SETUP GUIDE - LANTIME NTP SERVER
1. Lieferumfang überprüfen
(mit dem Packzettel vergleichen)
Check Package contents
(compare with the packing list)
Halterohr nur für GPS Antenne
10
Pole only for GPS antenna
4
5
1
2
!
A
Packzettel
Packing List
LANTIME Verpackungsinhalt
LANTIME Package Contents
1. Option: 5-pol. DFK Stecker
2. USB-Stick mit Software und Dokumentation
3. Optional: Stromkabel mit 5-pol. Stecker
8
Nur bei mitgelieferter Antenne
6
Only with delivered Antenna
A
4. Antenne
5. Optional: Kabel für Überspannungsschutz
7
6. Antennenkabel
7. CAB Konsolenkabel
8. Optional: Überspannungsschutz mit Haltewinkel
9
9. Halter für Antennenmast- oder Wandmontage
10. Halterohr für Antennenmontage (GPS Antenne)
3
4 x bei GPS Antenne,
2 x bei Langwellenantenne
4 x for GPS antenna
2 x for long wave antenna
(zusätzlicher Stecker bei DC Netzteil)
Option: 5-pin DFK connector
(additional connector in case of
DC power supply)
USB stick with software and documentation
Optional:
Power cable with 5-pin connector
Antenna
Optional: cable for surge voltage protector
Antenna cable
CAB console cable
Optional: surge voltage protector with bracket
Brackets for pole or wall mounting
Pole for antenna mounting (GPS Antenna)
1
B
Montagebausatz für GPS Antenne
(Wand- oder Mastmontage)
Mounting Kit for GPS Antenna
(wall or pole mounting)
4x
4x
8
2x
Montageteile für Masthalter oder Wandbefestigung
Mounting parts for pole- or wallmount
2x
C
Montagebausatz für Langwellenantenne
(Wandmontage)
Mounting Kit for Long Wave Antenna
(wall mounting)
2x
2x
8
4x
4x
Montageteile für Wandbefestigung
Mounting parts for wallmount
Hinweis:
Lesen Sie dazu die beigelegten Sicherheitshinweise
für den Einbau von elektronischen Geräten. Ein aus-
führliches Handbuch befindet sich auf dem mitgelie-
ferten USB Memory Stick.
Note:
Please read the safety instructions and the manual
carefully to familiarize yourself with the safe and proper
handling of electronic devices. The product documentation
can be found on the USB Flash Memory.
4x
4x
8x
8x
B
C
