SPECIFICATIONS ................................................................................................................................................ 2
WIRING DIAGRAM ............................................................................................................................................... 3
EXTERNAL DIMENSIONS ................................................................................................................................... 4
OPERATION INSTRUCTIONS ............................................................................................................................ 4
INSTALLATION INSTRUCTIONS ........................................................................................................................ 7
DISASSEMBLING PROCEDURE ...................................................................................................................... 10
HOW TO REPAIR REFRIGERATION ................................................................................................................ 14
ELECTRICAL COMPONENT TEST .................................................................................................................... 16
MICROCOMPUTER CONTROL SYSTEM .......................................................................................................... 17
TROUBLESHOOTING GUIDE ............................................................................................................................ 24
RUNNING CONDITION ...................................................................................................................................... 28
PACKING AND ACCESSORIES ......................................................................................................................... 29
REPLACEMENT PARTS LIST ............................................................................................................................ 30
SHARP CORPORATION
SERVICE MANUAL
MODELS
In the interest of user-safety the air conditioner should be restored to
its original condition and only parts identical to those specified should
be used.
TABLE OF CONTENTS
This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
1
AIR CONDITIONER
AF-T908X
AF-R908X
AF-R1108X
AF-R1208X
AF-T908X
AF-R908X
AF-R1108X
AF-R1208X
S6830AFR128X/
Page
Advertisement
Table of Contents
Related Manuals for Sharp AF-T908X
Summary of Contents for Sharp AF-T908X
-
Page 1: Table Of Contents
AF-T908X AF-R908X AF-R1108X AF-R1208X SERVICE MANUAL S6830AFR128X/ AIR CONDITIONER AF-T908X MODELS AF-R908X AF-R1108X AF-R1208X In the interest of user-safety the air conditioner should be restored to its original condition and only parts identical to those specified should be used. TABLE OF CONTENTS Page SPECIFICATIONS .............................. -
Page 2: Specifications
AF-T908X AF-R908X AF-R1108X AF-R1208X SPECIFICATIONS Models AF-T908X, AF-R908X AF-R1108X AF-R1208X Cooling capacity BTU/h 8500 10500 12000 Moisture removal Pints/h ELECTRICAL DATA Phase Single Rated frequency Rated voltage Volts Rated current Amps 10.2 11.9 Rated input Watts 1100 1300 Power factor BTU/Wh 10.0... -
Page 3: Wiring Diagram
AF-T908X AF-R908X AF-R1108X AF-R1208X ELECTRICAL PARTS Models AF-T908X,AF-R908X AF-R1108X AF-R1208X Running capacitor 370V-35µF 370V-40µF 370V-60µF Fan capacitor(indoor/outdoor) 250V-3µF/250V-6µF 250V-6µF/250V-6µF 250V-6µF/250V-6µF Thermistor 15kΩ at 78˚F Fan motor RMLA046/RMLA045 RMLA044/RMLA043 RMLA044/RMLA043 Overload relay MRA12061-9201 MRA98965-9200 MRA12053-9200 WIRING DIAGRAM WIRE COLOR THERMISTOR POWER SUPPLY CORD (ROOM TEMP.) -
Page 4: External Dimensions
AF-T908X AF-R908X AF-R1108X AF-R1208X EXTERNAL DIMENSIONS 22-1/16" 38-19/32" 24-5/16" 27-5/32" 5-3/16" OPERATION INSTRUCTIONS PARTS NAMES UNIT 1 Front panel 2 Air inlet (Indoor side) 3 Louvers 4 Air outlet (Indoor side) 5 Exhaust lever 6 Control panel 7 Cabinet 8 Air outlet (Outdoor side) 9 Air inlet (Outdoor side) 0 Filter (Pull the filter handle to the right to remove.) - Page 5 AF-T908X AF-R908X AF-R1108X AF-R1208X CONTROL PANEL Display 2 SELECTOR indicator HIGH COOL 3 SELECTOR pad MED COOL LOW COOL 4 POWER indicator FAN ONLY 5 POWER ON/OFF pad SELECTOR 6 TEMPERATURE and TIMER setting pad " " " " ••••Temp. lower or time reverse "...
- Page 6 AF-T908X AF-R908X AF-R1108X AF-R1208X TO CHANGE FAN SPEED PROCEDURE DISPLAY / INDICATOR • SELECTOR indicator will light in order During operation as you touch. SELECTOR Touch SELECTOR pad and select the desired fan HIGH COOL speed. MED COOL LOW COOL...
-
Page 7: Installation Instructions
NOTE: These models can also be installed through the wall with the optional through the wall mounting kit, model AZ-80WK. To order this kit either contact your dealer or call 1-800-BE-SHARP. The wall opening dimensions for through the wall installation are: 25" (635mm) (W) x 17 1/4 " (438mm) to 17 3/4" (451mm) (H) x 4" (102mm) minimum (D). -
Page 8: Front Panel
AF-T908X AF-R908X AF-R1108X AF-R1208X 2. Open the box of the front panel assembly and take out the front panel and 2 screws. Screws Front panel 3-1. Unscrew the 6 stopper screws of the cabinet. Keep the 4 screws from the top and front , as they will be used later. -
Page 9: Louvers
AF-T908X AF-R908X AF-R1108X AF-R1208X 7-1. Secure the cabinet to the window stool with 3 screws (L=1", 25.4 mm), working from the inside of the cabinet. Top angle INSTALLATION INSTRUCTIONS 7-2. Secure the top angle and the closure assemblies to the window sash with 3 screws (L=1", 25.4 mm). -
Page 10: Disassembling Procedure
AF-T908X AF-R908X AF-R1108X AF-R1208X DISASSEMBLING PROCEDURE CAUTION: DISCONNECT THE ROOM AIR CONDITIONER FROM THE POWER SUPPLY BEFORE ANY SERVICE 1. Unscrew the two screws holding the front panel on each 5. Unscrew the four screws holding the control unit. side. - Page 11 AF-T908X AF-R908X AF-R1108X AF-R1208X 9. Cut the tfixing band holding the wires. 13.Remove the putty and unfasten the one nut at the top of compressor holding the terminal cover. Then remove the wiring connector of the compressor cord. 10.Remove the control unit.
- Page 12 AF-T908X AF-R908X AF-R1108X AF-R1208X 17.Remove the condenser by liftting up about 1 inch and 21.Unscrew the four screws holding the fan motor. pull it toward you and move to right. Note: Torque is 7 - 10 kgf.cm at re-installing. 18.Unfasten the one nut holding propeller fan by rotating it clockwise.
- Page 13 AF-T908X AF-R908X AF-R1108X AF-R1208X 25.Unscrew the two screws holding the orifice 29.Unscrew the three screws holding the printed wiring board. 26.Unfasten the one nut holding the centrifugal fan by 30.Detach terminals by using long-nose pliers. rotating it counterclockwise. 27.Unscrew the one screw holding the fan motor lead wire.
-
Page 14: How To Repair Refrigeration
AF-T908X AF-R908X AF-R1108X AF-R1208X HOW TO REPAIR REFRIGERATION Before sealed system work can be preformed a refrigerant recovery EPA and LOCALLY approved certification is required, additionally, EPA and LOCALLY approved refrigerant recovery equipment is required. SEALED SYSTEM REPAIR Sealed system repairs should be properly diagnosed before entering into a repair of the system. - Page 15 Directing Torch Flame to Copper Tubing. AF-T908X AF-R908X Figure 3 AF-R1108X AF-R1208X HEATING THE TUBING Direct the torch flame so that the larger tube receives most of the heat. Silver solder flows at 1200˚F and silfos flows at 1300˚F. Heat all around the tubing.
-
Page 16: Electrical Component Test
AF-T908X AF-R908X AF-R1108X AF-R1208X A very faint green indicates a small leak. The flame will be unmistakably changed to green or purple when large leaks are encountered. To simplify leak detection pressurize the system to approximately 75 lbs. Some leaks can be located by a visual inspection of the system components and solder joints and if oil is found at any given location it generally is a sign that a leak exists at that point due to the fact that flame does carry oil with it travels through the system. -
Page 17: Microcomputer Control System
AF-T908X AF-R908X AF-R1108X AF-R1208X MICROCOMPUTER CONTROL SYSTEM... - Page 18 AF-T908X AF-R908X AF-R1108X AF-R1208X...
- Page 19 AF-T908X AF-R908X AF-R1108X AF-R1208X Q9 E COM IC3 JP19 JP18 JP15 JP16 125V 4A Printed Wiring Board for AF-T908X Q9 E COM IC3 JP19 JP18 JP15 JP16 125V 4A Printed Wiring Board for AF-R908X and AF-R1108X and AF-R1208X...
- Page 20 AF-T908X AF-R908X AF-R1108X AF-R1208X MICROCOMPUTER CONTROL SYSTEM 1. Temperature control characteristic 3. Fan speed Fan speeds are given by the fan motor, “H”, “M” and “L”, which are available in the following operation 1-1 COOL operation In the “COOL” mode, the thermostat circuit is controlled mode.
- Page 21 AF-T908X AF-R908X AF-R1108X AF-R1208X 6. Safety start When you turn the air conditioner OFF and restart again soon, wait at least 3 minutes before the cooling operation starts. 7. Test mode Keep pushing both buttons “POWER ON/OFF” and “ " ” and supply the power, the system will go to the test mode.
- Page 22 AF-T908X AF-R908X AF-R1108X AF-R1208X INSTRUCTIONS FOR USING COOLING LOAD ESTIMATE FROM FOR ROOM AIR CONDITIONERS (AHAM PUB. NO. RAC-1) A. This cooling load estimate form is suitable for estimating the cooling load for comfort air conditioning installations which do not require specific conditions of inside temperature and humidity.
- Page 23 AF-T908X AF-R908X AF-R1108X AF-R1208X COOLING LOAD ESTIMATE FORM BTU/Hr FACTORS (Quantity HEAT GAIN FROM QUANTITY x Factor) Inside Outside (Area a Shades Shades Shades Factor) 1. WINDOWS: Heat gain from sun. sq ft Northeast only sq ft Southeast sq ft...
-
Page 24: Troubleshooting Guide
AF-T908X AF-R908X AF-R1108X AF-R1208X TROUBLESHOOTING GUIDE TROUBLESHOOTING GUIDE Symptom Check Defect Remedy 1) Fuse open or circuit breaker Neither fan motor 1) Check power supply 1) If fuse or breaker are open nor compressor switch or plug and normal, ask the power... - Page 25 AF-T908X AF-R908X AF-R1108X AF-R1208X Symptom Check Defect Remedy Fan motor runs 1) Change overload relay 1) No current runs. 1) Overload relay defective but compressor (Compressor doesn't operate circuit) 2) Change compressor 2) Compressor coil burnt out 3) Wiring disconnected or burnt out...
- Page 26 AF-T908X AF-R908X AF-R1108X AF-R1208X Symptom Check Defect Remedy 1) Connector open CN1 Fan motor doesn't 1) Check PWB 1) Joint of connector CN1 operate with connector CN1 "Selector switch" set at "Fan only" 2) Crack at solder part of CN1...
- Page 27 AF-T908X AF-R908X AF-R1108X AF-R1208X Symptom Check Defect Remedy 1) Connector open CN1 Compressor operates 1) Check PWB 1) Joint of connector CN1 in cooling but fan connector CN1 2) Crack at solder part of CN1 2) Over solder doesn't rotate...
-
Page 28: Running Condition
1000 3. Outlet air temp. is influenced by the method of measurement. Measurement examples are shown. 4. Use power input data when checking the Running Condition. RUNNING CONDITION FOR MODEL AF-T908X/AF-R908X PERFORMANCE CURVE 1100 1000 (96) (88) (77) (68) -
Page 29: Packing And Accessories
AF-T908X AF-R908X AF-R1108X AF-R1208X PACKING AND ACCESSORIES Panel case's window Accessory kit (To be uped the window side) Note: Place the Accessory Kit on with the Panel cases window facing upwards Top pad B Packing case Top pad F Closure ass'y... -
Page 30: Replacement Parts List
Condenser shroud [AF-R1108X] 1-15 PKESPA047JBT0 Condenser shroud [AF-R1208X] 1-16 PKESPA063JBFA Orifice 1-17 LBND-A046JBE0 Wire fixing band 1-18 PCOV-A454JBFA Con. shroud cover [AF-T908X] 1-18 PCOV-A454JBFA Con. shroud cover [AF-R908X] 1-18 PCOV-A454JBFA Con. shroud cover [AF-R1108X] 1-18 PCOV-A002JBFA Con. shroud cover [AF-R1208X] 1-19 PGUMMA180JBE0... - Page 31 PSEL-B520JBE0 Motor insulator 1-48 PSEL-B528JBE0 Base pan insulator 1-49 PSEL-B530JBE0 Bulkhead insulator 1-50 PFPFPB528JBE0 Insulator 1-51 PSEL-B533JBE0 Con. shroud insulator [AF-T908X] 1-51 PSEL-B533JBE0 Con. shroud insulator [AF-R908X] 1-51 PSEL-B533JBE0 Con. shroud insulator [AF-R1108X] 1-52 PFPFPB611JBE0 Insulator 1-53 PSEL-B553JBE0 Orifice insulator...
- Page 32 Evaporator [AF-T908X] 3-14 PEVA-A347JBE0 Evaporator [AF-R908X] 3-14 PEVA-A347JBE0 Evaporator [AF-R1108X] 3-14 PEVA-A356JBE0 Evaporator [AF-R1208X] 3-15 DCPY-A145JBK0 Capillary tube ass’y [AF-T908X] 3-15 DCPY-A145JBK0 Capillary tube ass’y [AF-R908X] 3-15 DCPY-A144JBK0 Capillary tube ass’y [AF-R1108X] 3-15 DCPY-A149JBK0 Capillary tube ass’y [AF-R1208X] 3-16 PPIPCD390JB10...
- Page 33 Packing case [AF-R908X] 5- 3 SPAKCI155YDE0 Packing case [AF-R1108X] 5- 3 SPAKCI160YDE0 Packing case [AF-R1208X] 5- 4 TLAB-B072JBR0 Bar code badge [AF-T908X] 5- 4 TLAB-B067JBR0 Bar code badge [AF-R908X] 5- 4 TLAB-B065JBR0 Bar code badge [AF-R1108X] 5- 4 TLAB-B070JBR0 Bar code badge [AF-R1208X]...
- Page 34 AF-T908X AF-R908X AF-R1108X AF-R1208X CABINET PARTS FOR AF-T908X/AF-R908X/AF-R1108X...
- Page 35 AF-T908X AF-R908X AF-R1108X AF-R1208X CABINET PARTS FOR AF-R1208X...
- Page 36 AF-T908X AF-R908X AF-R1108X AF-R1208X CYCLE PARTS FOR AF-T908X/AF-R908X/AF-R1108X 3-11 3-10 3-22 3-21 3-12 3-18 1-44 3-19 3-17 3-16 3-13 3-15 3-20 3-17 1-68 3-14 5-10...
- Page 37 AF-T908X AF-R908X AF-R1108X AF-R1208X CYCLE PARTS FOR AF-R1208X 3-11 3-10 3-22 3-12 3-21 1-44 3-18 6-10 3-19 3-13 3-16 3-24 3-15 3-17 3-20 6-10 3-23 3-14 1-68 5-10...
- Page 38 AF-T908X AF-R908X AF-R1108X AF-R1208X CONTROL BOX PARTS FOR AF-T908X 6-13 2-10 2-11 6-15 1-67 6-11 2-13 2-12...
- Page 39 AF-T908X AF-R908X AF-R1108X AF-R1208X CONTROL BOX PARTS FORÅ AF-R908X/AF-R1108X/AF-R1208X 6-13 2-10 2-11 6-15 1-67 6-11 2-13 2-12...
- Page 40 No part of this publication may be reproduced, stored in a retrieval systems, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher. ’98 SHARP CORP. (5U1.600E) Printed in JAPAN...
