- Page 1 ANI-010XUHD HDBitT 1x4 / 1x8 HDMI Extender Splitter Over CAT5/5e/6 ANI-0104UHD ANI-0108UHD RECEIVER A-NeuVideo.com Frisco, Texas 75036 AUDIO / VIDEO MANUFACTURER...
- Page 2 SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.
- Page 3 • Do not attach the power supply cabling to building surfaces. • Use only the supplied power supply unit (PSU). Do not use the The ANI-010XUHD series combine the extender and splitter PSU if it is damaged. functions to split (1) HDMI signal to (4) or (8) identical HDMI signals •...
- Page 4 NEUVIDEO FEATURES & SPECIFICATIONS FEATURES • Supports (1) HDMI Input to (4) or (8) HDbitT outputs • Up to ~394 ft/120M transmission distance over a single CAT6 cable (high quality cable can reach ~492 ft/150M) • Compatible with a receiver devices which support HDbitT transport protocol •...
- Page 5 NEUVIDEO Panel descriptions ANI-0104UHD FRONT PANEL SIGNAL LINK LED DATE TRANSMISSION INDICATOR CONNECTION INDICATOR BACK PANEL POWER INPUT (DC5V) RJ-45 OUTPUT RESET BUTTON IR BLASTER EXTENSION PORT HDMI INPUT ANI-0108UHD BACK PANEL POWER INDICATOR CONNECTION INDICATOR SIGNAL LINK LED RJ-45 OUTPUT HDMI INPUT IR BLASTER EXTENSION PORT RESET BUTTON...
- Page 6 NEUVIDEO Connection & operation Application Example network cable Follows the standards of IEEE-568B: 1- Orange/white 2- Orange 3- Green/white 4- Blue 5- Blue/white 6- Green 7- Brown/white 8- Brown Connection ANI-0104UHD...
- Page 7 NEUVIDEO Connection Connection ANI-0108UHD...
- Page 8 BY, THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
