GX1910 / GX1910C
Technical Manual
700058A
April 7, 2010
Allied Vision Technologies Canada
Inc.
101-3750 North Fraser Way
Burnaby, BC
V5J 5E9 / Canada

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GX1910C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Allied Vision Technologies GX1910C

Summary of Contents for Allied Vision Technologies GX1910C

  • Page 1 GX1910 / GX1910C Technical Manual 700058A April 7, 2010 Allied Vision Technologies Canada Inc. 101-3750 North Fraser Way Burnaby, BC V5J 5E9 / Canada...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ......................2 Introduction ........................5 Precautions ........................5 Warranty ........................5 Specifications ....................... 7 Supported Features ..................... 8 Mechanical ........................9 Connections ....................... 10 Cleaning the Sensor ....................16 Adjusting the C-mount ....................17 Network Card Configuration ..................
  • Page 3 These products are not designed for use in life support appliances, devices, or systems where malfunction of these products can reasonably be expected to result in personal injury. Allied Vision Technologies customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Allied Vision Technologies for any damages resulting from such improper use or sale.
  • Page 4 Contacting Allied Vision Technologies • Technical information: http://www.alliedvisiontec.com • Support: support@alliedvisiontec.com Allied Vision Technologies GmbH (Headquarters) Taschenweg 2a 07646 Stadtroda, Germany Tel.: +49.36428.677-0 Fax.: +49.36428.677-28 e-mail: info@alliedvisiontec.com Allied Vision Technologies Canada Inc. 101-3750 North Fraser Way Burnaby, BC, V5J 5E9, Canada...

  • Page 5: Introduction

    Introduction The GX1910 series of cameras are sensitive, 63 frames per second, HDTV resolution, Gigabit Ethernet cameras based on the Kodak KAI-02150 CCD sensor. These cameras support the use of 1 or 2 gigabit Ethernet ports in a LAG configuration for higher bandwidth requirements.
  • Page 6 Canada Inc. will not warranty parts which have been damaged through the obvious misuse of this product. GX1910 Technical Manual Page 6...

  • Page 7: Specifications

    IEEE 802.3 1000BASE-T, 100BASE-TX Software Interface Standard GigE Vision Standard 1.0 Regulatory Conforms to CE, FCC, RoHS Applies to GX1910C only. † †† Power consumption will increase with reduced ROI imaging, vertical binning, and color formats. See Notes on Triggering in the Addendum.

  • Page 8: Supported Features

    Supported Features Imaging Modes free-running, external trigger, fixed rate, software trigger Fixed Rate Control 0.001 fps to maximum frame rate External Trigger Delay 0 to 60 seconds in 1 microsecond increments External Trigger Event rising edge, falling edge, any edge, level high, level low Exposure Time 10 microseconds to 60 seconds in 1 microsecond increments Gain...

  • Page 9: Mechanical

    Mechanical GX C-MOUNT GX1910 Technical Manual Page 9...

  • Page 10: Connections

    Connections GX CONNECTION DIAGRAM GX1910 Technical Manual Page 10...
  • Page 11 GIGABIT ETHERNET PORTS These ports conform to the IEEE 802.3 1000BASE-T standard for Gigabit Ethernet over copper. It is recommended that CAT5E or CAT6 compatible cabling and connectors be used for best performance. Cable lengths up to 100m are supported. For higher bandwidth requirements, both ports can be used in a link aggregation group (LAG) configuration.
  • Page 12 EXTERNAL POWER This connection provides the main power for the camera. The camera operates from a DC voltage between 5V to 24V. The current capacity of the power supply can be estimated by dividing the camera’s power requirement by the external power voltage. It is also recommended to factor this by about 50% as follows: Power supply current capacity = (power specification / external voltage) x 1.5 The conductor used for this connection must be adequate for the current consumption...
  • Page 13 SYNC OUTPUTS (1 to 4) These signals are optically isolated and require the user to provide a high voltage level (USER VCC) and signal common (USER GROUND). USER VCC can be from 5V to 24V. ICC is a function of USER VCC and load resistor R. An example of the functional circuit is indicated in the following diagram.
  • Page 14 These signals only function as outputs and can be configured as follows: Exposing Corresponds to when camera is integrating light. Trigger Ready Indicates when the camera will accept a trigger signal. Trigger Input A relay of the trigger input signal used to “daisy chain”...
  • Page 15 LENS CONTROL PORT FUNCTION IRIS + IRIS - FOCUS + FOCUS - ZOOM + ZOOM - AUTO IRIS SIGNAL GROUND LENS CONTROL PORT AS SEEN FROM BACK OF CAMERA This connector provides the signals necessary to control the iris, focus, and zoom of most commercially available TV Zoom lenses.

  • Page 16: Cleaning The Sensor

    Cleaning the Sensor DO NOT CONTACT CLEAN SENSOR UNLESS ABSOLUTELY NECESSARY. Identifying Debris Debris on the image sensor or optical components will appear as a darkened area or smudge on the image that does not move as the camera is moved. Do not confuse this with a pixel defect which will appear as a distinct point.

  • Page 17: Adjusting The C-Mount

    Adjusting the C-mount THE C-MOUNT IS ADJUSTED AT THE FACTORY AND SHOULD NOT REQUIRE ADJUSTING. If for some reason, the C-mount requires adjustment, use the following method. Loosen Locking Ring Use an adjustable wrench to loosen locking ring. Be careful not to scratch the camera. When the locking ring is loose, unthread the ring a few turns from the camera face.
  • Page 18 ring. Rotate the lens and c-mount ring until the image is focused. Carefully tighten locking ring. Recheck focus. GX1910 Technical Manual Page 18...

  • Page 19: Network Card Configuration

    Network Card Configuration Operating GigE Vision GX cameras using multiple network adaptors The GX series cameras offer two Gigabit Ethernet ports for image data transfer and control. Users can connect one or both ports on the GX to Ethernet adapter ports on a host computer. Connecting both ports will increase the available bandwidth to 240 MB/sec, allowing higher frame rates and resolutions than a single port connection.
  • Page 20 5. Click on “OK” to validate your change (the “Properties” window will close). The Property list will be different between different types/brands of gigabit Ethernet interface cards. If "Jumbo Frames" does not appear in this list, then your card probably does not support it.
  • Page 21 adapter from others in your system. Click “Next” to continue. 12. Select the two Ethernet ports to which the GX camera will be connected. These ports will form our LAG or TEAM. Click “Next” to continue. 13. Choose “Static Link Aggregation”. Click “Next”...
  • Page 22 15. Once completed the properties of the TEAM (LAG) that has just been created will appear. A new Network Connections Icon corresponding to the LAG group is created. You have now completed the Link Aggregate Group configuration. 16. Reboot the system and install GigE Sample Viewer. GX1910 Technical Manual Page 22...

  • Page 23: Gige Sample Viewer And Filter Driver

    GigE Sample Viewer and Filter Driver o Download GigE Sample Viewer from www.alliedvisiontec.com. This will install the Sample Viewer application program, drivers, and optionally the AVT/Prosilica Filter Driver. The Filter Driver will improve CPU performance and is recommended. o Plug in the GX camera Ethernet cable(s) and power. Verify that the Green LED is a solid green.

  • Page 24: Trouble Shooting

    Trouble Shooting Is the camera getting power? The Green LED is the camera power indicator. If unlit, check the power adaptor. If possible, swap with one that is known to work. If using a custom power adaptor, be sure the adaptor supports the voltage and power requirements of the camera . If the LED still does not light up, contact AVT Canada Inc.
  • Page 25 The following example is not on the same Subnet: NIC IP 169.250.23.2 Subnet Mask: 255.255.255.0, CamIP 169.254.13.0 Subnet Mask: 255.255.0.0. This can happen if you use a non AutoIP range on your NIC and it doesn’t have access to a DHCP server. Either change your NIC IP to be in the AutoIP range, or fix the camera IP address to be on the same subnet as your NIC.
  • Page 26 All stats 0 while streaming. Firewall likely blocking traffic • All stats 0. Likely a firewall is blocking incoming traffic. Disable your firewall. Check your camera trigger settings. Many camera trigger modes require a software or hardware trigger event to capture frames. •...

  • Page 27: Addendum

    Addendum GX1910 Technical Manual Page 27...

  • Page 28: Gx Io Schematic

    VDD+3.3 VDD+3.3 VDD+3.3 4.7K 4.7K PIN 1. POWER GROUND PIN 2. EXTERNAL POWER 180R 5V TO 24V PIN 3. SYNC OUT 4 1/10W IF = 5mA PIN 4. SYNC IN 1 PIN 5. SYNC OUT 3 PIN 6. SYNC OUT 1 CAMERA LOGIC SY NC IN 1 MMBF4393LT1G PIN 7.

  • Page 29: User Trigger Circuit Example

    CAMERA POWER CABLE SIDE POWER GROUND EXTERNAL POWER SYNC OUT 4 SYNC IN 1 SYNC OUT 3 SYNC OUT 1 USER GND VDD+5 5V POWER USER VCC CIRCUIT SYNC IN 2 SYNC OUT 2 HIROSE HR10A-10P-12S NOTES: 1. CAMERA POWER = 5V TO 24V USER LOGIC SYNC IN 1 1Y 1 2.

  • Page 30: Tv Zoom Lens Connection

    ZOOM+ IRIS+ IRIS- ZOOM- FOCUS+ FOCUS+ FOCUS- TV ZOOM LENS BIPOLAR TYPE FOCUS- ZOOM+ ZOOM- IRIS+ IRIS- COMMON COMMON HIROSE 3240-8P-C(50) IRIS COMMON ZOOM FOCUS COMMON TV ZOOM LENS FOCUS UNIPOLAR TYPE ZOOM IRIS COMMON COMMON COMMON HIROSE 3240-8P-C(50) NOTES: 1.

  • Page 31: Video Iris Connection

    POWER GROUND POWER GROUND 12V POWER 12V_POWER HIROSE HR10A-10P-12S LENS POWER VIDEO HIROSE 3240-8P-C(50) AUTO-IRIS VIDEO SIGNAL LENS LENS GROUND JEITA CONNECTOR...

  • Page 32: Trigger Timing Diagram

    Trigger Timing Diagram GX1910 Technical Manual Page 32...

  • Page 33: Notes On Triggering

    Notes on Triggering Definitions o User Trigger is the trigger signal applied by the user. o Logic Trigger is the trigger signal seen by the camera internal logic. o Tpd is the propagation delay between the User Trigger and the Logic Trigger. o Exposure is high when the camera image sensor is integrating light.
  • Page 34 Triggering during the Readout State o For applications requiring the fastest triggering cycle time whereby the camera image sensor is exposing and reading out simultaneously, then the User Trigger signal should be applied as soon as a valid Trigger Ready is detected. o In this case, Trigger Latency and Trigger Jitter can be up to 1 line time since Exposure must always begin on an Interline boundary.

  • Page 35: Camera Controls

    Camera Controls For the latest, up to date camera controls, see AVT Camera and Driver Attributes.pdf at http://www.alliedvisiontec.com GX1910 Technical Manual Page 35...
