en
14
LED indicator Meaning
1 – 4 green Percentage of
LED charge condition
Continuous Battery is almost
red light empty
Red flashing Battery is not
light ready for opera-
tion
The real percentage of the battery charge condition is
only indicated when the power tool motor is stopped.
The electronics automatically switch off the motor prior
to the battery being deep discharged.
Selecting the rotation direction (see page 8).
A short beep sounds when actuating the rotational direc-
tion switch.
In left-hand running mode, both LED indicators
(red/green) flash.
The selected rotation direction is maintained until actuat-
ing the rotational direction switch again.
Changing the battery does not effect a change of the rota-
tion direction.
Meaning of the LED indicators and the beeps of the
power tool (see page 3).
Green LED indicator lit.
The screwdriving operation has been carried out prop-
erly. The preset torque has been reached.
Red LED indicator lit and a short beep.
The screwdriving operation has not been carried out
properly. The preset torque has not been reached. The
screwdriving operation must be carried out once more.
Red LED indicator lit and no beep.
The rotational direction switch or the On/Off switch
were pressed while sliding on the battery. Release the
switches again. When the red LED indicator goes out, the
machine is ready for operation again.
When the red LED indicator does not go out, either a
memory error is given or the On/Off switch is defective.
The electronic system is defective and must be replaced
by the after-sales service.
Red LED indicator flashes (1 time per second).
The battery is discharged (empty) and must be replaced.
The machine is blocked and will not be ready for opera-
tion until after being voltage-free for approx. 10 seconds.
Red LED indicator flashes (2 times per second).
The machine is overheated, the over-temperature pro-
tection has responded. After cooling down, the machine
is ready for operation again. If the over-temperature pro-
tection responds several times briefly after each other,
have the power tool checked by the after-sales service.
Brief lighting up of both LEDs.
The cordless screwdriver switches to the Energy Saving
Mode.
Repair and customer service.
Activity
Operation
Blow out the interior of the power tool via the ventila-
Charge battery
tion slots frequently with dry and oil-free compressed air.
After 500 000 screwdriving operations, the gearing
Bring the battery into
is to be relubricated with grease at the motor pinion
the battery operat-
and at the bearing axis of the planetary gears (grease
ing-temperature
3 21 60 014 23 0).
range, then charge
If required, you can change the following parts yourself:
application tools, battery

Warranty and liability.

The warranty for the product is valid in accordance with
the legal regulations in the country where it is marketed.
In addition, FEIN also provides a guarantee in accordance
with the FEIN manufacturer's warranty declaration.
The delivery scope of your power tool may include only
a part of the accessories described or shown in this
Instruction Manual.

Declaration of conformity.

FEIN declares itself solely responsible for this product
conforming with the relevant provisions given on the last
page of this Instruction Manual.
Technical documents at: C. & E. FEIN GmbH, C-DB_IA,
D-73529 Schwäbisch Gmünd

Environmental protection, disposal.

Packaging, worn out power tools and accessories should
be sorted for environmental-friendly recycling.
Dispose of batteries only when discharged.
For batteries that are not completely discharged, insulate
the terminals with tape as a protective measure against
short-circuiting.
When working metal under extreme operat-
ing conditions, it is possible for conductive
dust to settle in the interior of the power tool.
