- Page 1 Ti100, Ti105, Ti110, Ti125 TiR105, TiR110, TiR125 Performance Series Thermal Imagers Users Manual February 2012, Rev.3, 11/14 © 2012-2014 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies. MyFlukeStore 1.888.610.7664 www.
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction ................1 How to Contact Fluke ..............2 Safety Information ..............3 Radio Frequency Data ............... 5 Accessories ................7 Before You Start ................. 8 How to Charge the Battery ............. 9 Two-Bay Battery Charger Base........... 9 On-Imager AC Power Socket .......... - Page 4 Video Playback ............... 43 Laser Pointer ............... 44 LED Light (Torch) ..............45 Backlight ................45 Fluke Connect™ Wireless System ........46 CNX™ Wireless System ............47 Memory Menu ................. 48 Review Data Files ..............48 Delete Data Files ..............49 Settings Menu .................
- Page 5 List of Figures Figure Title Page Lens Cover Laser Warning ............3 IR-OptiFlex Focus ..............13 SD Memory Card Insertion and Removal ........20 Level and Span Settings ............25 MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
- Page 6 Ti90, Ti95, Ti100, Ti105, Ti110, Ti125, TiR105, TiR110, TiR125 Users Manual MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
-
Page 7: Introduction
Introduction The Fluke Ti90, Ti95, Ti100, Ti105, Ti110, Ti125, TiR105, TiR110, and TiR125 Thermal Imagers (the Product or Imager) are handheld, infrared imaging cameras for use in many applications. These applications include equipment troubleshooting, preventive and predictive maintenance, and building diagnostics. -
Page 8: How To Contact Fluke
To register your Product, visit register.fluke.com. To view, print, or download the latest manual supplement, visit us.fluke.com/usen/support/manuals. To download SmartView software visit www.fluke.com/smartviewdownload. To download the Fluke Connect app, go to iTunes or Google app store and download Fluke Connect. MyFlukeStore 1.888.610.7664 www. .com... -
Page 9: Safety Information
Additional laser warning information is on the inside of the Product lens cover, see Figure 1. US PAT. FCC ID: T68-F125 IC: 6627A-F125 gju05.eps Figure 1. Lens Cover Laser Warning MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... - Page 10 These objects pose a burn hazard. • Do not disassemble the battery. • Use only Fluke approved power adapters to charge the battery. • Do not disassemble or crush battery cells and battery packs. • Use only specified replacement parts.
-
Page 11: Radio Frequency Data
Radio Frequency Data Note • Changes or modifications to the wireless 2.4 GHz radio not expressly approved by Fluke Corporation could void the user's authority to operate the Product. • This section does not apply to the Ti90 and Ti95 models. - Page 12 Product Category: With reference to the equipment types in the WEEE Directive Annex I, this product is classed as category 9 “Monitoring and Control Instrumentation” product. Do not dispose of this product as unsorted municipal waste. Go to Fluke's website for recycling information. MyFlukeStore 1.888.610.7664 www.
-
Page 13: Accessories
TI-CAR CHARGER 12 V Vehicle Charger Adapter 3039779 FLK-TI-VISOR2 Sun Visor 3996500 FLK-TI-TRIPOD2 Tripod Mounting Accessory 3996517 BOOK-ITP Introduction to Thermography Principles 3413459 Fluke Connect™ Wireless SD Card FC-SD8GB 4463628 (where available) MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 14: Before You Start
Warranty Registration Card [1] Fluke Connect is not available in all countries. [2] Fluke recommends the SD memory card that is supplied with the Imager. Fluke does not warrant the use or reliability of aftermarket SD memory cards of different brands or capacities. -
Page 15: How To Charge The Battery
When the Imager’s power is off and the ac power adapter is connected, flashes in the center of the display to show that the battery charge is in process. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 16: Optional 12 V Vehicle Charger
10 minutes if the most accurate temperature measurement is very important to your application. When you move an Imager between environments with large differences in ambient temperature, more adjustment time can be required. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 17: Features And Controls
Description LCD Display All Models Power On/Off All Models • • • • • • • Speaker • • • • • • • Microphone MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... - Page 18 • • • • IR-OptiFlex™ Focus Control Lithium-ion Smart Battery All Models • • 2-Bay Battery Charging Base AC Power Adapter with All Models Universal Adapter MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
-
Page 19: Focus
Without the correct focus, the thermal image can be blurry and the radiometric data will be inaccurate. Out-of-focus infrared images are frequently unusable or of little value. >4 ft 4 ft gju04.eps Figure 2. IR-OptiFlex Focus MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 20: Primary And Secondary Triggers
The secondary trigger operates the laser and LED light. For information about how to enable the laser and torch, see pages 44 and 45. Note The secondary trigger does not apply to the Ti90 and Ti95 models. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 21: How To Use The Control Buttons
The option selection menu stays open until you make the selection, go up a menu level, or cancel the action. Table 6 is list of features by model that you access through the menus. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 22: Menu Overview
.IS2, .JPG, .BMP • • .IS3 • • • • .AVI User-selectable Sleep/Auto Off All Models Time and Date Settings All Models Language Selection All Models Center Point Temperature All Models MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 23: Image Capture
3. Push to enter the Picture mode. 4. Focus Imager on the object and pull the primary trigger. 5. Push to continue. 6. Push save the picture with the image. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 24: Voice Annotation
Do the steps in the Review Data Files section on page 48 to see the image on the display. Push . Push or to set Audio. Push to listen to the audio. Push again to pause the audio. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 25: Edit Data Files
Pull the trigger to capture the image. The image is now in the buffer and you can save or edit. Push to save the image as a file and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 26: Sd Memory Card
Figure 3. SD Memory Card Insertion and Removal For information about how to save data, see page 19. For information about how to view or erase a stored image, see page 48. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 27: Temperature Measurement
More information is available on emissivity at http://www.fluke.com/emissivity and http://www.fluke.com/emissivityexplanation. We recommend the study of this topic to get the most accurate temperature measurements. MyFlukeStore 1.888.610.7664 www. -
Page 28: Smartview Software
Fluke infrared cameras and is supplied with the Ti100, Ti105, Ti110, Ti125, TiR105, TiR110, and TiR125. This software is intended for Fluke Imagers and contains features to analyze images, organize data and information, and make professional ®... -
Page 29: Range
to set the change and go back to the live view. • or to set the change and go back to the previous menu. • to cancel the change and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... - Page 30 Push to move the range to a lower temperature level. While you adjust the manual level, the scale along the right side of the display shows the thermal span as it moves to different levels within the total range. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
- Page 31 Push to decrease or narrow the temperature span. While you adjust the manual span, the scale along the right side of the display shows the thermal span increasing or decreasing in size. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
-
Page 32: Emissivity Adjustment
ε = x.xx. Adjust by Number To set the emissivity value: Push . Push / to highlight Measurement. Push or to view the menu. Push / to highlight Emissivity. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... - Page 33 to set the change and go back to the live view. • or to set the change and go back to the previous menu. • to cancel the change and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
-
Page 34: Reflected Background Temperature Compensation
to cancel the change and go back to the live view. Note If the Display is set to Display All, you see the information about current reflected background temperature as BG = xx.x. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 35: Tir-Mode
When you scan with the TiR-Mode on, the Imager displays a slight blurring effect. For best image results, hold the camera steady. Image enhancement cannot be applied to images after they are taken. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 36: Transmission/Transmittance Adjustment
to cancel the change and go back to the live view. Note If Display Information is set to Display All, you see the information τ about current transmission correction as = xx. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 37: Spot Temperatures
to cancel the change and go back to the live view. Note If the Display is set to Display All, you see the information about current transmission correction as τ = xxx%. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 38: User-Definable Spot Markers
Push to move the Marker location on the image. Push to highlight the next marker. Do Step 1 again. Do Step 2 for a third marker. Push when done. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 39: Center Box
When satisfied with the size of the Center Box, push: • or to set the change and go back to the previous menu. • to cancel the change and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 40: Image Menu
These palettes work best in situations with high thermal contrast for extra color contrast between the high temperatures and low temperatures. Table 7 lists the palettes that are available for each model. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... - Page 41 • Amber • • Amber Inverted To set a palette: Push . Push / to highlight Measurement. Push or to view the menu. Push / to highlight Image. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
-
Page 42: Ir-Fusion
IR-Fusion has different modes that vary by model, see Table 8. Full Visible mode is also available. (The Fluke Ti100 does not have IR-Fusion and can only display a full infrared image.) Table 8. -
Page 43: Color Alarm (Temperature Alarm)
The user must manually find and set these parameters. Certain models also display color isotherms, or infrared information, inside or outside of a set of both high and low limits. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 44: Set High-Temperature Color Alarm
to set the change and go back to the live view. • or to set change and go back to the previous menu. • to cancel the change and go back to the live view MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 45: Set Low-Temperature/Dew Point Color Alarm
to set the change and go back to the live view. • or to set the change and go back to the previous menu. • to cancel the change and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 46: Display Graphics Presentation
to set the change and go back to the live view. • or to set the change and go back to the previous menu. • to cancel the change and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 47: Camera Menu
or to go back to the previous menu. • to cancel the change and go back to the live view. Note shows on the display when the compass cannot make a reading. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 48: Video
to set the change and go back to the live view. • or to set the change and go back to the previous menu. • to cancel the change and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 49: Video Recording
During playback, push or for fast forward and rewind. Push to continue normal playback. Push to exit the playback mode. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 50: Laser Pointer
to cancel the change and go back to the live view. The laser warning symbol () shows in the Header zone of the display when the laser is turned on and you pull the secondary trigger. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 51: Led Light (Torch)
to set the change and go back to the live view. • or to set the change and go back to the previous menu. • to cancel the change and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 52: Fluke Connect™ Wireless System
The Imager supports the Fluke Connect™ Wireless System (may not be available in all regions). Fluke Connect™ is a system that wirelessly connects your Fluke test tools with an app on your smartphone. It enables you to see images from your infrared camera on your smartphone screen, save images to the asset's EquipmentLog™... -
Page 53: Cnx™ Wireless System
Menus CNX™ Wireless System The Imager supports the Fluke CNX™ Wireless System (may not be available in all regions). It can discover up to 10 3000 Series wireless tools up to 20 meters away. From those 10, you can select 5 tools to view their live measurements on the Imager display. -
Page 54: Memory Menu
Push / to highlight Memory. Push or to view the memory menu. Push to highlight the thumbnail of the file for review. Push to review the file. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 55: Delete Data Files
Push / to highlight Memory. Push . Highlight All Image and push . The Imager prompts you to continue or cancel. 5. Push to delete all files on the SD memory card. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 56: Settings Menu
.bmp, .jpg, and .is2. Video format selections are .avi and .is3. These selections remain valid when you turn the Imager off or on. To change the file format: Push . Push / to highlight Settings. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... - Page 57 The .is2 file format can be emailed and then opened with SmartView Software. This format has the maximum versatility. Visit the Fluke website or contact Fluke to find out how to download SmartView analysis and reporting software at no charge.
-
Page 58: Auto Off
to cancel the change and go back to the live view. When the Auto off feature is disabled and the Imager is left on, the Imager stays on until the battery is depleted. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 59: Date
to set the change and go back to the live view. • or to set the change and go back to the previous menu. • to cancel the change and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 60: Time
to set the change and go back to the live view. • or to set the change and go back to the previous menu. • to cancel the change and go back to the live view. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 61: Language
You can access information about the Imager from the Settings Menu. This includes: • Model • Camera serial number • Refresh rate • Engine serial number • Firmware version • FPGA # • Factory calibration date • Production date MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 62: Maintenance
How to Clean the Case Clean the case with a damp cloth and a weak soap solution. Do not use abrasives, isopropyl alcohol, or solvents to clean the case or lens/window. MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... -
Page 63: Battery Care
• Always operate in the specified temperature range. Caution Do not incinerate the Product and/or battery. Go to Fluke’s website for recycling information. MyFlukeStore 1.888.610.7664 www. -
Page 64: General Specifications
AC Operation ............AC operation with included power supply: 110 – 240 Vac, 50/60 Hz 15 V Power Saving ............Sleep Mode activated after 5 minutes of inactivity Automatic Power Off after 20 minutes of inactivity MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... - Page 65 Calibration Cycle ..........2 years (assumes normal operation and normal aging) Supported Languages .......... Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
-
Page 66: Detailed Specifications
Ti90 ..............150 mK Ti95, Ti100, Ti105, Ti110, Ti125 ..... ≤100 mK (0.1 °C at 30 °C target temperature) TiR105, TiR110, TiR125 ........≤80 mK (0.08 °C at 30 °C target temperature) MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:... - Page 67 ............ Ti105, Ti110, Ti125, TiR105, TiR110, TiR125 max mode ........... Ti95, Ti105, Ti110, Ti125, TiR105, TiR110, TiR125 Full Visible ............Ti90, Ti95, Ti105, Ti110, Ti125, TiR105, TiR110, TiR125 MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
- Page 68 Radiometric (.avi, .bmp, .jpg) files Export File Formats with ® SmartView Software .......... JPEG, JPG, JPE, JFIF, BMP, GIF, DIB, PNG, TIF, TIFF Memory Review ........... Thumbnail view navigation and review selection MyFlukeStore 1.888.610.7664 www. .com Shop for Fluke products online at:...
