KX224-I2C-EVK-001 is an evaluation board for KX224-1053, which is a ROHM Accelerometer. This User's Guide is about how to use KX224-I2C
-EVK-001 together with SensorShield*

Preparation

 Arduino Uno
 Personal Computer installed Arduino IDE
 Requirement : Arduino 1.6.7 or higher
 Please use Arduino IDE which can be
downloaded from the link below:
http://www.arduino.cc/
 USB cable for connecting Arduino and PC
 SensorShield
 KX224-I2C-EVK-001

Setting

Connect the Arduino and the SensorShield (Figure 1)
1.
USB connecter
Figure 1. Connection between the Arduino and the
SensorShield
Connect KX224-I2C-EVK-001 to the socket of I2C area
2.
on the SensorShield (Figure 2)
Set Voltage of the SensorShield to 1.8V or 3.0V (Figure 2)
3.
© 2018 ROHM Co., Ltd.
1 . *1 SensorShield is sold as Shield-EVK-001.
1pc
1pc
1pc
1pc
1pc
SensorShield
Figure 2. Connection between KX224-I2C-EVK-001 and
Connect the Arduino to the PC using a USB cable
4.
Download KX224-I2C.zip from the link below:
5.
http://www.rohm.com/web/global/sensor-shield-support
Launch Arduino IDE
6.
Select [Sketch]->[Include Library]->[Add.ZIP library...],
7.
install KX224-I2C.zip
Select [File]->[Examples]->[KX224-I2C]->[example]->
8.
[KX224-I2C]
1/2
User's Guide
the SensorShield
No. 60UG063E Rev.001
Apr.2018
