JL Audio Stealthbox SB-POL-SLINGSUBP/10W3v3 Installation Manual page 2

I N C L U D E D H A R D WA R E
8
9
6
Note: For optimum performance, JL Audio recommends applying the included Foam Strips (or sound damping material) to surrounding plastic panels to reduce unwanted vibrations.
Page 2 • JL Audio, Inc., 2017
SB-POL-SLINGSUBP/10W3v3 INSTR_SKU# 011483
1
2
3
4
BOM ID Qty SKU Description
1 2 153814 8 - 32 x 1/2" Pan Head Phillips Machine Screw
ABS Plate
2 1 153850
3 2 153855 M6 - 1 x 50mm Hex Drive Flanged Button Head Screw
4 4 153858 Nylon Plastic Washer
5 2 153853 M6 - 1 x 25mm Hex Drive Flanged Button Head Screw
6 4 153856 M6 - 1 U-Nut
7 1 153849 Bottom Bracket
8 1 150285 Nylon Cable Tie
9 1 153847 Top Bracket
- 1 153857 3/4" x 3/4" EPDM Foam (not shown)
- 1 150249 Foam Tape (not shown)
5
4
6
7
Continued on Next Page
