Ultra-low refrigerated circulator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Operating Manual
Ultra-Low
Refrigerated Circulator
FP51-SL
1.951.2823-V7
Find Quality Products Online at:
06/18
GlobalTestSupply
www.
English
09.07.18
.com
sales@GlobalTestSupply.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9352751.N.CSA/UL and is the answer not in the manual?

Questions and answers

Related Manuals for Julabo 9352751.N.CSA/UL

Summary of Contents for Julabo 9352751.N.CSA/UL

  • Page 1 English Operating Manual Ultra-Low Refrigerated Circulator FP51-SL 1.951.2823-V7 06/18 09.07.18 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 2 Congratulations! You have made an excellent choice. JULABO thanks you for the trust you have placed in us. This operating manual has been designed to help you gain an understanding of the operation and possible applications of our circulators. For optimal utilization of all functions, we recommend that you thoroughly study this manual prior to beginning operation.

  • Page 3: Table Of Contents

    FP51-SL TABLE OF CONTENTS Operating manual ........................ 5 Intended use ......................... 5 1.1. Description ....................... 5 Operator responsibility – Safety recommendations ............6 2.1. Disposal ........................8 2.2. Warranty conditions ....................8 2.3. EC Conformity ......................9 2.4. Technical specifications ..................11 Operating instructions .......................
  • Page 4 12.3. List of commands ....................86 12.4. Status messages ....................90 12.5. Error messages....................... 90 13. Installation of electronic module with analog connectors ..........91 14. JULABO Service – Online remote diagnosis ............... 92 15. Cleaning / repairing the unit ..................93 GlobalTestSupply www.

  • Page 5: Operating Manual

    Operating manual Intended use JULABO circulators have been designed to control the temperature of specific fluids in a bath tank. The units feature pump connections for temperature control of external systems (loop circuit). JULABO circulators are not suitable for direct temperature control of foods, semi- luxury foods and tobacco, or pharmaceutical and medical products.

  • Page 6: Operator Responsibility - Safety Recommendations

    Operator responsibility – Safety recommendations Operator responsibility – Safety recommendations The products of JULABO ensure safe operation when installed, operated, and maintained according to common safety regulations. This section explains the potential dangers that may arise when operating the circulator and also specifies the most important safety precautions to preclude these dangers as far as possible.
  • Page 7 Warning label W26: Colors: yellow, black Hot surface warning. (The label is put on by JULABO) Observe the instructions in the manuals for instruments of a different make that you connect to the circulator, particularly the respective safety recommendations. Also observe the pin assignment of plugs and technical specifications of the products.

  • Page 8: Disposal

    10 000 working hours. To apply for this extended warranty the user must register the unit on the JULABO web site. Indicating the serial no. The extended warranty will apply from the date of JULABO GmbH’s original invoice.

  • Page 9: Ec Conformity

    FP51-SL 2.3. EC Conformity GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 10 Operator responsibility – Safety recommendations GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 11: Technical Specifications

    FP51-SL 2.4. Technical specifications Ultra-Low Refrigerated Circulator FP51-SL Working temperature range °C -51 ... 200 Temperature stability °C ±0,05 Cooling capacity °C -20 -40 Medium: ethanol 2.0 1.5 1.0 0.26 Cooling compressor 1-stage Refrigerant R507 Overall dimensions (WxDxH) 46x55x89 Bath opening (WxL) 18x12 Bath depth...
  • Page 12 Operator responsibility – Safety recommendations Electrical connections: External alarm device 24-0 V DC / max. 25 mA Computer interface RS232 or RS485 External Pt100 sensor Optional for HL, SL (Order No. 8900100 Electronic module with analog connections) Programmer input -100 °C to 400 °C = 0 - 10 V or 0 - 20 mA or 4 - 20 mA Input for the signal of a flow meter or external manipulated variable Temperature recorder outputs 0 - 10 V (0 V = -100 °C, 10 V = 400 °C)
  • Page 13 The operator undertakes to have maintenance, repair, service, recovery and recycling work carried out by certified personnel who have been authorized by JULABO. All such work must be documented. The operator must keep records and archive them for at least five years.

  • Page 14: Operating Instructions

    Operating instructions Operating instructions Safety notes for the user 3.1. Explanation of safety notes In addition to the safety warnings listed, warnings are posted throughout the operating manual. These warnings are designated by an exclamation mark inside an equilateral triangle. “Warning of a dangerous situation (Attention! Please follow the documentation).”...

  • Page 15: Safety Recommendations

    FP51-SL 3.3. Safety recommendations Follow the safety instructions to avoid personal injury and property damage. Also, the valid safety instructions for workplaces must be followed. Only connect the unit to a power socket with an earthing contact (PE – protective earth)! The power supply plug serves as a safe disconnecting device from the line and must always be easily accessible.
  • Page 16 Safety notes for the user Caution: The temperature controlling i.e. of fluids in a reactor constitutes normal circulator practice. We do not know which substances are contained within these vessels. Many substances are: inflammable, easily ignited or explosive hazardous to health environmentally unsafe i.e.: dangerous The user alone is responsible for the handling of these substances!

  • Page 17: Operating Controls And Functional Elements

    FP51-SL Operating controls and functional elements Front view Rear view Mains power switch, illuminated for circulator Mains power switch, illuminated for cooling machine VFD COMFORT-DISPLAY Header: Control indicators Line 1: Actual value internal or external The display is depending on the selected control mode in the menu >...
  • Page 18 Operating controls and functional elements (providing EPROG input set to >Flow rate<) *refer to >MENU / CONFIGIGURATIO> page 35 Control indicators in the header: Heating / Cooling / Alarm / emote control Control indicators in the header: Temperature indication Internal or External actual value Temperature indication in °C or °F Display for the adjusted pump pressure stage in the -OFF- mode.
  • Page 19 FP51-SL Keypad 1 Navigation keys 1. Key: >OK< Start / Stop (pump / heater ) 2. >OK< in the menu Menu item / select submenu for setting Save set value Save selected parameter A beep signals the end of setting After the actions Start, Stop and change from VFD Display to standard display the key is locked for a short time.
  • Page 20 Socket for external measurement and control sensor or external setpoint programming ext Pt100 Interface RS232 / RS485: remote control via personal computer SERIAL Control cable of JULABO refrigerated circulator Socket: output for alarm messages Socket: Option: Electronic module Order No. 8 900 100 The circulator automatically recognizes the connected electronic module.

  • Page 21: Preparations

    FP51-SL Preparations 5.1. Installation Place the unit on an even surface on a pad made of non-flammable material. Using the castors move the unit to the intended location. For better stability, apply the holding breaks on the front casters. Cooling machine, pump motor and electronics produce intrinsic heat that is dissipated via the venting openings! Never cover these openings! Keep at least 20 cm of open space on the front and rear venting grids.
  • Page 22 Fire or other dangers when using bath fluids that are not recommended: Use only non-acidic and non-corroding bath fluids. JULABO assumes no liability for damage caused by the selection of an unsuitable bath liquid. Unsuitable bath fluids are fluids which, e.g.,...

  • Page 23: Temperature Application To External Systems

    Differing flow rates of the pressure and suction pumps should be compensated. To maintain a constant liquid level, the JULABO „D+S“ Level Adapter is recommended for the external bath tank. The flow rate of the pressure pump will be then regulated by a built-in float device.

  • Page 24: Tubing

    Preparations Backflow safety device If the liquid levels in the circulator bath and the external SERIAL ALARM STAND-BY REG+ Pt100 E-PROG system are at different heights, overflowing must be prevented after the power has been turned off. T16A T16A Flood hazard! T1.25A For this reason, solenoid valves for loop circuit or shut-off valves can be integrated in the loop circuit.

  • Page 25: Filling / Draining

    FP51-SL Avoid sharp bends in the tubing, and maintain a sufficient distance from surrounding walls. Regularly check the tubing for material defects (e.g. for cracks). Preventive maintenance: Replace the tubing from time to time. 5.4. Filling / draining Notice: Pay attention to the thermal expansion of bath oil during heating to avoid overflowing of the liquid.

  • Page 26: Operating Procedures

    Operating procedures Operating procedures 6.1. Power connection Caution: Only connect the unit to a power socket with earthing contact (PE – protective earth)! The power supply plug serves as safe disconnecting device from the line and must be always easily accessible. Never operate equipment with damaged mains power cables.

  • Page 27: Switching On The Cooling Machine

    FP51-SL Selecting the language: There are two options for the language of the LCD DIALOG-DISPLAY: German or English. Select the desired language in the menu >Configuration< under the submenu >Language/Sprache<. Press the respective keys in the following order: 3x up to menu Configuration 6x up to submenu >Language/Sprache<...

  • Page 28: Setting Of Temperatures

    Setting of temperatures Setting of temperatures Press the key to call up the menu for temperature selection. 3 different working temperatures can be adjusted. Their values are freely selectable within the operating temperature range. The temperatures can be set in start or stop mode. Setting of working temperature in the menu 1.
  • Page 29 FP51-SL SafeTemp: Setting range: 20 °C ... 320 °C Rough setting can be effected by using the temperature scale. Settings: Press the key and by pressing the key select the menu item and confirm the by pressing the key For setting proceed as follows. SafeTemp: Set the new cut-out value within 30 seconds with a screw driver.
  • Page 30 Safety installations, warning functions Depending on the setting of >ControlType - internal or external< the actual temperature values for both sensors are shown/indicated on both displays. Examples: I 94.06 Ext. : xx.xx°C Type: >Warning< or >Alarm< For the two menu items >OverTemp< and >SubTemp< choose between a warning message being signaled or a complete shutdown of the main functional elements such as heater and circulating pump being effected.
  • Page 31 FP51-SL Setting >WARNING< A mere warning function with optical and audible warning signal (interval tone) A message appears on the VFD COMFORT-DISPLAY: OverTemp SubTemp The LCD –DISPLAY shows the message: Setting >ALARM< Temperature limit with shutdown of heater and circulating pump. An audible alarm sounds (continuous tone) and a message appears on the VFD COMFORT-DISPLAY: OverTemp...

  • Page 32: Early Warning System, Low Level Protection

    Safety installations, warning functions 8.0.1. Early warning system, low level protection This low level protection is independent of the control circuit and is divided into two sections: 1. Switch in stage 1 recognizes a critical fluid level DBGM: 20306059.8 An audible warning (interval tone) sounds and a message appears on the VFD COMFORT-DISPLAY.

  • Page 33: Menu Functions

    FP51-SL Menu functions The term „menu functions“ refers to adjustments such as Menu level 1 Start program Page 35 This menu will start a previously set program. Administration and creation of programs Page 40 Electronically adjustable pump capacity Page 44 The capacity of the circulating pump is set by adjusting the motor speed.
  • Page 34 Menu functions Menu level 1 Adjustable interface parameters Page 58 BAUDRATE, PARITY, HANDSHAKE ATC - Absolute Temperature Calibration, Page 59 Sensor calibration internal sensor, Sensor calibration external sensor 3-point calibration Limitations of temperature and capacity Page 66 Setpoint Max / Min - Maximum and minimum setpoint Heating Max –...

  • Page 35: Start Of A Program

    FP51-SL 9.1. Start of a program The start menu of the integrated programmer allows one of six previously stored temperature programs to be called up and started. The profiles are started manually or via the integrated timer. Requirements: 1. Create a program. (refer to next chapter) 2.
  • Page 36 Menu functions Level 2 Parameter /Value Set desired parameters with Confirm >now< with the key and the program will start immediately start at the set time under parameter (time ). Set time in the example below: 09. August 2009, 11:15 hrs Submenu TIMER If the parameter time is selected, a further submenu opens for setting the start time.

  • Page 37: Status At The End Of A Program

    FP51-SL 9.1.1. Status at the end of a program Program end StdBy , PSetp, Setp 1, Setp 2 , Setp 3 This parameter is used to determine if the unit switches to the -OFF- condition at the end of a profile or if temperature control is continued, and the working temperature setpoint that is to be used if temperature control is continued.

  • Page 38: Interrupting A Program

    Menu functions Initiation and exit of the editing function: After the start enter the submenu „3 EDITOR“.by pressing the key See chapter „program administration, creation“ page 40 Exit the editing modus anytime by pressing the key Particularity for changes in a section that is currently in process. If the target temperature is changed, the slope of the ramp is automatically calculated based on the remaining time of the section.

  • Page 39: Interruption After A Power Failure

    FP51-SL 9.1.5. Interruption after a power failure It is possible to operate the programmer safely in case of a power failure. Important: For this, >Autostart< needs to be set in the >Configuration< menu. If the AUTOSTART function is activated, the programmer starts again at a point approx.

  • Page 40: Program Administration, Creation

    Menu functions 9.2. Program administration, creation The integrated programmer permits fast and easy programming of setpoint temperature sequences. This temperature sequence is called program. A program is composed of individual sections (Step). The sections are defined by duration (t) or Gradient (°/t) and target temperature.
  • Page 41 FP51-SL Editing PrgNr: Set the program you wish to create. 0 ... 5 SP : Setpoint TI : Time [hh:mm] or GRD: Gradient [°/t] = [°/min] Change type of program in MENU >configuration<, menu item >Programmtyp/program type< . Step 0 … 59 Press the key if a parameter is to be retained.
  • Page 42 Menu functions Delete It is possible to delete an entire program or consecutive sections Delete PrgNr: Set the program you wish to delete 0 ... 5 Delete from Step X to Step X - (0 … 59) Press the key if a parameter is to be retained. (prior to OK) Submenu >Delete<...
  • Page 43 FP51-SL Print Every program can be printed via the serial interface for control and documentation purposes. Press the key if a parameter is to be retained. (prior to OK) Submenu >Print< Level 2 Set menu item >Print PrgNr.< by pressing Set desired >PrgNr.<...

  • Page 44: Setting The Pump Pressure

    Menu functions 9.3. Setting the pump pressure The capacity of the circulating pump is set by adjusting the motor speed Press the key if a parameter is to be retained. (prior to OK) Submenu >Pump< Level 2 The set pump stage is displayed. Example: 1 Confirm by pressing Set required pump stage by pressing Example: 3...

  • Page 45: Configuration

    FP51-SL 9.4. Configuration Press the key if a parameter is to be retained. (prior to OK) Level 2 Parameter level Remote control via serial interface. Possible parameters: off / on Switch on and off remote control by pressing First set the >type< of interface (RS232 or RS485) in the MENU >INTERFACE SERIAL<...
  • Page 46 Menu functions Level 2 Parameter level Pump-Mode Possible parameters: P. on / P. off Switch on and off >Off-Mode by pressing P.on continuous operation of circulating pump P.off circulating pump is linked to Start/Stop ActVar - actuating variable Possible parameters: control, Eprog, serial Set desired parameters with Programming of variables for the parameters >...
  • Page 47 FP51-SL Level 2 Parameter level Reset Return to factory settings by pressing >Reset?< returns all set values to the factory setting except for date and time. A RESET can be effected only in the – OFF- mode. During the message >Running < all parameters are reset to factory settings.

  • Page 48: Remote Control Via The Serial Interface

    Menu functions 9.4.1. Remote control via the serial interface Setpoint is set via the serial RS232/RS485 interface through a PC or Factory setting: off superordinated data system. In the header of the VFD COMFORT-DISPLAY, an “ ” illuminates. It indicates that remote control mode is active. The selected setting is shown on the LCD DIALOG-DISPLAY.

  • Page 49: Autostart

    - Autostart off (Factory setting) Note: The circulator has been configured and delivered by JULABO according to N.A.M.U.R. recommendations. This means for the start mode that the unit must enter a safe operating state after a power failure (non- automatic start mode).

  • Page 50: Actvar - Actuating Variable

    Menu functions 9.4.5. ActVar - actuating variable The variable (ACTuating VARiable) corresponds to the extent to which the heater or cooling unit of the circulator is controlled. Heat or cold is applied to the bath according to this variable. If this happens with the control electronics of the circulator, called >...

  • Page 51: Setting Of Clock And Date

    FP51-SL 9.4.6. Setting of clock and date The internal real time clock allows starting a program any time. The clock is set to the local mean time (MEZ) at the factory. If the unit is operated in a different time zone, the clock can be adjusted in this menu.

  • Page 52: Control

    Menu functions 9.5. Control The circulator is designed for internal and external temperature control. This can be switched in this submenu. Only the set of parameters corresponding to the particular setting is displayed. Control internal Control external For external temperature control and measurement connect a Pt100 external sensor to the socket at the rear of the circulator.
  • Page 53 FP51-SL Control Type internal Parameter-Level The value flashes. Set by using the numeric keypad and confirm by pressing Example: Setting range: 0.1 … 99.9 K The value flashes. Set by using the numeric keypad and confirm by pressing Setting range: 3 … 9999 s The value flashes.

  • Page 54: Control Internal / External

    Menu functions 9.5.1. Control internal / external The control type can be adjusted in the -OFF- mode only. Possible parameters: intern internal temperature control extern external temperature control with external Pt100 sensor IMPORTANT: Additional measures for external temperature control. ext. Connect a Pt100 sensor to the socket on the rear of the circulator.

  • Page 55: Selftuning

    FP51-SL 9.5.2. Selftuning When performing a selftuning for the controlled system (temperature application system), the control parameters Xp, Tn and Tv are automatically determined and stored. Possible parameters: off - no selftuning The control parameters ascertained during the last identification are used for control purposes.

  • Page 56: Cospeed - Extern

    Menu functions 9.5.4. CoSpeed - extern CoSpeed: This parameter affects the temperature pattern only in case of external control. Possible parameters: 0 ... 5 During selftuning, the control parameters Xp, Tn, °C Int. temperature and Tv of a controlled system are automatically determined and stored.
  • Page 57 FP51-SL Optimization instructions for the PID control parameters: optimum setting The heat-up curve reveals inappropriate control °C settings. Inappropriate settings may produce the following heat-up curves: Xp too low Tv/Tn too low °C °C Xp too high or Tv too high Tv/Tn too high or Xp too high °C °C...

  • Page 58: Serial Interface

    Menu functions 9.6. Serial Interface For communication between the circulator and a PC or a superordinated Factory settings: process system, the interface parameters of both units must be identical. 4800 Baud The adjustment is usually carried out one time only in the >Interface serial< even menu.

  • Page 59: Atc Absolute Temperature Calibration, 3-Point Calibration

    FP51-SL 9.7. ATC Absolute Temperature Calibration, 3-point calibration ATC is used to compensate for a temperature difference between the circulator and a defined measuring point in the bath tank that may develop for physical reasons. internal external Principle: For ATC calibration, in steady state the bath temperature at the location Example: of the temperature sensor (CT) is determined at the respective adjusted 1-point calibration...
  • Page 60 Menu functions Press the key if a parameter is to be retained. (prior to OK) Level 2 Parameter-Level The parameter flashes, switch by pressing The parameter flashes, switch by pressing >no< Carry out an ATC calibration >yes< return to standard operation after calibration.
  • Page 61 FP51-SL The value >TmpValue< is only indicated In addition the measured temperature value >CalValue X< is saved during the next step. The value flashes. Set by using the numeric keypad and confirm by pressing If only a 2-point calibration is carried out, the following menu items are not indicated anymore The value >TmpValue<...

  • Page 62: Atc Fühler - Intern / Extern

    Menu functions 9.7.1. ATC Fühler - intern / extern In the first submenu the ATC function is set for the >intern< internal or the >extern< external temperature sensor. Calibration can be carried out for the internal temperature sensor and for the external temperature sensor connected to the socket „ext.
  • Page 63 FP51-SL 1. Set circulator to internal control: The type of control can be set only in the –OFF- mode. 2. Set working temperature setpoint 80.00 °C 120.00 °C See standard display line 1 160.00 °C Example 80.00 °C Press the keys and confirm by pressing The bath is heated up.
  • Page 64 Menu functions The value flashes. Set by using the numeric keypad and confirm by pressing Return to 2. Set working temperature value: 120.00 °C The value >TmpValue< is only indicated. In addition the measured temperature value >CalValue X< is saved during the next step.

  • Page 65: Limits

    FP51-SL 9.8. Limits The >Limits< menu allows the minimum and maximum values to be set for all important setting ranges and capacity variables. Control internal Control external Press the key if a parameter is to be retained. (prior to OK). Level 2 Parameter-level The parameter flashes.

  • Page 66: Limits For Internal Control And External Control

    Menu functions The parameter flashes. Set by using the numeric keypad and confirm by pressing The parameter flashes. Set by using the numeric keypad and confirm by pressing The parameter flashes. Set by using the numeric keypad and confirm by pressing 9.8.1.

  • Page 67: Limits For External Control

    FP51-SL 9.8.2. Limits for external control INTERN MAX / MIN Restriction for the temperature range of the internal bath. Setting range: -94,9 °C ... +300,0 °C The limits IntMax and IntMin are only active in external control. IntMax and IntMin determine fixed limits for the temperature within the internal bath.

  • Page 68: Analog Inputs/Outputs

    Menu functions 9.9. Analog inputs/outputs In order to use the analog inputs and outputs, the circulator must be equipped with the electronic module, which is available as option. Order No. 8 900 100 Electronic module ALARM STAND-BY REG+ E-PROG This submenu enables the input and output values to be set for the programmer input and the temperature recorder outputs of the REG+E- PROG socket.
  • Page 69 FP51-SL Level 2 Level 3 Parameter-level Define the output value for channel 1 Possible parameters: ActInt, ActExt, Power, Setpoint The parameter flashes, switch by pressing Select the scale for channel 1. The value flashes. Set by using the numeric keypad and confirm by pressing The value flashes.
  • Page 70 Menu functions Level 2 Level 3 Parameter-level Define the output value for channel 3 Possible parameters: ActInt, ActExt, Power, Setpoint The parameter flashes, switch by pressing Select the scale for channel 3. The value flashes. Set by using the numeric keypad and confirm by pressing The value flashes.
  • Page 71 FP51-SL Level 2 Level 3 Parameter-level Possible parameters: voltage, current The parameter flashes, switch by pressing The value flashes. Set by using the numeric keypad and confirm by pressing The value flashes Set by using the numeric keypad and confirm by pressing The value >setpoint<...

  • Page 72: Control Connector

    Menu functions Level 2 Level 3 Parameter-level Possible parameters: normal, inverse The parameter flashes, switch by pressing 9.9.1. Control connector Control connector (14): SV-Out >Backflow< or >C-Pulse< or >Refill< The control output (14) can be adapted to solenoid valves for different tasks.

  • Page 73: Outputs Of The Connector - Reg+E-Prog

    FP51-SL 9.9.2. Outputs of the connector - REG+E-PROG Outputs of the connector 1. First define the desired output value for channels 1 to 3: ActInt internal actual temperature value (bath temperature) ActExt external actual temperature value (external sensor) Power periodic or intermittent heating or cooling Setpoint active setpoint temperature (setpoint 1, 2, 3/integr.

  • Page 74: Input Of The Connector - Reg+E-Prog

    Menu functions 9.9.3. Input of the connector - REG+E-PROG E-PROG - Input Setting is necessary if Menu >Configuration< 1. the Setpoint is to be set via an external voltage or current source or programmer For this, in the menu >Configuration<, first set the menu item >Setpoint<...
  • Page 75 FP51-SL After returning the LCD display to standard display by pressing the , the temperature value adjusted and set on the external voltage or current source is displayed in line 1 (Example: Eprog 50.00 C). This EPROG input enables the use of different voltage and current values as program parameters.

  • Page 76: External Stand-By Input

    Menu functions 9.9.4. External Stand-by input Ext. StBy (External STAND-BY input) Stand-By input for external switch-off. Possible parameters: inactive - Stand-By input is ignored active - Stand-By input is active Activate the standby input: 1. Under menu item >Ext. StBy<, set the parameter to >active<. 2.

  • Page 77: Alarm-Output

    FP51-SL 9.9.5. Alarm-output Alarm output (10) (for external alarm signal) This socket is a potential-free change-over contact. With the adjustments in the menu >Inputs/Outputs<, all operating conditions can be signaled without having to change the pin assignments. Meaning of the terms under menu item >Function< : The circulator is in condition ALARM >StandBy<...

  • Page 78: Troubleshooting Guide / Error Messages

    The float is defect (e. g., because damaged in transit). Repair by authorized JULABO service personnel. During the self-test after switch-on a short-circuit is registered between pin 2 and pin 4 of the control cable or the control cable is interrupted during operation.
  • Page 79 FP51-SL Defect of the working or excess temperature sensor. The working temperature and excess temperature sensors report a temperature difference of more than 35 K. Other errors (I C-BUS errors) Error in A/D converter Excess temperature sensor is defective. The safety temperature is below the working temperature setpoint. Set the safety temperature to a higher value.
  • Page 80 Replenish the bath tank with bath fluid. After eliminating the malfunction, turn the mains power switch off and on again to cancel the alarm state. If the unit cannot be returned to operation, contact an authorized JULABO service center. Special message “CONFIGURATION ERROR”...

  • Page 81: Electrical Connections

    Electrical connections 11. Electrical connections Notice: Use shielded cables only. The shield of the connecting cable is electrically connected to the plug housing. The unit ensures safe operation if connecting cables with a maximum length of 3 m are used. The use of longer cables does not affect proper performance of the unit, however external interferences may have a negative impact on safe operation (e.g.
  • Page 82 8 900 110 USB interface adapter cable / Control output The connector may only be used for control of a JULABO refrigerated circulator or JULABO MVS Solenoid valve controller for cooling water. Pin assignment: Signal (only with attached JULABO equipment) +24 V (I max.
  • Page 83 Electrical connections Programmer input / temperature recorder output Signal 1 Voltage output Channel 1 0 ... 10 V 2 Voltage output Channel 2 0 ... 10 V 3 GND for outputs REG+E-PROG 4 Programmer input EPROG 0 to 10 V / 0 to 20 mA 5 Current output Channel 3 0 to 20 mA / 4 to 20 mA...

  • Page 84: Communication With A Pc Or A Superordinated Data System

    FP51-SL 12. Remote control 12.1. Setup for remote control 1. Check the interface parameters for both interfaces (on the circulator and PC) and make sure they match. In the >Interface< menu, set the menu item >Type< to >RS232< or SERIAL >RS485<.

  • Page 85: Remote Control

    Remote control Important times for a command transmission: To ensure secure data transfer, the time gap between two commands should be at least 250 ms. The circulator automatically responds to an in command with a data string followed by an LF (Line Feed). The next command should be sent only after 10 ms.
  • Page 86 FP51-SL Command Parameter Response of circulator OUT_MODE_03 Set external programmer input to current. Current 0 mA ... 20 mA OUT_MODE_04 Temperature control of internal bath. OUT_MODE_04 External control with Pt100 sensor. OUT_MODE_05 Stop the unit = R –OFF-. OUT_MODE_05 Start the unit. OUT_MODE_08 Set the control dynamics - aperiodic OUT_MODE_08...
  • Page 87 Remote control IN commands: Asking for parameters or temperature values to be displayed. Command Parameter Response of circulator VERSION None Version number of the software (V X.xx) STATUS none Status message, error message (see page 90) IN_PV_00 none Current bath temperature. IN_PV_01 none Heating power being used (%).
  • Page 88 FP51-SL Command Parameter Response of circulator IN_PAR_13 none Adjusted maximum internal temperature of the cascade controller. IN_PAR_14 none Adjusted minimum internal temperature of the cascade controller. IN_PAR_15 none Band limit (upper) IN_PAR_16 none Band limit (lower) IN_MODE_01 none Selected setpoint: 0 = Setpoint 1 1 = Setpoint 2 2 = Setpoint 3...

  • Page 89: Status Messages

    Remote control 12.4. Status messages Status messages Description 00 MANUAL STOP Circulator in „OFF“ state. 01 MANUAL START Circulator in keypad control mode. 02 REMOTE STOP Circulator in „r OFF“ state. 03 REMOTE START Circulator in remote control mode. 12.5. Error messages Error messages Description -01 LOW LEVEL ALARM...

  • Page 90: Error Messages

    FP51-SL Error messages Description -22 WARNING: COMPRESSOR STAGE Second-stage compressor does not work. 2 DOES NOT WORK -23 WARNING: HIGH TEMPERATURE Excess temperature at first-stage compressor. ON COMPRESSOR STAGE 1 -24 WARNING: HIGH TEMPERATURE Excess temperature at second-stage compressor. ON COMPRESSOR STAGE 2 -25 REFRIGERATOR WARNING Error in the cooling machine.

  • Page 91: Julabo Service - Online Remote Diagnosis

    JULABO Service – Online remote diagnosis 14. JULABO Service – Online remote diagnosis JULABO circulators of the HighTech series are equipped with a black box. This box is implemented in the controller and records all significant data for the last 30 minutes.

  • Page 92: Cleaning / Repairing The Unit

    The circulator is designed for continuous operation under normal conditions. Periodic maintenance is not required. The tank should be filled only with a bath fluid recommended by JULABO. To avoid contamination, it is essential to change the bath fluid from time to time.
