The 300L can receive MIDI information on three independent channels: one for
Sysex, Dump messages, and Fixed and MAP Program Change requests for
Setups, and two channels for Dynamic MIDI MOD patches within each Machine
(A and B), as well as Programs and Registers. MIDI Channel assignments are
made in Control Mode. To select this function, press CTRL, then press PAGE
and press 5, to display the MIDI Automation, Dump, Dump Delay, and Channel
sliders.
AUTO DMP
Sliders 4,5,and 6 set MIDI channels for the System, Machine A and Machine B,
respectively.
MIDI Out
MIDI In
AES/EBU EIAJ CP340
DO DI R OUT L OUT R IN
PUSH PUSH
DO DI
DI
DO
MIDI
OUT THRU IN
DLY CHL
MIDI Out
MIDI In
L IN
PUSH
INPUT
GAIN
CHL CHL
MIDI Operation
300L with sequencer/computer
and keyboard

Setting MIDI Channels

7-3
