Guarantee and support _______________________________________________________________________________ Ordering maintenance products______________________________________________________________________ Technical specifications_______________________________________________________________________________ Introduction Dear customer, we thank you for buying this Philips 2100 series automatic espresso machine! To fully benefit from the support that Philips offers, please register your product at www.philips.com/welcome. The machine is...
- Do not use the machine if the mains plug, the power cord or the machine itself is damaged. - Do not make any modifications to the machine or its power cord. - Only have repairs carried out by a service center authorized by Philips to avoid a hazard.
English - The machine should not be used by children younger than 8 years old. - This machine can be used by children aged from 8 years and above and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the machine in a safe way and if they understand the hazards involved.
The water can be contaminated. Use fresh water every time you use the machine. Electromagnetic fields (EMF) This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic fields. Machine overview (Fig. 1)
English First installation Installing the machine 1 Remove all packaging material from the machine. 2 Place the machine on a table or worktop away from the tap, the sink and heat sources. Note: Leave at least 15 cm of free space above, behind and on both sides 15cm of the machine.
English 2 Remove the water tank from the machine. 3 Rinse the water tank under the tap. 4 Fill the water tank with cold tap water up to the MAX indication. 5 Slide the water tank back into the machine. Filling the coffee bean container 1 Fill the coffee bean container with espresso beans.
English 3 When the warning light flashes quickly, turn the control dial to the hot water icon and wait a few seconds. The warning light goes out and some water comes out of the hot water/steam wand or automatic milk frother. 4 After a few seconds, when hot water stops coming out of the hot water/steam wand and the warning light flashes slowly, turn the control dial back to the single bean icon.
English 3 Turn the knob of the filter to the setting that corresponds to the water hardness of the area you live in. a Very soft water/ soft water b Hard water (default) c Very hard water Note: You can test the water hardness with a water hardness test strip. 4 Place the filter in the empty water tank.
English Brewing milk- based beverages Note: Use cold milk (at a temperature of approximately 5°C/41°F) with a protein content of at least 3% to ensure an optimal frothing result. You can use whole milk, semi-skimmed milk, soy milk and lactose free milk. Brewing cappuccino Warning: Danger of burning! Dispensing may be preceded by small jets of hot water.
English 9 Place a cup under the automatic milk frother. Perform a quick clean dispensing hot water for 3-5 seconds after brewing a cappuccino, see chapter 'Cleaning and maintenance', section 'Quick Clean of the milk system'. 10 Remove the milk tube connector from the automatic milk frother. 11 Plug the milk connector to the pin on the milk container lid and put the milk container in the fridge.
English 5 Turn the control dial back to one of the coffee bean icons when the cup contains the preferred amount of hot water. Adjusting the machine You can adjust the grinding degree and coffee volume to obtain coffee that is perfectly customised to your taste.
English The machine automatically saves the new setting. Cleaning and maintenance Regular cleaning and descaling prolongs the lifetime of your machine and ensures optimum quality and taste of your coffee. Warning: Never use scouring pads, abrasive cleaning agents or aggressive liquids to clean the machine. Warning: Always unplug the machine and let it cool down before you clean it.
Page 17
English Cleaning cycle with milk circuit cleaner and water. 1 Pour the content of a Saeco milk circuit cleaner sachet into the milk carafe and fill the milk carafe with water up to the MAX level. Close the lid of the milk carafe. 2 Insert the other end of the suction tube into the milk carafe till the bottom of the milk carafe.
Page 18
English 4 To detach the automatic milk frother, press the sides (1) and remove it by pulling it out while making slight lateral movements (2). 5 Remove the rubber lid from the milk frother. 6 Rinse the components with lukewarm water. Note: You can also clean these components in the dishwasher.
English 10 Place the rubber ring back onto the automatic milk frother. 11 Attach the automatic milk frother back to the hot water/steam wand. Cleaning the brew group Warning: Do not clean the brew group in the dishwasher and do not use washing-up liquid or a cleaning agent to clean it.
Page 20
English 4 Press the PUSH button and pull at the grip of the brew group to remove it from the machine. 5 Clean the coffee exit duct thoroughly with a spoon handle or another round-tipped kitchen utensil. 6 Clean the inside of the machine with a damp cloth. 7 Rinse the outside of the brew group under a lukewarm tap.
12 Slide the coffee grounds container back into the machine. Lubrication For optimal performance of the machine you have to lubricate the brew group. See table below for the lubrication frequency. For support visit our website: www.philips.com/support. Type of usage Nr of daily products Lubrication frequency...
Philips Saeco descaling solution to descale the machine. The Philips Saeco descaling solution is designed to ensure optimal performance of the machine. You can buy the Philips Saeco descaling solution in the online shop at www.shop.philips.com/service. Note:The use of other descaling products may cause damage to the machine and leave residues in the water.
(if present). 3 Empty the water tank and remove the Intenza+ water filter (if present). Pour the entire bottle of the Philips/Saeco descaling solution into the water tank. 4 Add water to the descaling solution in the water tank up to the MAX indication.
English 5 Turn the control dial to the hot water icon. 6 Let hot water flow out of the hot water/steam wand until the ‘water tank empty’ light lights up continuously. Note: If you want to interrupt the water flow, turn the control dial back to the coffee bean icon.To restart the water flow, turn it back to the hot water icon.
English Meaning of light signals - The on/off button light lights up continuously. The machine is ready for use. - The on/off button flashes slowly. The machine is warming up or performing a procedure. - The on/off button flashes quickly. The machine is overheated. Brew a cup of hot water to cool down the machine.
Page 26
English - The 2-cup and on/off button lights flash slowly. The machine is programming the amount of coffee to brew. Follow the instructions in chapter ‘Using the machine’, section ‘Adjusting the coffee volume’. - The 2-cup light lights up continuously and the on/off button flashes slowly.
- All the lights flash slowly and simultaneously. The machine is out of order. Switch off the machine for 30 seconds, then switch it back on.Try this two or three times. If the machine does not reset, contact the Philips Consumer Care Centre.
Page 28
English The machine is stuck in the The descaling process Press the on/off button. You can restart descaling procedure. has been interrupted or the descaling procedure or follow the proceeded in an instructions in chapter ‘Descaling the incorrect order. machine’, section ‘Interruption of the descaling process'.
Page 29
English The brew group cannot be The brew group is not in The brew group was not put in rest inserted. the correct position. position before it was placed back. Make sure that the lever is in contact with the base of the brew group and that the hook of the brew group is in the correct position.
If you need information or support, please visit www.saeco.com/support or read the separate guarantee leaflet. If you need information or support, please contact the Philips Saeco hotline in your country. Contacts are included in the warranty booklet supplied separately or visit www.saeco.com/support.
English Technical specifications Feature Value/ location Nominal voltage Inside of service door Power rating Inside of service door Size (w x h x d) 295mm x 325mm x 420mm Weight 6.9 kg Material Plastic Cord length 0.8m -1.2m Water tank capacity 1000ml Cup size Up to 95mm...
