AF-W18CME
ROOM AIR CONDITIONER
INSTALLATION AND OPERATION
MANUAL
CONTENTS
• PRECAUTIONS ........................................ 2
• CONTROLS .............................................. 4
• BASIC OPERATION ................................. 6
• TIMER OPERATION................................. 8
• SAVE OPERATION .................................. 10
• ONE-HOUR OFF TIMER .......................... 10
• AUXILIARY MODE ................................... 11
• MAINTENANCE ........................................ 12
• LOCATION................................................ 15
• POWER CABLING.................................... 15
• INSTALLATION ........................................ 16
Thank you for purchasing a SHARP air conditioner.
Please read this manual carefully before installing or
operating the product.
The manual should be kept in a safe place for handy
reference.
PAGE

Advertisement

Table of Contents
loading

Summary of Contents for Sharp AF-W18CME

  • Page 1: Table Of Contents

    • LOCATION..........15 • POWER CABLING........15 • INSTALLATION ........16 Thank you for purchasing a SHARP air conditioner. Please read this manual carefully before installing or operating the product. The manual should be kept in a safe place for handy reference.
  • Page 2: Operation Instructions

    OPERATION INSTRUCTIONS PRECAUTIONS WARNINGS FOR USE Do not pull or deform the power supply cord. Pulling and misuse of the power supply cord can result in damage to the unit and cause electrical shock. Be careful not to expose your body directly to the outlet air for a long time. It may affect your physical conditions.
  • Page 3: Additional Notes On Operation

    PRECAUTIONS Be sure to stop the operation and turn the circuit breaker off before performing any maintenance or cleaning. A fan is rotating inside the unit and you may get injured. Do not splash or pour water directly on the unit. Water can cause electrical shock or equipment damage.
  • Page 4: Controls

    CONTROLS UNIT Control panel Reciever Window Operation Lamp (Red) Ventilation lever Timer Lamp (Yellow) AUX. Button REMOTE CONTROL TRANSMITTER DISPLAY (Liquid Crystal Display) ON/OFF Button THERMO. (Thermostat) Button SAVE Button MODE Button TIMER TIMER ON Button (for setting the timer) ONE-HOUR OFF TIMER Button TIMER OFF Button (for setting the timer) FAN Button...
  • Page 5: Using The Remote Control

    USING THE REMOTE CONTROL INSTALLING BATTERIES Use two size-AAA (R03) batteries. Remove the battery cover at the back of the remote control. Insert batteries in the compart- Battery cover ment, making sure the polarities are correctly aligned. • Lines will be indicated on the display when batteries are MODE TEMP.
  • Page 6: Basic Operation

    BASIC OPERATION Press the MODE button to select the opera- tion mode. AUTO COOL Press the ON/OFF button to start operation. MODE TEMP. • The red OPERATION lamp on the unit will light Press the THERMO. button to set the de- TIMER sired temperature.
  • Page 7: Air Flow And Ventilation

    AIR FLOW AND VENTILATION LEFT/RIGHT AIR FLOW ADJUSTMENT Adjust the louvers to change the direction of air Left/Right air flow adjustment louvers (Automatic) flow. Press the SWING button on the remote control, and the Left/Right air flow adjustment louvers will swing continuously. Press the button again to stop.
  • Page 8: Timer Operation

    TIMER OPERATION TIMER OFF The unit will turn off automatically according to your setting. Timer duration can be set from minimum 0.5 hours (30 minutes) to maximum 12 hours. Up to 9.5 hours, you can set by 0.5 hours (30 minutes) increments and from 10 to 12 hours, by 1 hour increment.
  • Page 9 TIMER ON The unit will turn on automatically according to your setting. Timer duration can be set from minimum 0.5 hours (30 minutes) to maximum 12 hours. Up to 9.5 hours, you can set by 0.5 hours (30 minutes) increments and from 10 to 12 hours, by 1 hour increment.
  • Page 10: Save Operation

    SAVE OPERATION With the SAVE operation, the temperature setting rises 1°C higher than the origi- nal thermostat setting. It offers you efficient and economical operation when used during seasons and hours with low outdoor temperature, such as night time. Press the SAVE button during operation. •...
  • Page 11: Auxiliary Mode

    AUXILIARY MODE Use this mode when the remote control is not available. TO TURN ON Press the AUX. button on the unit's control panel. • The red OPERATION lamp on the unit will light up and the unit will start operating in the AUTO mode.
  • Page 12: Maintenance

    MAINTENANCE Be sure to disconnect the power cord from the wall outlet or turn off the circuit breaker before performing any maintenance. CLEANING THE FILTER If the filter is clogged with dust, the amount of air flow will be reduced, resulting in poor cooling performance.
  • Page 13: Before Calling For Service

    BEFORE CALLING FOR SERVlCE IF YOUR AIR CONDITIONER DOES NOT OPERATE PROPERLY, PLEASE CHECK THE FOLLOWING ITEMS BEFORE CALLING FOR SERVICE. AIR CONDITIONER DOES NOT OPERATE AT ALL • Is the power cord loosened or disconnected? • Is the fuse blown or has the circuit breaker been tripped? •...
  • Page 14: Installation Instructions

    INSTALLATION INSTRUCTIONS PART NAMES AND DIMENSIONS Front panel Grille Air filter (behind the grille) Up/Down air flow adjustment louvers Left/Right air flow adjustment louvers Cabinet Ventilation lever Control panel Stopper screws (on left and right side) Power cord Remote control DIMENSIONS A (mm) B (mm)
  • Page 15: Location

    Maximum Permissible of the unit to a properly rated independent circuit with a System Impedance time delay fuse or a circuit breaker. See chart for proper 0.13 ( AF-W18CME) amp ratings for each model. AF-W18CME 20 amp. Downloaded from: http://www.usersmanualguide.com/...
  • Page 16: Installation

    INSTALLATION Fig. INSTALLATION WARNING : Turn off and disconnect the unit before working. Grille (1) Remove the grille by sliding it to the left until it stops and then pull it towards you.(fig.1) Fig.1 Air filter Next lift and unhook the bottom of the air filter and remove it.
  • Page 17 Compressor Remove the 3 fixing nuts and the fixing Wrench angles from the compressor.(Fig.5) T h e s e a r e f o r t h e p u r p o s e o f Fixing nut transportation only. Keep them in a Fixing angle handy place in case of re-location.
  • Page 18 INSTALLATION WARNING: cabinet At this step, make sure the cabinet is inclined approximately 1cm (3/8") to the back (Fig.10). If the cabinet is not properly inclined, mounting the water collected in the bottom tray frame during operation will not drain properly incline backwards about 1cm and may flow into the room where the (3/8")
  • Page 19 Downloaded from: http://www.usersmanualguide.com/...
  • Page 20 SHARP CORPORATION Printed in Egypt TINS-A779JBRZ 04B- 1 Downloaded from: http://www.usersmanualguide.com/...
