This INSTALLATION AND OPERATION
MANUAL explains the proper use of your new
Sharp Air Conditioner. Read these instructions
carefully before installing or operating your air
conditioner. The INSTALLATION AND OP-
ERATION MANUAL should be kept in a safe
place for handy reference.
AF-R100CX
AF-R120CX
AF-R140CX
ROOM AIR CONDITIONER
INSTALLATION AND OPERATION
MANUAL
CONTENTS
FOR YOUR PROTECTION ....................
• CHECK WINDOW AREA ........................ 4
• LOCATlON .............................................. 4
• ITEMS PACKED WITH THlS UNIT ......... 5
• SUGGESTED TOOLS ............................ 5
• INSTALLATION ....................................... 5
• CAUTION FOR USE ............................ 8
• GROUNDING INSTRUCTIONS ........... 8
• NOTES ON OPERATION .................... 9
• ENERGY EFFICIENCY TIPS ............... 9
HOW TO OPERATE
• PARTS NAMES ................................... 10
• COOLING OPERATION ...................... 11
• TO CHANGE TEMPERATURE SETTING .......... 11
• TO CHANGE FAN SPEED .................. 12
• FAN ONLY OPERATION ..................... 12
• ENERGY SAVER ................................. 13
• TO CHANGE AIR FLOW DIRECTION ....... 13
• EXHAUST ............................................ 13
• ON TIMER OPERATION ..................... 14
• OFF TIMER OPERATION .................... 15
• USING THE REMOTE CONTROL ....... 16
CLEANING AND MAINTENANCE ........ 18
BEFORE CALLING FOR SERVlCE ...... 19
PAGE
2
3
Advertisement
Table of Contents
Related Manuals for Sharp AF-R100CX
Summary of Contents for Sharp AF-R100CX
-
Page 1: Table Of Contents
This INSTALLATION AND OPERATION MANUAL explains the proper use of your new Sharp Air Conditioner. Read these instructions carefully before installing or operating your air conditioner. The INSTALLATION AND OP- ERATION MANUAL should be kept in a safe place for handy reference. -
Page 2: For Your Protection
Address City State Telephone TO PHONE: Dial 1-800-BE-SHARP (237-4277) for: SERVICE (for your nearest Sharp Authorized Servicer) PARTS (for your Authorized Parts Distributor) ACCESSORIES ADDITIONAL CUSTOMER INFORMATION TO WRITE: For service problems, warranty information, missing items and other assistance: Sharp Electronics Corporation... -
Page 3: Consumer Limited Warranty
Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. -
Page 4: Installation Instructions
For safe installation, repairs, replacement and secure positioning, make sure foundation is solid and level. The room air conditioner must be installed in an area within reach of a properly rated grounded outlet. Use of extension cords of any kind is not recommended. -
Page 5: Items Packed With Thls Unit
These models can also be installed through the wall with the optional through the wall mounting kit, model AZ-80WK. To order this kit either contact your dealer or call 1-800-BE-SHARP. The wall opening dimensions for through the wall installation are: 25"... - Page 6 1 cm (3/8”) to the back. If the cabinet is not properly inclined, the water collected in the bottom tray during operation will not drain properly and may flow into the room where the air conditioner is installed. Front panel Front panel...
- Page 7 Insert the closure assemblies on both sides into the rails of the jamb. Closure assembly (Left) Sill Stool Secure the cabinet to the window stool with 3 screws (L=1", 25.4 mm), working from the inside of the cabinet. Secure the top angle and the closure assemblies to the window sash with 3 screws (L=1", 25.4 mm).
-
Page 8: Precautions
CAUTION FOR USE IMPORTANT: Points to keep in mind when using your air conditioner. • Install the air conditioner by following the installation instructions given in the previous section of this manua • Make sure the unit is the correct capacity for the area you want to cool. -
Page 9: Notes On Operation
• If a power failure occurs during use, allow 3 minutes before restarting the unit. After power is reinstated, restart the air conditioner. If the power was off for less than three minutes, be sure to wait at least three minutes before restarting the unit. If you restart the air conditioner within three minutes, a protective device in the unit may cause the compressor to shut off. -
Page 10: Parts Names
OPERATION INSTRUCTIONS PARTS NAMES UNIT Front panel Air inlet (Indoor side) Louvers Air outlet (Indoor side) Exhaust lever Control panel CONTROL PANEL SELECTOR indicator Receiver window for remote control signal Display SELECTOR pad TIMER ON/OFF pad TIMER indicator Cabinet Air outlet (Outdoor side) Air inlet (Outdoor side) Filter (Pull the filter handle to the right to remove.) Filter handle... -
Page 11: Cooling Operation
HOW TO OPERATE COOLING OPERATION Procedure Touch POWER ON/OFF pad. • The unit is preset at 74°F and HIGH COOL. This will show in the display when the power is first turned on. To turn off the unit, touch POWER ON/OFF pad again TO CHANGE TEMPERATURE SETTING Procedure During cooling operation... -
Page 12: To Change Fan Speed
FAN ONLY. When the unit is turned off, the last fan speed will be stored in memory. The next time the air conditioner is used, the memorized fan speed will start automatically. Display / Indicator • SELECTOR indicator will light in order as you touch. -
Page 13: Energy Saver
ENERGY SAVER During normal operation, the thermostat automatically controls cooling and the fan runs continuously. When the ENERGY SAVER is selected, the thermostat automatically controls cooling and the fan automatically stops when the compressor is not operating. (Fan will stop 30 seconds after the compressor stops. rotate for 2 minutes, every maximum 20 minutes, to detect room temperature. -
Page 14: On Timer Operation
HOW TO OPERATE ON TIMER OPERATION This unit has a built-in timer that can be programmed to start the unit up to 12 hours in • advance. You can set the timer to start in increments of 30 minutes (0.5 hours) up to 9.5 hours in •... -
Page 15: Off Timer Operation
OFF TIMER OPERATION This unit has a built-in timer that can be programmed to shut the unit off up to 12 hours • in advance. You can set the timer to stop in increments of 30 minutes (0.5 hours) up to 9.5 hours in •... -
Page 16: Using The Remote Control
HOW TO OPERATE USING THE REMOTE CONTROL INSTALLING BATTERIES Use two size-AAA (R03) batteries. Remove the battery compartment cover. Insert the batteries in the compartment, making sure the are properly aligned. Replace the cover. NOTES: • The battery life is approximately one year with normal use. •... - Page 17 OPERATING WITH THE REMOTE CONTROL POWER ON/OFF TEMP. TEMP. SELECTOR SET TIMER/OFF NOTE: • The "ON" TIMER cannot be set with the remote control. It can only be activated by the TIMER ON/OFF pad on the unit's control panel ( See page 14 ). To Change the Temperature Setting When the ON / OFF Timer Is In Use Push a TEMPERATURE setting button.
-
Page 18: Cleaning And Maintenance
CLEANING AND MAINTENANCE ENERGY EFFICIENCY TIPS CLEANING THE FILTER If the filter is clogged with dust, the amount of air flow will be reduced, resulting in poor cooling performance. The filter should be cleaned every10 days. At the beginning of every cooling season or after a long period of inactivity, clean the filter before starting the unit. -
Page 19: Before Calling For Servlce
• Did you restart the unit within 3 minutes after a power failure? If the power was off for less than 3 minutes, and you restarted the air conditioner within 3 minutes, a protective device may cause the compressor to shut off, preventing cooling for about 5 minutes. - Page 20 SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07430-2135 SHARP CORPORATION Osaka, Japan Printed in Thailand TINSEA297JBRZ 01LO...
