A - 6 DVD DUAL A - 8 DVD DUAL...

  • Page 57: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the W970SUW notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 58: System Block Diagram

    Schematic Diagrams System Block Diagram 5V,3V,5VS,3VS Audio Board SHEET 31 SHEET 37 (W540) W5xx/W9xxSU1 System Block Diagram (Shark Bay) Power Switch Board 1.05VS SHEET 38 (W54/W55) SHEET 32 Audio Board VDD3,VDD5 SHEET 39 (W55) Haswell SHEET 33 PS8625 ODD Board PROCESSOR (EDP TO LVDS) SHEET 40...

  • Page 59: Processor 1/7

    Schematic Diagrams Processor 1/7 Haswell rPGA Processor 1/7 ( DMI,PEG,FDI ) VCCIOA_OUT U17A Haswell rPGA EDS PEG_IRCOMP 24.9_1%_04 PEG_RCOMP PEG_RXN_0 [16] DMI_TXN0 DMI_RXN_0 PEG_RXN_1 [16] DMI_TXN1 DMI_RXN_1 PEG_RXN_2 [16] DMI_TXN2 DMI_RXN_2 PEG_RXN_3 [16] DMI_TXN3 DMI_RXN_3 PEG_RXN_4 PEG_RXN_5 [16] DMI_TXP0 DMI_RXP_0 PEG_RXN_6 [16] DMI_TXP1...
  • Page 60 Schematic Diagrams Processor 2/7 Haswell Processor 2/7 ( CLK,MISC,JTAG ) 1.05V_LAN_M Processor Pullups/Pull downs H_THRMTRIP_R_N *100_04 R301 VCCIO_OUT CPU_RST_N *75_04 R312 62_04 R309 H_PROCHOT# DDR3 Compensation Signals 10K_04 R297 H_CPUPWRGD_R SM_RCOMP_0 R327 100_1%_04 TRACE WIDTH 10MIL, LENGTH <500MILS SM_RCOMP_1 R324 75_1%_04 SM_RCOMP_2 R328...
  • Page 61 Schematic Diagrams Processor 3/7 Haswell Processor 3/7 ( DDR3 ) M_A_DQ[63:0] [10] M_B_DQ[63:0] Haswell rPGA EDS U17C Haswell rPGA EDS U17D M_A_DQ0 AR15 SA_DQ_0 RSVD_AC7 M_A_DQ1 AT14 M_B_DQ0 AR18 SA_DQ_1 SA_CK_N_0 M_A_CLK_DDR#0 SB_DQ_0 RSVD M_A_DQ2 AM14 M_B_DQ1 AT18 M_A_CLK_DDR0 M_B_CLK_DDR#0 [10] SA_DQ_2 SA_CK_P_0...
  • Page 62 Schematic Diagrams Processor 4/7 Haswell Processor 4/7 ( POWER ) Short V_VCCDDQ V_VDDQ_DIMM *OPEN-3mm 0.1u_10V_X5R_04 0.1u_10V_X5R_04 VCCIN Haswell rPGA EDS U17E PROCESSOR CORE POWER AA26 V_VCCDDQ ICCMAX Maximum Processor SV 48 AA28 VCCIN AA34 4.2A RSVD AA30 RSVD AA32 RSVD C331 C329 AB26...
  • Page 63 Schematic Diagrams Processor 5/7 Haswell Processor 5/7 ( GRAPHICS POWER ) VCCIOA_OUT 3.3VS EDP_RCOMP 24.9_1%_04 EDP_UTIL *10K_04 VCCIO_OUT Haswell rPGA EDS U17H DP_AUXN DDIB_TXBN_0 EDP_AUXN DP_AUXP DDIB_TXBP_0 EDP_AUXP DP_HPD# DDIB_TXBN_1 EDP_HPD EDP_RCOMP 10K_04 Sheet 6 of 45 DDIB_TXBP_1 EDP_RCOMP EDP_UTIL DDIB_TXBN_2 EDP_DISP_UTIL DDIB_TXBP_2...
  • Page 64 Schematic Diagrams Processor 6/7 Haswell Processor 6/7 ( GND ) Haswell rPGA EDS U17F Haswell rPGA EDS U17G AK34 AL10 AL11 AL12 AL14 AL15 AL17 AL18 AL20 AL21 AL23 AA11 AA25 AA27 AA31 AA29 AB10 AA33 AA35 AM10 AM13 AC25 AM16 AC27 AM19...

  • Page 65: Processor 7/7

    Schematic Diagrams Processor 7/7 Haswell Processor 7/7 ( RESERVED ) CFG Straps for Processor PCI EXPRESS STATIC LANE REVERSAL FOR ALL PEG PORTS 1: (DEFAULT)NORMAL OPERATION; (Default) CFG2 LANE# DEFINITION MATCHES 0: LANE REVERSAL Haswell rPGA EDS U17I CFG2 *1K_04 RSVD_TP RSVD_TP RSVD_TP...

  • Page 66: Ddr3 So-Dimm_1

    Schematic Diagrams DDR3 SO-DIMM_1 SO-DIMM A_0 V_VDDQ_DIMM CHANGE TO STANDARD C357 C103 C359 C100 0.1u_10V_X5R_04 *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 0.1u_10V_X5R_04 0.1u_10V_X5R_04 JDIMM1A M_A_A[15:0] M_A_DQ[63:0] M_A_A0 M_A_DQ0 JDIMM1B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 V_VDDQ_DIMM V_VDDQ_DIMM M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 VDD1 VSS16 M_A_A6 M_A_DQ6 VDD2 VSS17...

  • Page 67: Ddr3 So-Dimm_0

    Schematic Diagrams DDR3 SO-DIMM_0 SO-DIMM B_0 CHANGE TO STANDARD JDIMM2B V_VDDQ_DIMM JDIMM2A M_B_A[15:0] M_B_DQ[63:0] M_B_A0 M_B_DQ0 M_B_A1 M_B_DQ1 VDD1 VSS16 M_B_A2 M_B_DQ2 VDD2 VSS17 M_B_A3 M_B_DQ3 VDD3 VSS18 M_B_A4 M_B_DQ4 VDD4 VSS19 M_B_A5 M_B_DQ5 VDD5 VSS20 M_B_A6 M_B_DQ6 VDD6 VSS21 M_B_A7 M_B_DQ7 VDD7...

  • Page 68: Ps8625

    Schematic Diagrams PS8625 3.3VS 3.3VS VDDIO PWM_IN R474 *0_04 PANEL_PWM HCB1005KF-121T20 HCB1005KF-121T20 BCNR3010C-2R2M HCB1005KF-121T20 VDDIOX SW_OUT VDD12 VDDRX R286 R285 10K_04 10K_04 C310 C309 C299 RTD_PLVDD_EN RTD_PLVDD_EN [12] 0.47u_10V_Y5V_04 1u_6.3V_X5R_04 0.47u_10V_Y5V_04 4.7u_6.3V_X5R_06 4.7u_6.3V_X5R_06 *4.7u_6.3V_X5R_06 ENBLT 1u_6.3V_X5R_04 ENBLT [12] C312 C311 PANEL_PWM PANEL_PWM [12]...

  • Page 69: Panel, Inverter

    Schematic Diagrams Panel, Inverter PANEL CONNECTOR (30Pin_eDP & 40Pin_LVDS CO-lay) PANEL POWER VLED OPEN_2A LED PANEL (LVDS Dual Channel). 3.3VS Q11A *MTS3572G6 4.7K_04 4.7K_04 VLED D02A J_LCD2 P_DDC_DATA P_DDC_DATA [11] P_DDC_CLK P_DDC_CLK [11] 3.3V BRIGHTNESS_R *0.22u_50V_Y5V_06 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 R279 *4.7K_06 INV_BLON R282 1M_04...

  • Page 70: Crt

    Schematic Diagrams 5VS_CRT RB551V-30S2 J_CRT1 3.3VS C10556-11505-L *20mil_04 FCM1005MF-600T01 FRED [17] DAC_RED 2.2K_8P4R_04 *20mil_04 FCM1005MF-600T01 FGRN [17] DAC_GREEN *20mil_04 FCM1005MF-600T01 FBLUE [17] DAC_BLUE C326 C325 C324 DDCDATA DDCDATA HSYNC [17] DAC_DDCADATA DDC_IN1 DDC_OUT1 DDCLK VSYNC [17] DAC_DDCACLK DDC_IN2 DDC_OUT2 HSYNC_C R306 33_04 HSYNC...

  • Page 71: Lynx 1/9

    Schematic Diagrams Lynx 1/9 Lynx Point - M (HDA,JTAG,SATA) RTCVCC BAT54CS3 VDD3 C268 1u_6.3V_X5R_04 RTC_VBAT_1 C393 R249 18p_50V_NPO_04 2011/12/29 20K_1%_04 RTC_RST# R252 6-22-32R76-0B2 6-22-32R76-0BG R385 LPT_PCH_M_EDS 1K_04 C257 JOPEN1 U24A 1u_6.3V_X5R_04 *OPEN_10mil-1MM MC-306_32.768KHz 10M_04 SATA_RXN0 RTC CLEAR SATA ODD J_RTC1 SATA_RXN_0 R245 C389...

  • Page 72: Lynx 2/9

    Schematic Diagrams Lynx 2/9 NO REBOOT STRAP 3.3VS NO REBOOT STRAP: HDA_SPKR High Enable 3.3V_PCH 10K_04 R153 LPC_SIRQ 2.2K_8P4R_04 SML0_CLK Lynx Point - M (LPC,SMBUS,SPI,C-LINK) SML0_DATA SMB_DATA iTPM ENABLE/DISABLE TPM FUNCTION:SPI_SI High Enable SMB_CLK *1K_04 R334 SPI_SI PCH_GPIO74 R207 10K_04 LPT_PCH_M_EDS U24D SML1CLK...

  • Page 73: Lynx 3/9

    Schematic Diagrams Lynx 3/9 Lynx Point -M (DMI,FDI,PWRGD) 3.3VS LPT_PCH_M_EDS U24B PM_CLKRUN# R127 8.2K_04 AW22 DMI_RXN0 DMI_RXN_0 AR20 AC_PRESENT R185 *100K_04 DMI_RXN1 DMI_RXN_1 AJ35 FDI_RXN_0 FDI_TXN0 AP17 DMI_RXN2 DMI_RXN_2 AV20 AL35 FDI_TXN1 DMI_RXN3 DMI_RXN_3 FDI_RXN_1 RTCVCC AY22 AJ36 FDI_TXP0 DMI_RXP0 DMI_RXP_0 FDI_RXP_0 AP20...

  • Page 74: Lynx 4/9

    Schematic Diagrams Lynx 4/9 3.3VS BLON *1K_04 R239 L_BRIGHTNESS_R *1K_04 R240 HDMI_CTRLDATA 2.2K_04 R243 HDMI_CTRLCLK 2.2K_04 R246 Lynx Point -M (CRT,LVDS,PCI,DISPLAY) 10K_8P4R_04 Boot BIOS Strap CRIT_TEMP_REP#_R [18] CRIT_TEMP_REP#_R D_GPU_PWM_SELECT# SB_KBCRST# BBS_BIT1 BBS_BIT0 Boot BIOS Location [18,30] SB_KBCRST# D_GPU_PWR_EN# R419 150_1%_04 DAC_BLUE R416 150_1%_04...

  • Page 75: Lynx 5/9

    Schematic Diagrams Lynx 5/9 Lynx Point - M (GPIO,CPU/MISC,NCTF) 3.3V_PCH R154 10K_04 HOST_ALERT#1 R164 10K_04 PCH_GPIO8 PLL_ODVR_EN R172 *10K_04 U24F LPT_PCH_M_EDS R183 10K_04 PCH_GPIO27_R S_GPIO R162 100_04 S_GPIO_R BMBUSY#/GPIO0 R200 10K_04 PM_LANPHY_ENABLE LPM Enable: R215 SMI# LPM Disable: R200 [30] SMI# TACH1/GPIO1 R215...

  • Page 76: Lynx 6/9

    Schematic Diagrams Lynx 6/9 3.3V_PCH RN13 10K_8P4R_04 Lynx Point -M (PCIe,USB) USB_OC#01 USB_OC#1011 For 17" USB_OC#45 USB_OC#23 2.0 P O R T -B&1  &DUG 5HDGHU U24I LPT_PCH_M_EDS U S B 2 7 P O R T U S B 3 . 0 RN14 10K_8P4R_04 USB_OC#89...

  • Page 77: Lynx 7/9

    Schematic Diagrams Lynx 7/9 Lynx Point -M (POWER) 0.1A 1.5A VCCA_DAC_1_2 1.5VS U24G LPT_PCH_M_EDS 1.05V_LAN_M HCB1608KF-121T25 VCCADAC1_5 AA24 C266 C264 AA26 CRT DAC C277 C274 C153 C210 C222 C194 AD20 VCCADACBG3_3 AD22 10u_6.3V_X5R_06 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 AD24 AD26 BB44 VCCVRM AD28 AE18 AN34...

  • Page 78: Lynx 8/9

    Schematic Diagrams Lynx 8/9 Lynx Point - M (POWER) 3.3V_PCH 3.3V PJ14 *OPEN-2mm 3.3V_PCH 0.015A 3.3V_PCH VDD3 PJ15 0.261A *OPEN-2mm C225 C238 *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 LPT_PCH_M_EDS C242 U24H 0.1u_16V_Y5V_04 3.3V_PCH Sheet 21 of 45 Default 1.05V_LAN_M VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 VCCSUS3_3 R232 *20mil_04 VCCSUS3_3 Lynx 8/9...

  • Page 79: Lynx 9/9

    Schematic Diagrams Lynx 9/9 Lynx Point -M (GND) Lynx Point -M (CLK) U24K LPT_PCH_M_EDS AA16 AA20 LPT_PCH_M_EDS AA22 U24C AA28 AB12 AB35 CLKOUT_PCIE_N_0 CLKOUT_PEG_A AB34 AB38 BA40 AB36 CLKOUT_PCIE_P_0 CLKOUT_PEG_A_P BD11 BD15 PCIECLKRQ0# PEG_CLKREQ# PCIECLKRQ0#/GPIO73 PEGA_CLKRQ#/GPIO47 AC44 BD19 AD14 AY36 AA44 CLKOUT_PCIE_N_1 CLKOUT_PEG_B...

  • Page 80: 3G, Wlan, Msata

    Schematic Diagrams 3G, WLAN, MSATA 3G/MSATA MINI CARD C297 220u_6.3V_6.3*6.3*4.2 C316 0.1u_16V_Y5V_04 J_3G1 60mils 6-36-00180-202 3G_3.3V WAKE# 3.3V_0 3G_3.3V BT_DATA 1.5V_0 UIM_PWR BT_CHCLK UIM_PWR 3G POWER UIM_DATA UIM_PWR *4.7K_04 UIM_DATA UIM_DATA SIM CONN UIM_CLK CLKREQ# UIM_CLK C314 UIM_RST M S A T A f u n c t i o n REFCLK- UIM_RESET UIM_VPP...

  • Page 81: Hdd, Ccd, Tpm, Power Con

    Schematic Diagrams HDD, CCD, TPM, Power Con SLB9655TT & NPCT420 COLAY HDD CONNECTOR (CO-LAY) TPM 2.0 13&7 PRXQW J_HDD1 J_HDD2 R100 *0_04 Gen3 3.3V SATA_TXP5_R C415 0.01u_16V_X7R_04 SATA_TXP5_R 6/% PRXQW SATA_TXP5 [14] SATA_TXN5_R C411 0.01u_16V_X7R_04 SATA_TXN5_R 0_04 SATA_TXN5 [14] [15,30] LPC_AD0 LAD0 3.3VS...

  • Page 82: Usb3.0, Led, Usb Charger

    Schematic Diagrams USB3.0, LED, USB Charger USB Charger PORT 3.3VS R393 *0_04 [9,16,30,31,32] SUSB# HDD LED AIRPLAN LED R397 0_04 USB_DD_ON# R271 R270 [30,31,33] DD_ON PRE# USB_PN0 USB_PN0_R 220_04 220_04 [19] USB_PN0 USB_PP0 USB_PP0_R [19] USB_PP0 WLAN LED R409 10K_04 VDD5 VDD5 C406...

  • Page 83: Card Reader / Lan Rtl8411B

    Schematic Diagrams Card Reader / LAN RTL8411B LAN (RTL8411B) 4 IN 1 SOCKET SD/MMC/MS/MS Pro CO-LAY Crystal 503 2 SI Z E RSET R159 2.49K_1%_04 Switching Regulator close to PIN48 meet realtek Freq tolerance 50ppm J_CARD-REV1 SD_CD# R160 *1K_04 CD_SD XTAL2 R151 0_06...

  • Page 84: Tp/Audio Con, G-Sensor

    Schematic Diagrams TP/Audio Con, G-Sensor TP CONN G Sensor 3.3V 10u_6.3V_X5R_06 C376 0.1u_10V_X7R_04 C377 10/8 TP_VCC R479 *0_06 3.3VS 3.3V 3.3V_GSENSOR R427 0_06 3.3V_GSENSOR C420 C419 R360 *20mil_04 R429 R428 Q16A *10u_6.3V_X5R_06 1u_6.3V_X5R_04 MTDK5S6R J_TP1 10K_04 10K_04 G_I2CC SMB_CLK [9,10,15] R381 R366 TP_CLK...

  • Page 85: Hdmi, Rj45, Fan

    Schematic Diagrams HDMI, RJ45, Fan HDMI Repeater no level shief, D9,D10,D11 mount HDMI CONNECTOR ISET 3.3VS HDMI_SDA-C [17] HDMI_CTRLCLK 5VS_HDMI HDMI_SCL-C [17] HDMI_CTRLDATA For ESD 1.5VS 1.5VS 5VS_HDMI FLG# VOUT1 R145 R146 2.2K_04 2.2K_04 VIN1 VOUT2 VIN2 VOUT3 *BAV99 RECTIFIER *BAV99 RECTIFIER [31,34] SUSB...

  • Page 86: Audio Codec Vt1802S

    Schematic Diagrams Audio Codec VT1802S CODEC (ALC269Q_VB7) DVDD_IO PVDD1_2 3.3VS R430 *28mil_06 R433 *20mil_04 C431 C440 C429 C422 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 976/ XQPRXQW $/&4/ PRXQW 5VS_AUD C428 C286 HCB1005KF-121T20 3.3VS 3.3VS_AUD 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 HCB1005KF-121T20 C292 *1u_6.3V_X5R_04 PD# Control 3.3VS_AUD C432 C426 5VS_AUD...

  • Page 87: [30] Kbc-Ite It8587

    Schematic Diagrams KBC-ITE IT8587 KBC_AVDD *CV-40mil HCB1005KF-121T20 R111 10K_04 R112 1K_04 VDD3 VDD3 VDD3 C146 C138 C139 C137 10u_10V_Y5V_08 C168 C167 0.1u_10V_X7R_04 0.1u_10V_X7R_04 0.1u_10V_X7R_04 [16] SUS_PWR_ACK GPJ0/TACH2 5VT/SSCE0#/GPG2 AUTO_LOAD_PWR [31] 0.1u_10V_X7R_04 *0.1u_10V_X7R_04 GPJ4/DAC4/DCD0# GPJ5/DAC5/RIG0# C158 [14] ME_WE GPJ2/DAC2//TACH0B KSO16/SMOSI/GPC3 BT_DET# [23] KBC_AGND 0.1u_10V_X7R_04 KSO17/SMISO/GPC5...

  • Page 88: 5Vs, 3Vs, 3.3Vm, 1.5Vs Cpu

    Schematic Diagrams 5VS, 3VS, 3.3VM, 1.5VS CPU 3.3VS DD_ON# SUSB SLP_A NMOS PQ14A VDD3 SYS15V MTNN20N03Q8 3.3VS VDD3 VDD3 VDD3 PR139 PR136 PR47 PC34 PR134 PC37 PR45 10K_04 100K_04 1M_04 100_04 100K_04 DD_ON# [25,27] SUSB [28,34] 3.3VS_EN1 SLP_A [31,32] PQ34B PQ33 PC116 PC113...

  • Page 89: 1.05V Series

    Schematic Diagrams 1.05V Series PR141 280K_04 1.05V_LAN_M VTT_SELECT VTT VR Output Voltages IMAX:5A 1.1 V PC124 PC131 PC134 high (V1.1S_VTT) 1.05 V OCP:10A 4.7u_25V_X5R_08 4.7u_25V_X5R_08 1u_6.3V_X5R_04 PR146 1.05V_LAN_M For CV test PR142 3.3V PC122 10_04 0_06 PJ27 *CV-40mil PC128 0.1u_50V_Y5V_06 TMPC0603H-1R0M-Z01 PR153 10K_04...

  • Page 90: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VDD3/VDD5 VREF PR173 *0_04 PR64 *20mil_04 PC51 1u_6.3V_X5R_04 PR161 PR62 EN_3V EN_5V PC150 130K_04 130K_04 PC49 1000p_50V_X7R_04 1000p_50V_X7R_04 VREG3 PC140 PC138 PC139 PC153 PC136 PC137 PC148 PR61 *10K_04 4.7u_25V_X5R_08 4.7u_25V_X5R_08 1u_6.3V_X5R_04 10/4 add VDD3 SYS5V LDO3 PC48 0.1u_10V_X5R_04 VDD5...

  • Page 91: Ddr 1.5V Or 1.35V/0.75Vs Pch 1.5Vs

    Schematic Diagrams DDR 1.5V or 1.35V/0.75VS PCH 1.5VS 1.5V or 1.35V/0.75VS 1.5V or 1.35V PC93 PC95 PC96 PC94 IMAX:8A RB0540S2 G5616 VDDQ_VTT PC103 PQ30 OCP:15A VDDQ 10u_10V_Y5V_08 MTB11N03Q8 PC29 0.1u_10V_X5R_04 Short VLDOIN VBST PJ20 PR117 Short VDDQ_VTT DRVH VDDQ V_VDDQ_DIMM 2.2_04 PJ19 *OPEN-2mm...

  • Page 92: Vcore

    Schematic Diagrams VCore 3.3VS PR78 100K_1%_NTC_04 PR109 300K_1%_0603 SWN3 100K_04 PUT COLSE PC25 PC78 PC28 PC53 TO VCORE PR108 300K_1%_0603 SWN1 *4mm Phase 1 PJ18 PR107 PR106 APGND Inductor VIN_CPU *CV-40mil 75K_1%_04 165K_1%_04 PC62 PC55 PC69 PC89 PC154 PC21 PQ28 PR77 0_04 VR_EN...

  • Page 93: Charger, Dc In

    Schematic Diagrams Charger, DC IN SMART CHARGER PR23 *20mil_04 PQ21 EMB20P03V V_BAT PR94 *10K_06 J_DC_JACK1 10/18 6-15-32023-7B0 50932-00301-001 VJACK BTD-05TEAB for W540SU1 PQ19 PQ23A PL10 J B A T T A 2 EMB20P03V EMB17A03V HCB2012KF-800T80 PR67 PR12 BTD-06RC1B for W94SU 0.01_1%_32 8.2UH_6.8*7.3*3 0.01_1%_32...

  • Page 94: Audio Board

    Schematic Diagrams Audio Board USB PORT AS_USBVCC 60 mil PCBA CHECK ASC3 ASC2 ASC4 0.1u_16V_Y5V_04 1ASR1 *0_04 4ASR1 *0_04 2ASR1 *0_04 5ASR1 *0_04 ASJ_USB1 ASGND Port3 ASL6 3ASR1 *0_04 6ASR1 *0_04 ASUSB_PN1 ASUSB_PN1_R DATA_L ASUSB_PP1 ASUSB_PP1_R DATA_H *WCM2012F2S-161T03-short US04036BCA081 6-21-B49C0-104 6-21-B49B0-104 ASGND TO M/B...

  • Page 95: Power Switch Board

    Schematic Diagrams Power Switch Board POWER SW & LED PCBA CHECK SS_3.3VS POWER 1SSMR *0_04 4SSMR *0_04 SWITCH 2SSMR *0_04 5SSMR *0_04 SSR1 220_04 3SSMR *0_04 6SSMR *0_04 20mil SSC2 *0.1u_16V_Y5V_04 SSJ_SW1 SSMGND SSMGND SSM_BTN# SSD2 RY-SP150DBW71-5A SS_3.3VS 20mil 6-52-56001-023 6-52-56001-028 85201-04051 6-52-56000-020...

  • Page 96: Audio Board

    Schematic Diagrams Audio Board USB PORT AA_USBVCC AA_USBVCC_2 60 mil 60 mil AAC18 AAC3 AAC2 AAC19 AAC15 AAC16 AAC4 AAC17 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 10/18 Port3 10/18 Port4 AAJ_USB1 AAJ_USB2 AAGND AAGND *WCM2012F2S-161T03-short AAL6 AAUSB_PN1 AAUSB_PN1_R AAUSB_PN2 AAUSB_PN2_R DATA_L DATA_L AAUSB_PP1 AAUSB_PP1_R AAUSB_PP2 AAUSB_PP2_R DATA_H...

  • Page 97: External Odd Board

    Schematic Diagrams External ODD Board ODD BOARD FROM M/B TO ODD QJ_ODD1 QJ_ODD2 PCBA CHECK Q_SATA_TXP1 Q_SATA_TXN1 Q_SATA_RXN1 Q_SATA_RXP1 *0_04 *0_04 QGND QGND *0_04 *0_04 Q_ODD_DETECT# Sheet 40 of 45 Q_5VS Q_5VS *0_04 *0_04 External ODD Q_SATA_ODD_DA# Board 242003-1 C185J9-11308-L GND1~2=WGND QGND QGND...

  • Page 98: Lid Switch Board

    Schematic Diagrams LID Switch Board LID SWITCH BOARD L_VDD3 LJ_LID1 L_LID_SW# 85204-03001 L_GND For 15" L_VDD3 Sheet 41 of 45 L_U1 L_LID_SW# LID Switch Board L_C1 0.1u_16V_Y5V_04 MH248-ALFA-ESO H2_3B5_0D2_3 C44D44N C44D44N L_GND L_GND 6-02-00248-LC2 6-02-00268-LC1 L_GND DMFWP! DP/! ! Title Title Title [41] LID SWITCH BOARD...

  • Page 99: Touch Panel Board

    Schematic Diagrams Touch Panel Board T_5VS TJ_TPT1 TJ_TPT2 Sheet 42 of 45 T_USB_PN1 T_USB_PP1 Touch Panel Board GB5RF101-110N-7H 85205-05001 TGND DMFWP! DP/! ! Title Title Title [42] TOUCH PANEL BOARD [42] TOUCH PANEL BOARD [42] TOUCH PANEL BOARD Size Size Size Document Number Document Number...

  • Page 100: Audio Board (W94

    Schematic Diagrams Audio Board (W94) USB PORT PCBA CHECK A_USBVCC 60 mil 1AAR *0_04 4AAR *0_04 0.1u_10V_X5R_04 2AAR *0_04 5AAR *0_04 AJ_USB1 3AAR *0_04 6AAR *0_04 AGND AUSB_PN1 AUSB_PN1_R DATA_L AUSB_PP1 AUSB_PP1_R DATA_H *WCM2012F2S-SHORT US04036BCA081 6-21-B49C0-104 6-21-B49B0-104 AGND Sheet 43 of 45 TO M/B AUDIO JACK Audio Board (W94)

  • Page 101: Power Switch Board (W94

    Schematic Diagrams Power Switch Board (W94) POWER SW & LED S_3.3VS POWER SWITCH 330_04 PCBA CHECK 20mil *0.1u_10V_X5R_04 1PPR *0_04 4PPR *0_04 SJ_SW1 SMGND SMGND 2PPR *0_04 5PPR *0_04 SM_BTN# *HT-150BP HT-150BP S_3.3VS 20mil 3PPR *0_04 6PPR *0_04 6-52-57001-022 50578-0040N-001 6-52-57301-021 SMGND Sheet 44 of 45...

  • Page 102: Power On Seq

    Schematic Diagrams Power On SEQ W5XXSU EVT SEQ VDD3 VDD5 476us DD_ON 1.04ms 1.76ms 3.3V 56ms PWR_BTN 222.4ms SUSC# 367.4us 1.35V 200us DDR1.35V_PWRGD 34.8us SUSB# 2.02ms 1.5VS 1.72ms 3.3VS 2.57ms 1.2ms 1.05V_LAN_M 2.02ms 1.05V_LAN_PWRGD Sheet 45 of 45 ALL_SYS_PWRGD 339ms PM_PCH_PWROK Power On SEQ 392ms...

  • Page 103: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 104: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
