INSTALLATION
To install the monitor to your host system, please follow the steps as given
below:
Steps
1. 1-1
Connect Video Cable
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the VGA video cable to the computer.
1-2
Connect the digital cable (only for dual-input models).
a. Make sure both the monitor and computer are powered-OFF.
b. Connect one end of the 24-pin DVI cable to the back of the
monitor and connect the other end to the computer's port.
HDMI Cable (Only HDMI-Input Model)
1-
3
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the HDMI cable to the computer.
2.
Connect the adapter
a
Connect the AC cord to the adapter.
b
Connect one end of the adapter to the monitor and the other end to
a properly grounded, AC outlet
3
. Power-ON Monitor and Computer
Power-ON the monitor first, then power-ON the computer.
This sequence is very important.
4.
If the monitor still does not function properly, please refer to the
troubleshooting section to diagnose the problem.
DC
HDMI
.
VGA
DVI
HDMI
DC IN
DVI
EN-12
2
VGA
