- Page 1 SPMAR8360T Spektrum AR8360T AS3X and SAFE 8 CH Receiver...
- Page 2 WARNING AGAINST COUNTERFEIT PRODUCTS Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM or Spektrum technology.
-
Page 3: Table Of Contents
AR8360T AS3X and SAFE Telemetry Receiver The Spektrum™ AR8360T Receiver is full range with telemetry, and is compatible with all Spektrum™ DSM2 and DSMX technology ® ® transmitters. Perform the setup for the AR8360T receiver through a compatible Spektrum Transmitter with Forward Programming. -
Page 4: Smart Throttle
AR8360T receiver for Smart Technology features. For Smart to function you must have a Smart ESC paired with a Smart telemetry receiver, and a Spektrum DSMX transmitter with telemetry. An update for your transmitter may be required for Smart features. See www.spektrumrc. -
Page 5: Telemetry
XBus connector. Every XBus telemetry device has two XBus ports, and XBus telemetry sensors can be connected in a daisy chain in any order. The AR8360T is not compatible with the Spektrum Temperature Sensor (SPMA9571) See www.spektrumrc.com for more information about telemetry accessories Installing the AR8360T Receiver Mount the receiver using double-sided servo tape. -
Page 6: Transmitter And Receiver Binding
NOTICE: Do not cut, kink, or modify the antennas. Damage to the coaxial portion of an antenna will reduce the performance of the antenna. Shortening or cutting off the 31mm tip will reduce the range. Transmitter and Receiver Binding Programming the AR8360T receiver requires a Spektrum DSM2 /DSMX ™... -
Page 7: Failsafe
• All channels have no output until the receiver has linked to the transmitter. Initial Setup Verify your transmitter is updated to the latest Spektrum AirWare™ software to take advantage of Forward Programming. See your transmitter manual for updating instructions. -
Page 8: Ar8360T Receiver- Basic As3X Setup
AR8360T Receiver- Basic AS3X Setup To use AS3X technology with the Spektrum AR8360T Receiver, the receiver needs to be set up with a compatible Spektrum transmitter. Verify the basic setup and trim is accurate before attempting AS3X setup. Forward Programming Setup: The receiver is directly configured through the Forward Programming menu. -
Page 9: As3X Reaction Test
AS3X Reaction Test This test ensures that the AS3X control system is functioning properly. Assemble the aircraft, bind your transmitter to the receiver, and complete the AS3X First Time Setup in the Forward Programming menu before performing this test. Raise the throttle above 25% to activate AS3X, then lower the throttle. Once the AS3X system is active, control surfaces move in response to aircraft movement. -
Page 10: Ar8360T Receiver- Safe Setup
AR8360T Receiver- SAFE Setup Setting up SAFE Technology on the AR8360T Receiver takes place in Forward Programming. Complete the AS3X setup and verify operation in flight. Forward Programming Setup: To add SAFE flight stabilization the Flight Modes on the receiver need to be configured. 1. -
Page 11: Advanced Tuning
Advanced Tuning Basic gain tuning can be as simple as using a slider, but to fine tune the AS3X system there are many setup and tuning options. AS3X Gain tuning options In your transmitter’s menu select Forward Programming -> Gyro Settings -> AS3X Settings •... - Page 12 When you add Flight Modes within Forward Programming, additional tuning options are added in the AS3X Setting menu. Be sure to change through all the flight modes with your assigned switch and verify values for each feature for every flight mode. Select Forward Programming ->...
- Page 13 SAFE Setting menu. The First Time SAFE Setup should be sufficient to fly your airplane, but to fine tune the SAFE system there are many setup and tuning options. Select Forward Programming -> Gyro Settings -> SAFE Settings -> • SAFE Gains can be fine tuned for each axis within each Flight Mode. •...
-
Page 14: Safe (Self Leveling) Flying Tips
Other Settings (Forward Programming) System Setup Select Forward Programming -> Other Settings -> • Select Failsafe -> Select each channel and assign it to Preset or Hold Last. When you select a different channel for Output, a new group of settings appears. Capture Failsafe Positions ->... -
Page 15: Channel Limitations
Differences between Self Leveling/Angle Demand and AS3X modes This section is generally accurate but does not take into account flight speed, battery charge status, and other limiting factors. SAFE Beginner SAFE Intermediate Control stick Aircraft will continue to fly Aircraft will self level is neutralized at its present attitude Aircraft will bank or... -
Page 16: Flight Log
If your system displays a hold, diagnose the cause and resolve the issue before flying again. It is normal to see a hold logged if you power OFF your transmitter and back ON. IMPORTANT: The Spektrum Flight Log (SPM9540) is not compatible with the AR8360T receiver. -
Page 17: Range Testing
Range Testing Before each flying session, and especially with a new model, it’s important to perform a range check. All Spektrum aircraft transmitters incorporate a range testing system, which reduces the output power to allow a range check. 1. With the model resting on the ground, stand approximately 100 feet (30 meters) away from the model. -
Page 18: Receiver Power System Requirements
Receiver Power System Requirements Some of the power system components that affect the power supply to the receiver include: • Receiver battery pack (number of cells, capacity, cell type, state of charge). • The ESC’s capability to deliver adequate voltage to the receiver when the servos demand high current •... -
Page 19: Optional Accessories
Heading- An optional feature of AS3X, heading will make the airplane try to hold its attitude when the control is relaxed. This is not a self-leveling feature, it only makes the aircraft track accurately. Gain- Tells the stabilization system the level of damping it should provide. SRXL2- A Bi-Directional data communication protocol that enables digital devices to communicate over a single signal wire. -
Page 20: Troubleshooting Guide As3X
Troubleshooting Guide AS3X Problem Possible Cause Solution Damaged propeller or Replace propeller or spinner spinner Imbalanced Balance the propeller propeller Replace parts or correctly align Motor vibration propeller or other parts and tighten fasteners as needed Align and secure receiver in Loose receiver fuselage Tighten or otherwise secure parts... -
Page 21: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Throttle not at idle Reset controls with throttle and/or throttle trim stick and throttle trim at lowest too high setting Throttle servo travel is Make sure throttle servo travel Aircraft will not lower than 100% is 100% or greater respond to throttle but responds to... - Page 22 Problem Possible Cause Solution Move powered transmitter a few Transmitter too near feet from aircraft, disconnect aircraft during connecting and reconnect flight battery to process aircraft Aircraft or transmitter is Move aircraft and transmitter too close to large metal to another location and attempt object, wireless source or connecting again another transmitter...
-
Page 23: 1-Year Limited Warranty
1-YEAR LIMITED WARRANTY What this Warranty Covers - Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 year from the date of purchase. What is Not Covered - This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or due to improper use, installation, operation or... - Page 24 https://www.horizonhobby.com/content/service-center-render-service-center or call the toll free telephone number referenced in the Warranty and Service Contact Information section to speak with a Product Support representative. Inspection or Services - If this Product needs to be inspected or serviced and is compliant in the country you live and use the Product in, please use the Horizon Online Service Request submission process found on our website or call Horizon to obtain a Return Merchandise Authorization (RMA) number.
-
Page 25: Warranty And Service Contact Information
Warranty and Service Contact Information Country of Horizon Hobby Contact Information Address Purchase Horizon Service Center servicecenter.horizonhobby.com/ (Repairs and RequestForm/ Repair Requests) 2904 Research Rd. United States Champaign, Illinois, Horizon Product productsupport@horizonhobby.com. of America 61822 USA Support (Product Technical 877-504-0233 Assistance) websales@horizonhobby.com Sales... -
Page 26: Fcc Information
FCC ID: BRWSPMAR8360T Supplier’s Declaration of Conformity AR8360T 8CH Telemetry Receiver (SPMAR8360T) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 27: Compliance Information For The European Union
Compliance Information for the European Union EU Compliance Statement: AR8360T 8CH Telemetry Receiver (SPMAR8360T); Hereby, Horizon Hobby, LLC declares that the device is in compliance with the following: EU Radio Equipment Directive 2014/53/ EU; RoHS 2 Directive 2011/65/EU; RoHS 3 Directive - Amending 2011/65/EU Annex II 2015/863. - Page 28 © 2021 Horizon Hobby, LLC. DSM, DSM2, DSMX, SAFE, AS3X, Spektrum Airware, SRXL2, SmartSafe, Avian, and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
