Lexicon M300L Owner's Manual page 99

300L Owner's Manual
Compressor
Parameters
THR
0 to -40DB 1.0-99.99:1
EXT
0 to -70DB 1.0-99.99:1
L
Predelay
R
THR (Threshold)
SLP (Slope)
ATC (Attack Time
Constant)
RTC (Release
Time Constant)
DLY (Look Ahead Delay)
4-36
SLP GAIN
0 to +24DB
EXS EXG
0 to -24DB
Compressor
SLP THR
ATC RTC
Compressor Page One
THR sets the level at which compression starts.
SLP controls the slope of the gain reduction curve or the ratio of input level versus
output level.
GAIN
GAIN adjusts the gain of low level signals (below the compression threshold).
ATC adjusts the attack time constant.
RTC allows adjustment of the release time constant.
DLY sets the predelay of the audio before the digital VCA.
PAGE ONE
ATC
7-960MS
PAGE TWO
Compressor Gain
Expander
EXS
RTC DLY
16-4000MS 0-48MS
Expander Gain
EXT
