ROOM AIR CONDITIONER
INSTALLATION AND OPERATION
MANUAL
This INSTALLATION AND OPERATION
MANUAL explains the proper use of your new
Sharp Air Conditioner. Read these instructions
carefully before installing or operating your air
conditioner. The INSTALLATION AND OP-
ERATION MANUAL should be kept in a safe
place for handy reference.
As an ENERGY STAR Partner, Sharp Electronics has determined that these products (AF-S100EX, AF-
S120EX, AF-S125EX) meet the ENERGY STAR guidelines for energy efficient air conditioners. To meet
these guidelines, air conditioners must be at least 10% more efficient than the minimum Federal standard.
AF-S100EX
AF-S120EX
AF-S125EX
AF-R100EX
AF-R120EX
CONTENTS
FOR YOUR PROTECTION ....................
• CHECK WINDOW AREA ........................ 4
• LOCATlON .............................................. 4
• ITEMS PACKED WITH THlS UNIT ......... 5
• SUGGESTED TOOLS ............................ 5
• INSTALLATION ....................................... 5
• CAUTION FOR USE ............................ 8
• GROUNDING INSTRUCTIONS ........... 8
• NOTES ON OPERATION .................... 9
• ENERGY EFFICIENCY TIPS ............... 9
• PARTS NAMES ................................... 10
• COOLING OPERATION ...................... 11
• TO CHANGE TEMPERATURE SETTING .......... 12
• TO CHANGE AIR FLOW DIRECTION ....... 12
• EXHAUST ............................................ 12
• ENERGY SAVER OPERATION ........... 13
• SLEEP OPERATION ........................... 13
• ON TIMER OPERATION ..................... 14
• OFF TIMER OPERATION .................... 15
• USING THE REMOTE CONTROL ....... 16
CLEANING AND MAINTENANCE ........ 18
BEFORE CALLING FOR SERVlCE ...... 19
PAGE
2
3
Advertisement
Table of Contents
Related Manuals for Sharp AF-R100EX
Summary of Contents for Sharp AF-R100EX
-
Page 1: Table Of Contents
ERATION MANUAL should be kept in a safe place for handy reference. As an ENERGY STAR Partner, Sharp Electronics has determined that these products (AF-S100EX, AF- S120EX, AF-S125EX) meet the ENERGY STAR guidelines for energy efficient air conditioners. To meet these guidelines, air conditioners must be at least 10% more efficient than the minimum Federal standard. -
Page 2: For Your Protection
Address City State Telephone TO PHONE: Dial 1-800-BE-SHARP (237-4277) for: SERVICE (for your nearest Sharp Authorized Servicer) PARTS (for your Authorized Parts Distributor) ACCESSORIES ADDITIONAL CUSTOMER INFORMATION TO WRITE: For service problems, warranty information, missing items and other assistance: Sharp Electronics Corporation... -
Page 3: Consumer Limited Warranty
Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or property damage. -
Page 4: Installation Instructions
For safe installation, repairs, replacement and secure positioning, make sure the the foundation is solid and level. The room air conditioner must be installed in an area within reach of a properly rated grounded outlet. Use of extension cords of any kind is not recommended. -
Page 5: Items Packed With Thls Unit
ITEMS PACKED WITH THIS UNIT Accessories Right closure assembly Left closure assembly Window sash foam seal Window sash foam seal (adhesive type) Top angle Screws(L=1", 25.4mm) Screws(L= ", 6mm) Remote control Battery SUGGESTED TOOLS 1. Screw driver (medium size Phillips) 2. - Page 6 INSTALLATION INSTRUCTIONS Unscrew the 5 stopper screws of the cabinet. Keep the 3 screws from the front and side, as they will be used later. Slide the chassis out from the cabinet by pulling on the hand hold located at the bottom both sides of the chassis.
- Page 7 Insert the closure assemblies on both sides into the rails of the jamb. Closure assembly (Left) Sill Stool Secure the cabinet to the window stool with 2 screws (L=1", 25.4mm), working from the inside of the cabinet. Secure the top angle and the closure assemblies to the window sash with 3 screws (L=1", 25.4mm).
-
Page 8: Precautions
CAUTION FOR USE IMPORTANT: Points to keep in mind when using your air conditioner. • Install the air conditioner by following the installation instructions given in the previous section of this manua • Make sure the unit is the correct capacity for the area you want to cool. -
Page 9: Notes On Operation
• If a power failure occurs during use, allow 3 minutes before restarting the unit. After power is reinstated, restart the air conditioner. If the power was off for less than three minutes, be sure to wait at least three minutes before restarting the unit. If you restart the air conditioner within three minutes, a protective device in the unit may cause the compressor to shut off. -
Page 10: How To Operate
HOW TO OPERATE PARTS NAMES UNIT Front panel Air inlet (Indoor side) Vertical louvers Horizontal louvers Air outlet (Indoor side) Exhaust lever Control panel CONTROL PANEL Receiver window for remote control signal Display SLEEP indicator SELECTOR pad COOL indicator TEMPERATURE setting pad Lower temp. -
Page 11: To Change Fan Speed And Operation Mode
COOLING OPERATION COOL indicator POWER indicator SLEEP COOL TEMP SELECTOR TIMER ON/OFF POWER ON/OFF pad TO CHANGE FAN SPEED AND OPERATION MODE COOL indicator SLEEP COOL TEMP SELECTOR TIMER ON/OFF SELECTOR pad NOTES ON OPERATION MODE: MODE COOL indicator HIGH COOL light on MED COOL light on... -
Page 12: To Change Temperature Setting
HOW TO OPERATE TO CHANGE TEMPERATURE SETTING SLEEP COOL TEMP SELECTOR TIMER ON/OFF TEMPERATURE setting pad NOTES: • In fan only (HIGH FAN, MED FAN, LOW FAN) operation, the temperature display will go off and the temperature setting cannot be changed. •... -
Page 13: Energy Saver Operation
ENERGY SAVER OPERATION During normal operation, the thermostat automatically controls cooling and the fan runs continu- ously. When the ENERGY SAVER OPERATION is selected, the thermostat automatically controls cooling and the fan automatically stops when the compressor is not operating. (Fan will stop 30 seconds after the compressor stops. -
Page 14: On Timer Operation
HOW TO OPERATE ON TIMER OPERATION • This unit has a built-in timer that can be programmed to start the unit up to 12 hours in advance. You can set the timer to start in increments of 30 minutes (0.5 hours) up to 9.5 hours in advance of the start time, or in 1 hour increments from 10 to 12 hours in advance of the start time. -
Page 15: Off Timer Operation
OFF TIMER OPERATION • This unit has a built-in timer that can be programmed to shut the unit off up to 12 hours in advance. You can set the timer to stop in increments of 30 minutes (0.5 hours) up to 9.5 hours in advance of the stop time, or in 1 hour increments from 10 to 12 hours in advance of the stop time. -
Page 16: Using The Remote Control
HOW TO OPERATE USING THE REMOTE CONTROL INSTALLING BATTERIES Use two size-AA (R6) batteries. Open the battery compartment cover. Insert and slide the batteries into the compartment, making sure polarities are properly aligned. Close the cover. NOTES: • The battery life is approximately one year with normal use. •... -
Page 17: Sleep Button
TEMP. SELECTOR OFF TIMER SLEEP AIR CONDITIONER Light absorbing material is used for the Power ON/OFF and TEMP buttons. Keep the remote control in a lighted place for several hours in order for the buttons to absorb light. The buttons will glow for approximately two hours and the duration may differ depending on various conditions. -
Page 18: Cleaning And Maintenance
REMOVING THE AIR CONDITIONER Before removing the air conditioner, operate the unit in the HIGH FAN mode on the fine day, for about half a day to thoroughly dry the water inside the air conditioner unit. -
Page 19: Before Calling For Servlce
• Did you restart the unit within 3 minutes after a power failure? If the power was off for less than 3 minutes, and you restarted the air conditioner within 3 minutes, a protective device may cause the compressor to shut off, preventing cooling for about 5 minutes. - Page 20 SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, New Jersey 07430-2135 SHARP CORPORATION Osaka, Japan Printed in Thailand TINSEA362JBRZ 03MO TH 1...
