- Page 1 ANI-11X2MFS UHD 4K2K@30Hz Multi-Format Video Presentation Scaler Switch w/ Audio A-NeuVideo.com Frisco, Texas 75036 AUDIO / VIDEO MANUFACTURER...
- Page 2 SAFETY INFORMATION To ensure the best results from this product, please read this manual and all other documentation before operating your equipment. Retain all documentation for future reference. Follow all instructions printed on unit chassis for proper operation. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid. Make sure power outlets conform to the power requirements listed on the back of the unit.
-
Page 3: Table Of Contents
IR remote control, RS-232 interface or Telnet. We assume no responsibility for any inaccuracies that may be The ANI-11x2MFS integrates easily into various analog to digital applications contained in this document. We make no commitment to update or such as, in collaboration environments, lecture halls, conference rooms, to keep current the information contained in this document. -
Page 4: Features
NEUVIDEO FEATURES FEATURES Main Unit • Switch & Scale (11) Inputs to (2) HD/UHD displays • (4) HDMI, (4) VGA, (1) YPbPr, (1) Composite, (1) HDBaseT Inputs ™ • (2) simultaneous outputs ((1) HDMI, (1) HDBaseT ™ • Selectable Bypass and Scaled formatted output •... -
Page 5: Specifications
NEUVIDEO SPECIFICATIONS Specifications Main Unit • Bandwidth: 10.2Gbps • Video Input Connectors: (4) HDMI Type A, (4) VGA, (1) RJ-45, (1) YPbPr, (1) AV • Video Output Connectors: (1) HDMI Type A, (1) RJ-45 • Audio Input Connectors: (11) 3.5mm stereo jack •... -
Page 6: Front Panel - Main Unit
NEUVIDEO FRONT PANEL - MAIN UNIT FRONT PANEL LCD DISPLAY: Shows the status of the input-output selection, EDID info and so on. IR RECEIVER WINDOW: Receives the IR from the remote control. DUAL SWITCHER LED INDICATOR: When the LED is lit, the dual switcher mode is active. When not lit, the splitter mode is active. ™... - Page 7 NEUVIDEO FRONT PANEL - MAIN UNIT FRONT PANEL MENU BUTTON: Press to enter EDID, volume setting or F/W information. (3) EDID segments will display on the LCD panel formatted as: INPUT VIDEO AUDIO. For Example: IN1 1080p 2.0CH, means to set 1080p 2.0CH EDID to INPUT1. The blinking segment is the one that can be changed currently;...
-
Page 8: Back Panel - Main Unit
NEUVIDEO BACK PANEL - MAIN UNIT BACK PANEL VGA INPUT 1 TO 4: VGA input 1 to 4 with L/R audio input. L/R IN 1 TO 4: Connects to the additional audio sources to embed on to HDMI Sources 1 thru 4. AV INPUT: AV input with L/R audio input. -
Page 9: Remote Control - Main Unit
NEUVIDEO Remote Control - MAIN UNIT Remote Control NEC CODE: 1898 POWER: 1898 14 MODE: 1898 0D BYPASS: 1898 41 MUTE: 1898 46 EMBED: 1898 15 VOLUME UP: 1898 08 VOLUME DOWN: 1898 4A HDMI 1 OUT HDBT: 1898 09 HDMI1: 1898 19 HDMI2:... -
Page 10: Transmitter & Receiver Description
NEUVIDEO TRANSMITTER & RECEIVER RECEIVER FRONT PANEL BACK PANEL r t y RS-232 connector. Not supported. Audio Output. Input Select Button. Not supported. HDMI Link indicator. HDBT Input. HDMI Output. Signal Link indicator. IR Receiver jack. DC 12V screw type connector. IR Transmitter jack. -
Page 11: Rs-232 & Telnet Commands
NEUVIDEO RS-232 & Telnet Commands RS-232 & Telnet Commands COMMAND ACTION Prints Help Information HELP Prints Help Information STATUS Prints System Status and Port Status Power On, System Run On Normal State POFF Power Off, System Run On Power Save State IR ON/OFF Sets System IR Control On or Off KEY ON/OFF... - Page 12 NEUVIDEO RS-232 & Telnet Commands RS-232 & Telnet Commands COMMAND ACTION AUD HDMI yy ANA HDMI Input:yy Embedded Analog L/R Signal yy=[01...04]: HDMI Input 01 ~ 04 AUD HDMI yy AUTO HDMI Input:yy Embedded Analog L/R When Input is a DVI signal Signal yy=[01...04]: HDMI Input 01 ~ 04 VOL xx Sets Scaler Audio Volume...
-
Page 13: Rs-232 Pin Assignment & Diagram
NEUVIDEO RS-232 Pin Assignment & DIAGRAM RS-232 Pin Assignment ANI-11X2MFS Remote Control Console Assignment Assignment Baud Rate: 57600bps Data Bit: 8bit Parity: None Stop Bit: 1bit Flow Control: None APPLICATION DIAGRAM - MAIN UNIT... -
Page 14: Tcp Module Instructions
NEUVIDEO TCP Module user instructions TCP Module user instructions • Enable the PC’s RJ-45 interface and disable the PC’s WIFI. • Connect the PC and Matrix with a CAT6 cable directly through the RJ-45 interface. • Set the PC net properties to: IP=192.168.0.200, Subnet Mask=255.255.255.0, Gateway=192.168.0.1. •... - Page 15 NEUVIDEO TCP Module user instructions TCP Module user instructions • Click the “Config” button to modify the Device Tag, IP mode and IP address of the TCP Module: When filled in, click the “OK” button: Device Tag = ”MATRIX#1”, Static IP IP Address = 10.120.1.120.
- Page 16 NEUVIDEO TCP Module user instructions TCP Module user instructions • Run the “TCP-IP module configuration-v1.0.exe” again. • Search the TCP control module. 1. Click the “Search” button to pop up the auto searching window: 2. Because the TCP control module is in the same subnet, it will be found after auto searching: NOTE: Default settings of the TCP module are: Static IP mode and the IP address is 192.168.0.100.
- Page 17 NEUVIDEO TCP Module user instructions TCP Module user instructions NOTE: 1. Same Subnet means the Matrix connects to a router which is the same as the PC it is connected to, example below: Router Subnet: 192.168.0.x Matrix IP: 192.168.0.200 IP: 192.168.0.100 2.
- Page 18 NEUVIDEO TCP Module user instructions TCP Module user instructions • Set the TCP control configuration. • Click the “Config” button to show the TCP configuration window. 1. Set tag to identify the Matrix device. 2. SET IP MODE: Subnet should support DHCP protocols when set to Auto IP mode, then the Matrix device will obtain the IP automatically. Otherwise, set Static IP mode and designate a usable IP for the Matrix device.
-
Page 19: Gui Software
NEUVIDEO GUI SOFTW ARE GUI SOFTW ARE... - Page 20 NEUVIDEO GUI SOFTW ARE GUI SOFTW ARE...
- Page 21 NEUVIDEO GUI SOFTW ARE GUI SOFTW ARE...
- Page 22 NEUVIDEO GUI SOFTW ARE GUI SOFTW ARE...
- Page 23 NEUVIDEO GUI SOFTW ARE GUI SOFTW ARE...
- Page 24 NEUVIDEO GUI SOFTW ARE GUI SOFTW ARE...
- Page 25 NEUVIDEO GUI SOFTW ARE GUI SOFTW ARE...
- Page 26 NEUVIDEO GUI SOFTW ARE GUI SOFTW ARE...
- Page 27 THIS PAGE IS INTENTIONALLY LEFT BLANK.
- Page 28 BY, THROUGH OR UNDER A-NeuVideo, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to A-NeuVideo, Inc. at the return address set forth on the Product’s packing label at your expense.
