Summary of Contents for Spektrum SPMSRS4210
- Page 1 SPMSRS4210 INSTRUCTION MANUAL SPMSRS4210 BEDIENUNGSANLEITUNG MANUEL D’UTILISATION SPMSRS4210 MANUALE DI ISTRUZIONI SPMSRS4210...
-
Page 2: Warranty Registration
WARNING AGAINST COUNTERFEIT PRODUCTS Always purchase from a Horizon Hobby, Inc. authorized dealer to ensure authentic high-quality Spektrum product. Horizon Hobby, Inc. disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM or Spektrum. -
Page 3: General Precautions
WATERPROOF COMPONENT Your new Spektrum™ receiver has been designed and built to allow you to operate your vehicle in many wet conditions, including puddles, creeks, wet grass, snow and even rain. While waterproof, this component has not been designed to be immersed in water for long periods of time and should NOT be treated like a submarine. -
Page 4: Wet Conditions Maintenance
AVC – ACTIVE VEHICLE CONTROL AVC™ technology is the newest Spektrum™ RC innovation from Horizon Hobby. This Spektrum stabilization system adds a whole new level of control to your RC driving experience. AVC technology utilizes sensors to adjust steering and throttle output, providing you with a more stable and controlled driving experience. - Page 5 SRS4210 INSTRUCTION MANUAL The Spektrum™ SRS4210 DSMR™ Surface receiver is compatible with all Spektrum DSMR transmitters and is also ® backwards compatible with DSM2 transmitters. The SRS4210 ® receiver is NOT compatible with DSM transmitters. For a complete list of compatible transmitters, see the SRS4210 product page on spektrumrc.com.
-
Page 6: Receiver Connection And Installation
Receiver Connection and Installation You must install the receiver in the vehicle before binding the transmitter and receiver. The receiver can be mounted fl at with the label up or on its side. When you bind the receiver, the AVC system automatically detects the orientation of the receiver. - Page 7 Powering the receiver with a separate receiver pack Battery Throttle Servo Receiver Steering Servo Powering the receiver with an ESC Battery To Motor Electronic Speed Control Receiver Steering Servo IMPORTANT: If you adjust the steering and throttle trim on your transmitter, the receiver must be turned off and back on again in order to save the new trim settings.
-
Page 8: Binding And Calibrating The Receiver
Binding Receiver to Transmitter In order to operate, the receiver must be bound to the transmitter. Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifi er) code of a single specifi c transmitter. When a receiver is bound to a transmitter/model memory, the receiver will only respond to that specifi... - Page 9 The receiver Inadequate battery Charge or replace the receiver stops respond- voltage batteries. Spektrum receivers ing during require at least 3.5V to operate operation (We recommend using a 6V receiver pack). An inadequate power supply can allow voltage to momentarily drop below 3.5V...
-
Page 10: Year Limited Warranty
1-YEAR LIMITED WARRANTY What this Warranty Covers Horizon Hobby, Inc., (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship for a period of 1 years from the date of purchase. What is Not Covered This warranty is not transferable and does not cover (i) cosmetic damage, (ii) damage due to acts of God, accident, misuse, abuse, negligence, commercial... -
Page 11: Warranty Services
WARRANTY SERVICES Questions, Assistance, and Services Your local hobby store and/or place of purchase cannot provide warranty support or service. Once assembly, setup or use of the Product has been started, you must contact your local distributor or Horizon directly. This will enable Horizon to better answer your questions and service you in the event that you may need any assistance. - Page 12 ½ hour of labor. In addition you will be billed for return freight. Horizon accepts money orders and cashier’s checks, as well as Visa, MasterCard, American Express, and Discover cards. By submitting any item to Horizon for service, you are agreeing to Horizon’s Terms and Conditions found on our website http://www.horizonhobby.com/content/_service-center_render-service-center. ...
-
Page 13: Compliance Information For The European Union
FCC Statement This equipment has been tested and found to comply with the limits for Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 14 Updated 7/17 ©2017 Horizon Hobby, Inc. DSM, DSM2, DSMR, Active Vehicle Control, AVC and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, Inc. The Spektrum trademark is used with permission of Bachmann Industries, Inc. Patents pending.
