GOT-3156TL-830
All-in-One
15" XGA TFT Fanless Compact-Size
PANEL PC
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GOT-3156TL-830 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AXIOMTEK GOT-3156TL-830

Summary of Contents for AXIOMTEK GOT-3156TL-830

  • Page 1 GOT-3156TL-830 All-in-One 15” XGA TFT Fanless Compact-Size PANEL PC User’s Manual...
  • Page 2 AXIOMTEK does not warrant or assume any legal liability or responsibility for the accuracy, completeness or usefulness of any information in this document. AXIOMTEK does not make any commitment to update the information in this manual.

  • Page 3: Safety Approvals

    Safety Approvals CE Marking FCC Class A FCC Compliance This equipment has been tested in compliance with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are meant to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. The GOT-3156TL-830 does not come equipped with an operating system. An operating system must be loaded first before installing any software into the computer. Be sure to ground yourself to prevent static charge when installing the internal components.
  • Page 5 When handling boards and components, wear a wrist- grounding strap, available from most electronic component stores. Trademarks Acknowledgments AXIOMTEK is a trademark of AXIOMTEK Co., Ltd. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation. ® ™...

  • Page 6: Table Of Contents

    Table of Contents   Disclaimers ................ii   Safety Approvals ..............iii   Safety Precautions.............. iv CHAPTER 1 INTRODUCTION ......... 1      General Description ..........1     Specifications ............3     1.2.1 Main CPU Board ............3  ...
  • Page 7     Chipset Menu ............ 49     Exit Menu ............54 CHAPTER 4 DRIVERS INSTALLATION ..... 56      System .............. 56     Touch Screen ........... 57     4.2.1 Specification .............. 57     4.2.2 Driver Installation- Windows XP ....... 57  ...
  • Page 8 MEMO viii...

  • Page 9: Chapter 1 Introduction

    GOT-3156TL-830. Chapter 1 includes the following sections: General Description Specification Dimensions I/O Outlets Package List General Description The GOT-3156TL-830 adopts a 15-inch XGA TFT LCD with 400 ® nits brightness and an Intel Atom processor N270 1.6 GHz to provide excellent computing performance and thermal resistance.
  • Page 10 500Hz, random for 2.5” HDD) in operation mode with a patent of anti-vibration design. The patent improves the system reliability and sustainability. WLAN Antenna Supported (optional) GOT-3156TL-830 has a PCI Express Mini Card slot for optional add-ons such as wireless LAN card for 802.11 b/g connections & 3G/GPRS...

  • Page 11: Specifications

    GOT-3156TL-830 User’s Manual Specifications 1.2.1 Main CPU Board ○ Intel Atom N270 1.6GHz processor with FSB 533MHz onboard System Chipset 945GSE + ICH7M BIOS America Megatrends BIOS System Memory One 200-pin DDR2 SO-DIMM socket Maximum memory up to 2GB 1.2.2 I/O System...

  • Page 12: System Specification

    GOT-3156TL-830 User’s Manual 1.2.3 System Specification 15” XGA(1024x768) LCD with LED backlight 5 wired resistive Touch Fanless Heat Dispensing Design IP65 aluminum front bezel Disk drive housing: One 2.5” SATA drive Net Weight 5.3 Kg (11.68 lb) Dimension (Main Body Size) 396mm x 312mm x 65.9mm...

  • Page 13: Dimensions

    GOT-3156TL-830 User’s Manual Dimensions The following diagrams show the dimensions and outlines of GOT-3156TL-830. Introduction...

  • Page 14: I/O Outlets

    GOT-3156TL-830 User’s Manual I/O Outlets Please refer to the following illustration for I/O locations of the GOT- 3156TL-830. Function Function POWER SWITCH (ATX) COM 2 (RS-232) Power Input connector (phoenix type) 2 X USB 2.0 1X ETHERNET (RJ-45) COM 4 (RS-232) 2 X USB 2.0...

  • Page 15: Packing List

    GOT-3156TL-830 User’s Manual Packing List When you receive the GOT-3156TL-830, the bundled package should contain the following items: GOT-3156TL-830 unit x 1 Driver CD x1 Phoenix connector x 1 Panel mount kit x 6 Screws for HDD x 4 If you can not find the package or any items are missing, please contact AXIOMTEK distributors immediately.

  • Page 16: Chapter 2 Hardware Installation

    GOT-3156TL-830 User’s Manual CHAPTER 2 HARDWARE INSTALLATION The GOT-3156TL-830 provides rich I/O ports and flexible expansions for you to meet different demand, for example, CF card. The chapter will show you how to install the hardware. It includes: ™ CompactFlash...
  • Page 17 GOT-3156TL-830 series User’s Manual Step 2 Remove the back cover. Hardware Installation...

  • Page 18: Cf Card Installation

    GOT-3156TL-830 User’s Manual CF card Installation The GOT-3156TL-830 provides one CF slot for users to install ™ CompactFlash card. Please refer to the following instructions for installation: Step 1 Unscrew two screws on the cover of CF card slot on right side of GOT.

  • Page 19: Serial Ports Interface

    GOT-3156TL-830 series User’s Manual Serial Ports Interface The GOT-3156TL-830 has four serial ports. COM1 is RS-232/422/485, while COM2, COM3, and COM4 are RS-232. The following table shows you the pin assignments of this connector: Signal Signal Data Carrier Detect (DCD)
  • Page 20 GOT-3156TL-830 User’s Manual When COM1 is set to RS-422 or RS-485, the pin assignments are listed below: Signal Name Pin # RS-422 RS-485 DATA- DATA+ No connector No connector No connector No connector No connector No connector No connector No connector...

  • Page 21: Ethernet

    GOT-3156TL-830 series User’s Manual Ethernet The GOT-3156TL-830 is equipped with a high performance Plug and Play Ethernet interface, full compliant with IEEE 802.3 standard, and can be connected with a RJ-45 LAN connector. Please refer to detailed pin assignment list below:...

  • Page 22: Mountings: Panel / Wall / Desktop / Vesa

    There are 4 application options for the GOT-3120T/3128T, Panel/Wall/Desktop/VESA mountings. 2.4.1 VESA-ARM/Wall-Mount The GOT-3156TL-830 provides two ways for VESA mount: 75x75 mm and 100x100 mm. Screw four screws to fix the kit (optional) in the back chassis. 2.4.2 Desktop Kit Assembly The GOT-3156TL-830 is designed for desktop application.

  • Page 23: Panel-Mount Kit Assembly

    Screw 4 screws to fix the kit (Optional) in the side chassis. 2.4.3 Panel-mount Kit Assembly The GOT-3156TL-830 is designed for panel mount application. To mount the GOT-3156TL-830, the standard set of mounting kit (included in the system packaging) is needed. Hardware Installation...

  • Page 24: Hdd Installation

    GOT-3156TL-830 User’s Manual HDD Installation The GOT-3156TL-830 provides a convenient Hard Disk Drive (HDD) bracket for users to install 2.5” SATA HDD. Please follow the steps: Step 1 Refer section 2.1 to open the back cover. Step 2 Unscrew 4 screws to take off the HDD bracket.
  • Page 25 GOT-3156TL-830 series User’s Manual Step 4 Fix the HDD bracket into the system, and plug the data and power cable to HDD. Installation completes. Data Data Power Hardware Installation...

  • Page 26: Dram Installation

    GOT-3156TL-830 User’s Manual DRAM Installation The GOT-3156TL-830 provides one 200-pin DDR2 SODIMM socket that support system memory up to 2GB. Please follow steps below to install the memory modules: Step 1 Refer to section 2.1 to open the back cover and find out DIMM socket on mainboard (SBC87830).
  • Page 27 GOT-3156TL-830 series User’s Manual Step 3 Installation completes. Hardware Installation...

  • Page 28: Wireless Lan Card Installation

    GOT-3156TL-830 User’s Manual Wireless LAN Card Installation The GOT-3156TL-830 provides one Mini card slot for user to install one wireless LAN card. When installing the wireless LAN card, refer to the following instructions and illustration: Step 1 Refer to section 2.1 to open the back cover and find out mini-card slot on mainboard.
  • Page 29 GOT-3156TL-830 series User’s Manual Step 4 Remove the antenna plug from the top of back cover. Step 5 Install the antenna on the antenna connector. Hardware Installation...

  • Page 30: Power

    GOT-3156TL-830 User’s Manual Power GOT-3126TL-830 equips with a phoenix type power connector. It adopts 12VDC or 24VDC. Please follow the signs on power connector to connect DC power source. Power positive Safty ground －: Power negative Note: The safty ground must be connected to ensure the uiit working appropriately.
  • Page 31 GOT-3156TL-830 series User’s Manual MEMO Hardware Installation...

  • Page 32: Chapter 3 Ami Bios Setup Utility

    GOT-3156TL-830 User’s Manual CHAPTER 3 AMI BIOS SETUP UTILITY This chapter provides users with detailed description how to set up basic system configuration through the AMI BIOS setup utility. Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del> key immediately.

  • Page 33: Main Menu

    GOT-3156TL-830 series User’s Manual The <F10> key allows you to save any changes you have made and exit Setup. Press the <F10> key to save your changes. The <Esc> key allows you to discard any changes you have made and exit the Setup. Press the <Esc>...

  • Page 34: Advanced Menu

    GOT-3156TL-830 User’s Manual System Time or System Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time is entered in HH:MM:SS format.
  • Page 35 GOT-3156TL-830 series User’s Manual Configure advanced CPU settings This screen shows the CPU Configuration, and you can change the value of the selected option. Max CPUID Value Limit You can enable this item to let legacy operating systems boot even without support for CPUs with extended CPU ID functions.
  • Page 36 GOT-3156TL-830 User’s Manual Use this item to enable or disable the C-State technology. Enhanced C-States This item allows you to enable or disable any available enhanced C-states ( C1E, C2E, C3E, C4E and Hard C4E). IDE Configuration You can use this screen to select options for the IDE Configuration, and change the value of the selected option.
  • Page 37 GOT-3156TL-830 series User’s Manual installed in the system by pressing <Enter> for more options. SuperIO Configuration You can use this screen to select options for the SuperIO Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 38 GOT-3156TL-830 User’s Manual Serial Port2 IRQ This item specifies the IRQ used by the serial port 2. Serial Port3 Address This item specifies the base I/O port address and Interrupt Request address of serial port 3. Serial Port3 IRQ This item specifies the IRQ used by the serial port 3.
  • Page 39 GOT-3156TL-830 series User’s Manual Hardware Health Configuration This screen shows the Hardware Health Configuration, and a description of the selected item appears on the right side of the screen. System Temperature/CPU Temperature These items display the temperature of CPU and System, Vcore, etc.
  • Page 40 GOT-3156TL-830 User’s Manual ACPI Settings You can use this screen to select options for the ACPI Settings, and change the value of the selected option. A description of the selected item appears on the right side of the screen. AMI BIOS Setup Utility...
  • Page 41 GOT-3156TL-830 series User’s Manual APM Configuration You can use this screen to select options for the APM Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 42 GOT-3156TL-830 User’s Manual expired. The default setting is Suspend. This setting prevents the BIOS from initiating Disabled any power saving modes concerned with the video display or monitor. This option places the monitor into suspend mode after the specified period of display inactivity has expired.
  • Page 43 GOT-3156TL-830 series User’s Manual default setting is On/Off. Pushing the power button turns the computer On/Off on or off. This is the default setting. This is the default setting. Pushing the power button places the computer Suspend in Suspend mode or Full On power mode.
  • Page 44 GOT-3156TL-830 User’s Manual MPS Configuration This screen shows the MPS (Multi Processor Specification) Configuration, and you can change its value. A description of the selected item appears on the right side of the screen. MPS Revision Use this item to select MPS (Multi Processor Specification) Revision 1.1 or 1.4.
  • Page 45 GOT-3156TL-830 series User’s Manual PCI Express Configuration This screen shows the PCI Express Configuration, and you can change its value. A description of the selected item appears on the right side of the screen. Active State Power-Management Use this item to enable or disable the function of Active State Power-Management to provide you with lower power consumption.
  • Page 46 GOT-3156TL-830 User’s Manual USB Configuration You can use this screen to select options for the USB Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen. Legacy USB Support Use this item to enable or disable support for USB device on legacy operating system.

  • Page 47: Pci Pnp Menu

    GOT-3156TL-830 series User’s Manual PCI PnP Menu The PCI PnP menu allows users to change the advanced settings for PCI/PnP devices. AMI BIOS Setup Utility...
  • Page 48 GOT-3156TL-830 User’s Manual Clear NVRAM Use this item to clear the data in the NVRAM (CMOS). Here are the options for your selection, No and Yes. Plug & Play O/S When the setting is No, Use this item to configure all the devices in the system.
  • Page 49 GOT-3156TL-830 series User’s Manual and Yes. Palette Snooping Some old graphic controllers need to “snoop” on the VGA palette, and then map it to their display as a way to provide boot information and VGA compatibility. This item allows such snooping to take place. Here are the options for your selection, Disabled and Enabled.

  • Page 50: Boot Menu

    GOT-3156TL-830 User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. You can select any of the items in the left frame of the screen to go to the sub menus: Boot Settings Configuration...
  • Page 51 GOT-3156TL-830 series User’s Manual Boot Settings Configuration Quick Boot Enabling this item lets the BIOS skip some power on self tests (POST). The default setting is Enabled. Quiet Boot Set this item to allow the computer system Disabled to display the POST messages.
  • Page 52 GOT-3156TL-830 User’s Manual IRQ. Here are the options for your selection, Auto, Enabled and Disabled. Wait For ‘F1’ If Error If this item is enabled, the system waits for the F1 key to be pressed when error occurs. The default setting is Enabled.
  • Page 53 GOT-3156TL-830 series User’s Manual Removable Drives Use this screen to view the removable drives in the system. The BIOS will attempt to arrange the removable drive boot sequence automatically. You can also change the booting sequence. AMI BIOS Setup Utility...
  • Page 54 GOT-3156TL-830 User’s Manual Lan Boot Settings Configuration The Lan Boot Settings Configuration can enable or disable Lan Boot ROM to allow the system boot on LAN. AMI BIOS Setup Utility...

  • Page 55: Security Menu

    GOT-3156TL-830 series User’s Manual Security Menu The Security menu allows users to change the security settings for the system. Supervisor Password This item indicates whether a supervisor password has been set. If the password has been installed, Installed displays. If not, Not Installed displays.
  • Page 56 GOT-3156TL-830 User’s Manual menu. You can use the sub menu to change the user password. Boot Sector Virus Protection This option is near the bottom of the Security Setup screen. The default setting is Disabled. Set this item to prevent the Boot Sector Virus Disabled Protection.

  • Page 57: Chipset Menu

    GOT-3156TL-830 series User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: North Bridge Configuration South Bridge Configuration For items marked with “...
  • Page 58 GOT-3156TL-830 User’s Manual North Bridge Configuration DRAM Frequency This item allows you to control the Memory Clock. Configure DRAM Timing by SPD This item can enable or disable DRAM timing by SPD (Serial Presence Detect) device, which is a small EEPROM chip on...
  • Page 59 GOT-3156TL-830 series User’s Manual AMI BIOS Setup Utility...
  • Page 60 GOT-3156TL-830 User’s Manual South Bridge Configuration AMI BIOS Setup Utility...
  • Page 61 GOT-3156TL-830 series User’s Manual USB Function This item allows you to enable or disable USB function. USB 2.0 Controller This item allows you to enable or disable the USB 2.0 controller. Audio Controller This item allows you to enable or disable the audio support.

  • Page 62: Exit Menu

    GOT-3156TL-830 User’s Manual This item allows you to set or disable the PCI Express Ports. Exit Menu The Exit menu allows users to load your system configuration with optimal or failsafe default values 0 Save Changes and Exit When you have completed the system configuration...
  • Page 63 GOT-3156TL-830 series User’s Manual Use this item to abandon all changes. Load Optimal Defaults It automatically sets all Setup options to a complete set of default settings when you select this option. The Optimal settings are designed for maximum system performance, but may not work best for all computer applications.

  • Page 64: Chapter 4 Drivers Installation

    GOT-3156TL-830 User’s Manual CHAPTER 4 DRIVERS INSTALLATION System GOT-3156TL-830 supports Windows XP. To facilitate the installation of system driver, please carefully read the instructions in this chapter before start installing. Insert Driver CD and select the “\Drivers”. Select all files and follow the installing procedure.

  • Page 65: Touch Screen

    Active: 24.6mA / Idle Mode: 13.4mA 4.2.2 Driver Installation- Windows XP The GOT-3156TL-830 provides a touch screen driver that users can install it under the operating system Windows XP. To facilitate installation of the touch screen driver, you should read the instructions in this chapter carefully before you attempt installation.
  • Page 66 GOT-3156TL-830 User’s Manual Click Start menu and select “PenMount Utilities”; and then, a “PenMount Control Panel” pops out. Installation of Drivers...
  • Page 67 GOT-3156TL-830 series User’s Manual Select the “Standard Calibrate” tab. Calibration: To adjust the display with touch panel, click “Calibration” and follow the calibrate point to do calibration; there are five points on screen for calibration. Press OK. Installation of Drivers...

  • Page 68: Embedded O.s

    GOT-3156TL-830 User’s Manual Embedded O.S. The GOT-3156TL-830 provides the Windows XP Embedded and Windows CE.Net 6.0. The O.S. is supported devices which are listed below. 4.3.1 Windows XP Embedded Here are supported onboard devices: Onboard Multi I/O SATA HDD PS2 Keyboard and mouse...
