Video Input, Audio And Power Ports - Nixeus Vue NX-VUE22 User Manual

HDMI: This video input supports up to 1920 x 1080 Full HD resolution at 60Hz (HDMI cable not included). HDMI
also transmit audio to the NX-VUE22's speakers so you do not need to connect the 3.5mm audio cable.
VGA: This is a legacy video input that allows the NX-VUE22 to be used with older computers. Maximum
resolution for this video connection type is 1920 x 1080 with a VGA cable.
AUDIO: This is an audio input only port. If you are using VGA or DVI video cables - these type of connections do
not transmit audio to the NX-VUE22's speakers. You must use the included 3.5mm audio cable to
connect to your computer's 3.5mm audio output to the NX-VUE22's audio input port to use the
display's speakers.
DC: This is the power input connection for the NX-VUE22's power cable.
Video Input Ports, Audio, and Power
6
