- Page 1 GB660 / GB660C / GB660-V / GB660C-V Technical Manual 700045A Updated September 16, 2010 Allied Vision Technologies Canada Inc. 101-3750 North Fraser Way Burnaby, BC V5J 5E9 / Canada...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ......................2 Introduction ......................5 Precautions......................5 Warranty ......................... 5 Specifications ......................6 Supported Features ....................7 Mechanical ......................8 Connections ......................11 Cleaning the Sensor ....................15 Adjusting the C-mount ....................16 Camera Installation ....................17 System Optimization .................... - Page 3 Allied Vision Technologies customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Allied Vision Technologies for any damages resulting from such improper use or sale.
- Page 4 Contacting Allied Vision Technologies • Technical information: http://www.alliedvisiontec.com • Support: support@alliedvisiontec.com Allied Vision Technologies GmbH (Headquarters) Taschenweg 2a 07646 Stadtroda, Germany Tel.: +49.36428.677-0 Fax.: +49.36428.677-28 e-mail: info@alliedvisiontec.com Allied Vision Technologies Canada Inc. 101-3750 North Fraser Way Burnaby, BC, V5J 5E9, Canada...
-
Page 5: Introduction
Introduction The GB660 series of cameras are single board, 120 frames per second, VGA, Gigabit Ethernet cameras based on the Sony ICX618ALA and ICX618AQA, EXview HAD CCD sensors. Precautions READ INSTALLATION GUIDE CAREFULLY. This document contains specific information which is necessary for the correct operation and treatment of this product. -
Page 6: Specifications
Specifications Sensor Type Sony ICX618ALA CCD (ICX618AQA for color) Sensor Shutter Type Progressive Interline Image Resolution 659 x 494 pixels Pixel Size 5.6μm x 5.6μm Optical Format 1/4 inch Lens Mount C-mount with adjustable back focus (CS-mount available) † Color Sensor Filter Pattern Bayer Full Resolution Frame Rate 119 fps... -
Page 7: Supported Features
Supported Features Imaging Modes free-running, external trigger, fixed rate, software trigger Fixed Rate Control 0.001 fps to maximum frame rate External Trigger Delay 0 to 60 seconds in 1 microsecond increments External Trigger Event rising edge, falling edge, any edge, level high, level low Exposure Time 10 microseconds to 60 seconds in 1 microsecond increments Gain... -
Page 8: Mechanical
Mechanical 2.00 50.8 0.062 1.6 0.10 2.6 1.80 45.7 0.13 3.2 2 PLCS TYP 6 PLCS TYP 0.21 0.75 19.1 0.17 4.3 0.10 2.5 0.37 9.4 0.62 15.7 M2.5x0.45 MODEL: GB660/GB660C 2 PLCS TYP OPTIONS: LANDSCAPE/RIGHT ANGLE CONNECTORS 0.54 13.6 0.37 9.4 ITEM 1: 3M 10214-55G3PC 0.19 4.8... - Page 9 2.00 50.8 0.10 2.6 1.80 45.7 0.062 1.6 0.13 3.2 2 PLCS TYP 6 PLCS TYP 0.21 5.4 0.75 19.1 M2.5x0.45 0.53 13.5 0.63 16 2 PLCS TYP 1.16 29.5 0.93 23.6 0.37 9.4 0.62 15.7 MODEL: GB660-V/GB660C-V OPTIONS: LANDSCAPE/VERTICAL CONNECTORS 0.65 16.5 ITEM 1: 3M 10214-6212PC 0.23 5.8...
- Page 10 0.84 21.3 0.65 16.5 0.45 11.4 0.29 7.4 ADJUSTABLE C-MOUNT *Nominal value. This dimension will vary INCHES[MILLIMETERS] depending on CCD type. GB660 Technical Manual Page 10...
-
Page 11: Connections
Connections Figure 1. GB SERIES connection diagram. GB660 Technical Manual Page 11... - Page 12 Item 1: GIGABIT ETHERNET PORT This port conforms to the IEEE 802.3 1000BASE-T standard for Gigabit Ethernet over copper. It is recommended that CAT5E or CAT6 compatible cabling and connectors be used for best performance. Cable lengths up to 100m are supported. Item 2: General Purpose I/O PORT FUNCTION 12V POWER...
- Page 13 12V Power and Power Ground To operate the camera 12V Power with suitable current capacity (see specifications) must be provided on Pin 1 and the Power Ground on Pin 2. A cable assembly providing this power can be ordered from AVT (AVT P/N 02-8007A for North America or AVT P/N 02-8008A for a Universal supply).
- Page 14 Isolated Ground Isolated Ground must be connected to the user’s external circuit ground if Sync Input 1 or Sync Output 1 is to be used. Signal Ground Signal Ground must be connected to the user’s external circuit ground if Sync Input 2 or Sync Output 2 is to be used or if the RS-232 port is to be used.
-
Page 15: Cleaning The Sensor
Cleaning the Sensor DO NOT CONTACT CLEAN SENSOR UNLESS ABSOLUTELY NECESSARY. Identifying Debris Debris on the image sensor or optical components will appear as a darkened area or smudge on the image that does not move as the camera is moved. Do not confuse this with a pixel defect which will appear as a distinct point. -
Page 16: Adjusting The C-Mount
Adjusting the C-mount LOCKING RING C-MOUNT RING Figure 3. Camera Front View. THE C-MOUNT IS ADJUSTED AT THE FACTORY AND SHOULD NOT REQUIRE ADJUSTING. If for some reason, the C-mount requires adjustment, use the following method. Loosen Locking Ring Use an adjustable wrench to loosen locking ring. Be careful not to scratch the camera. When the locking ring is loose, unthread the ring a few turns from the camera face. -
Page 17: Camera Installation
Camera Installation Computer Interface The Prosilica GB Series cameras will work with any Ethernet network card; however AVT strongly recommends using Gigabit Ethernet components that support Jumbo Frames. A Jumbo Frame is loosely defined as a frame size greater than 1500 bytes however typical Jumbo Frames are around 9000 bytes. - Page 18 Gigabit Ethernet Setup for Windows o Install network card in computer. o Boot the PC and cancel the “Found new Hardware Wizard” window that may appear when Windows detects the new card. o Install the driver that came with the network card. o Once the driver is installed, open the Network Connections Dialog as follows: From the Windows desktop select start, then select Control Panel, then double click on the Network Connections icon.
- Page 19 Figure 5. Network card TCP/IP address. Figure 6. Turn off Firewall. o Return to the Gige Local Properties window as in Figure 4. Select the Advanced tab as in Figure 6 and disable the Firewall for this device. Click OK to save changes. GB660 Technical Manual Page 19...
- Page 20 Gigabit Ethernet Cabling All Gigabit Ethernet cabling and connectors should be CAT5E or CAT6 compatible. Cable lengths must not exceed 100 meters. Power Connection The camera requires a 12V DC power supply that can source a minimum of 500 mA of current. See the Connections section of this document for more information.
- Page 21 Installing GigE Viewer for Testing o The latest Viewer software can be downloaded from http://www.alliedvisiontec.com/us/support.html. o Run the GigE Viewer Installer.exe. This will install the Prosilica GB Digital Camera drivers as well as the AVT GigE Viewer application program. o Plug in the Prosilica GB camera via the Gigabit Ethernet port. Plug in the power connection. Verify that the Status LED 2 is a solid green.
-
Page 22: System Optimization
System Optimization o Open the Network Connections Dialog as follows: From the Windows desktop select start, then select Control Panel, then double click on the Network Connections icon. Double click the relevant network card listed or right-click the relevant network card and select Properties. This will open the properties window for your network card. - Page 23 Figure 9. Network card advanced settings. o Set Maximum Frame Size or Jumbo Frames to the maximum possible value. A typical value is 9000. If the list contains a property called Receive Descriptors, then change this value to its maximum value. Select OK to save properties. o From the main properties dialog as in Figure 8, make sure that only the Internet Protocol (TCP/IP) check box is selected then click OK.
-
Page 24: Trouble Shooting
Trouble Shooting Check the Basics o Is power available? Check the status LED 2. If the LED is off, the camera is not getting power. Verify the connections and cabling. o Is the LED 2 flashing once per second? This occurs if the firmware is corrupt because a firmware update was interrupted. -
Page 25: Addendum
Addendum GB660 Technical Manual Page 25... -
Page 26: Gb Io Schematic
GB IO Schematic CAMERA INTERNAL CIRCUIT SY NC OUTPUT 1 VDD-3.3 390R FAIRCHILD 1/8W MOCD207M SY NC INPUT 1 LOGIC SY NC INPUT 1 VDD-3.3 200R SY NC OUTPUT 1 ISOLATED GROUND LOGIC SY NC OUTPUT 1 GND POWER 12V POWER VDD-3.3 MAXIM MAX3221CPWR... -
Page 27: Isolated Trigger Schematic
Isolated Trigger Schematic CABLE SIDE USERS TRIGGER CIRCUIT SY NC OUTPUT 1 ISOLATED GROUND SY NC INPUT 1 POWER GROUND POWER GROUND 12V POWER 12V_POWER 3M 10114-3000PE SY NC INPUT 1 (DRIVER) USER POWER RECOMMENDED VALUES USER POWER SY NC OUTPUT 1 (RECEIVER) 0.7K 2.7K 1.8K... -
Page 28: Non-Isolated Trigger Schematic
Non-isolated Trigger Schematic USERS TRIGGER CIRCUIT CABLE SIDE POWER GROUND POWER GROUND 12V POWER 12V_POWER 3M 10114-3000PE SY NC INPUT 2 SY NC INPUT 2 (3.3V DRIVER) SY NC OUTPUT 2 SY NC OUTPUT 2 (3.3V RECEIVER) The non-isolated trigger circuit is connected to a Texas Instruments SN74LVC2G241 buffer/driver inside the camera. The required sync input current is less than 10uA and the maximum sync output current is 24mA. -
Page 29: Video Iris Schematic
Video Iris Schematic POWER GROUND POWER GROUND 12V POWER 12V_POWER 3M 10114-3000PE CABLE SIDE LENS POWER VIDEO SIGNAL LENS GROUND JEITA CONNECTOR GB660 Technical Manual Page 29... -
Page 30: Trigger Timing Diagram
Trigger Timing Diagram Readout Time Trigger Latency Expose Start Registered Delay Exposure Time User Trigger Logic Trigger Exposure Trigger Jitter Readout Interline Time Trigger Ready Imaging Idle GB660 Technical Manual Page 30... -
Page 31: Notes On Triggering
Notes on Triggering Definitions o User Trigger is the trigger signal applied by the user. o Logic Trigger is the trigger signal seen by the camera internal logic. o Tpd is the propagation delay between the User Trigger and the Logic Trigger. o Exposure is high when the camera image sensor is integrating light. - Page 32 Triggering during the Readout State o For applications requiring the fastest triggering cycle time whereby the camera image sensor is exposing and reading out simultaneously, then the User Trigger signal should be applied as soon as a valid Trigger Ready is detected. o In this case, Trigger Latency and Trigger Jitter can be up to 1 line time since Exposure must always begin on an Interline boundary.
