Summary of Contents for AXIOMTEK GOT315W-521-PCT

  • Page 1 GOT315W-521-PCT All-in-One 15.6” WXGA TFT Fanless PCT Multi-Touch PANEL PC User’s Manual...

  • Page 2: Disclaimers

    Axiomtek does not make any commitment to update any information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any forms or by any means, electronic, mechanical, photocopying, recording, among others, without prior written permission from Axiomtek Co., Ltd.

  • Page 3: Safety Precautions

    Most electronic components are sensitive to static electrical charge. Disconnect the power cord from the GOT315W-521-PCT series prior to any installation. Be sure both the system and all external devices are turned off. Sudden surge of power could ruin sensitive components. Make sure the GOT315W-521-PCT Series is properly grounded.

  • Page 4: Table Of Contents

    Table of Contents Disclaimers ..................... ii Safety Precautions ..................iii Section 1 Introduction ..........1 General Descriptions ................1 Specifications ..................2 Dimensions and Outlines ..............4 I/O Outlets .................... 6 Packing List ..................7 Section 2 Hardware and Installation ...... 9 Board Layout ..................
  • Page 5 3.4.1 System Agent (SA) Configuration ..............31 Security Menu ..................35 Boot Menu ..................36 Save & Exit Menu ................38 Section 4 Driver and Installation ......41 Operating System ................41 4.1.1 Driver CD Content ..................41 Touch Screen ..................42 Appendix A Watchdog Timer ........
  • Page 6 This page is intentionally left blank.

  • Page 7: Introduction

     Packing List General Descriptions The GOT315W-521-PCT adopts a 15.6-inch WXGA TFT LCD with 400-nit brightness and support the 8th Gen Intel® Core® Processor Coffee Lake-S i5-8500T(Tj 100°C) or GS5400T(Tj 100/88°C), up to 35W, providing excellent computing performance and thermal resistance.

  • Page 8: Specifications

     WLAN antenna supported (optional) The GOT315W-521-PCT comes with 2 Mini Card slots as an add-on option to connect a wireless LAN card under 802.11 a/b/g/n protocols, or with other 3G/GPRS applications, etc. These slots also come with 3 optional fixed rotational WLAN/3G antennas for wireless network connection.
  • Page 9 GOT315W-521-PCT User’s Manual  Expansion  1 x M.2 Key E slot  1 x Full size Mini-card slot  Storage 1 x 2.5” wide temperature SATA HDD/SSD (support 7mm and 9.5mm, removable)   Power connector  1x Phoenix power connector for DC power input System Specifications ...

  • Page 10: Dimensions And Outlines

    GOT315W-521-PCT User’s Manual Dimensions and Outlines Below shows the dimensions and outlines of the front panel of the GOT315W-521-PCT Front dimensions: 396.8 mm (15.6") (W) x 53 mm (2.08") (D) x 247.1 mm (9.73") (H) Introduction...
  • Page 11 GOT315W-521-PCT User’s Manual Diagram 1-2 Back outline of the GOT315W-521-PCT Diagram 1-3 Cutting-out dimensions of the GOT315W-521-PCT Cut out dimensions: 385.6 x 236.9 mm NOTE: The limited of wall depth is 9 mm in panel mount. Introduction...

  • Page 12: I/O Outlets

    GOT315W-521-PCT User’s Manual I/O Outlets Please refer to Figures 1-2 and 1-3 for I/O locations of the GOT315W-521-PCT. Figure 1-2 Bottom view of the GOT315W-521-PCT Note. Note. Power button 2x USB3.0 Phoenix Small type connector 2x RJ-45 for Giga Ethernet...

  • Page 13: Packing List

    A complete bundled package should contain the following items:  GOT315W-521-PCT unit x 1  Driver CD x1  Phoenix connector (DC power version only)  Panel mount kit Please contact an Axiomtek distributor immediately if any of the above-mentioned items is missing. Introduction...
  • Page 14 GOT315W-521-PCT User’s Manual This page is intentionally left blank. Introduction...

  • Page 15: Hardware And Installation

    GOT315W-521-PCT User’s Manual Section 2 Hardware and Installation The GOT315W-521-PCT provides rich I/O ports and flexible expansion for users to meet different demands. This Section describes hardware installation, including the following subsections:  Board Layout  Jumper and Connector Setting ...

  • Page 16: Jumper And Connector Settings

    Diagram 2-1 illustrates how to set up a jumper. Diagram 2-1 Definitions of pin settings Before applying power to GOT315W-521-PCT, please make sure all of the jumpers and connectors are in default position as listed in Table 2-1. NOTE: Once the default jumper setting needs to be changed, please do it under power-off condition.

  • Page 17: Auto Power On Jumper (Jp6)

    GOT315W-521-PCT User’s Manual 2.2.2 Auto Power On Jumper (JP6) If JP6 is enabled for power input, the system will be automatically power on without pressing soft power button. If JP7 is disabled for power input, it is necessary to manually press soft...

  • Page 18: Ethernet Connector

    GOT315W-521-PCT User’s Manual Ethernet Connector There are two RJ-45 connectors, LAN1 and LAN2, inside the GOT315W-521-PCT. Ethernet connection can be established by plugging one end of the Ethernet cable into this RJ-45 connector and the other end (phone jack) to a 1000/100/10-Base-T hub.

  • Page 19: Mounting Methods

    There are four ways to install the GOT315W-521-PCT, namely: panel/ VESA/ wall/ desktop mount. The GOT315W-521-PCT provides a standard panel mount kit. It can be installed by way of panel mount (see Figure 2-1, 2-2). Figure 2-1 Panel mount (back chassis)
  • Page 20 GOT315W-521-PCT User’s Manual Alternatively, the GOT315W-521-PCT can be installed by way of VESA mount which is in the dimensions of 100x100 mm. Simply fix four screws to fasten the kit from the back chassis, as shown in Diagram 2-3. Additionally, users can otherwise go for wall mount as an option, as shown in Diagram2-4.

  • Page 21: Hardware Installation

    GOT315W-521-PCT User’s Manual Hardware Installation 2.5.1 Installing a HDD The GOT315W-521-PCT provides a convenient swappable Hard Disk Driver (HDD) bracket for users to install a 2.5”(support 7mm & 9.5mm ) wide temperature SATA HDD. Please follow the steps: Step 1 Refer to Section 2.1 to open the back cover Step 2 Unfastening the screw to slide open.

  • Page 22: Installing A Dram

    GOT315W-521-PCT User’s Manual 2.5.2 Installing a DRAM The GOT315W-521-PCT provides one 260-pin DDR4 2133/2440Mhz SO-DIMM socket that supports system memory up to 32GB. Please follow steps below to install a memory module: Step 1 Refer to Section 2.1 to open the back cover.

  • Page 23: Installing A Cpu

    GOT315W-521-PCT User’s Manual 2.5.3 Installing a CPU The CPU socket type on main board that support 8th Gen Intel® Core™ processor up to 35W Coffee Lake-S i5-8500T Tj 100°C Coffee Lake-S G5400T Tj 100/88°Cr Step 1 Move the iron bar...

  • Page 24: Connecting The Power Input

    GOT315W-521-PCT User’s Manual 2.5.4 Connecting the Power Input The GOT315W-521-PCT is equipped with a Phoenix type of power connector which adopts 24VDC. Please follow the signs on the power connector to connect DC power source (see Figure 2-16). Figure 2-16 Power connector －:Power negative...

  • Page 25: Ami Bios Setup Utility

    GOT315W-521-PCT User’s Manual Section 3 AMI BIOS Setup Utility This Section provides users with detailed descriptions about how to set up basic system configurations through the AMI BIOS setup utility. Navigation Keys The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot keys can be used at any time during the setup navigation process.

  • Page 26: Main Menu

    GOT315W-521-PCT User’s Manual Main Menu When you first enter the setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below.

  • Page 27: Advanced Menu

    GOT315W-521-PCT User’s Manual Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus ►...

  • Page 28: It8625 Super Io Configuration

    GOT315W-521-PCT User’s Manual 3.3.1 IT8625 Super IO Configuration You can use this screen to select options for the Super IO Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 29 GOT315W-521-PCT User’s Manual  Serial Port 2 Configuration Serial Port Enable or disable serial port 2. The optimal setting for base I/O address is 2F8h and for interrupt request address is IRQ3 AMI BIOS Setup Utility...

  • Page 30: Hardware Monitor

    GOT315W-521-PCT User’s Manual 3.3.2 Hardware Monitor Below shows a screen reflecting the health status of the hardware in real time. This screen displays the temperature of system and CPU, cooling fans speed in RPM and system voltages (VCC_CPU, +3.3V, +12V, +5V, +5V standby ,+3.3V standby and VBAT).

  • Page 31: Trusted Computing

    GOT315W-521-PCT User’s Manual 3.3.3 Trusted Computing This screen provides function for specifying the TPM settings. Security Device Support Enable or disable BIOS support for security device. OS will not show security device. TCG EFI protocol and INT1A interface will not be available.
  • Page 32 GOT315W-521-PCT User’s Manual ® PTT: Intel built-in TPM. Pending operation Schedule an operation for the security device, see image below. None TPM Clear: Clear all data secured by TPM. AMI BIOS Setup Utility...

  • Page 33: Acpi Setting

    GOT315W-521-PCT User’s Manual 3.3.4 ACPI Setting ACPI Sleep State When the suspend button is pressed, the ACPI (Advanced Configuration and Power Interface) sleep state is S3 (Suspend to RAM). AMI BIOS Setup Utility...

  • Page 34: Cpu Configuration

    GOT315W-521-PCT User’s Manual 3.3.5 CPU Configuration Intel (VMX) Virtualization Technology Enable or disable Intel Virtualization Technology. When enabled, a VMM (Virtual Machine Mode) can utilize the additional hardware capabilities. It allows a platform to run multiple operating systems and applications independently, hence enabling a single computer system to work as several virtual systems.

  • Page 35: Sata Configuration

    GOT315W-521-PCT User’s Manual 3.3.6 SATA Configuration This screen allows users to select options for SATA Configuration, and change the value of the selected option. SATA Controller Highlight this item to set up SATA Controller to be Enable or Disable. SATA Mode Selection Determine how SATA controller(s) operate.

  • Page 36: Pch-Fw Configuration

    GOT315W-521-PCT User’s Manual 3.3.7 PCH-FW Configuration This screen displays ME Firmware information. 3.3.8 USB Configuration Display all detected USB devices. AMI BIOS Setup Utility...

  • Page 37: Chipset Menu

    GOT315W-521-PCT User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus: ► System Agent (SA) Configuration ►...
  • Page 38 GOT315W-521-PCT User’s Manual Graphics Configuration Primary IGFX Boot Display Select the video device which will be activated during POST (Power-On Self Test). The secondary boot display selection will appear based on your selection. Secondary IGFX Boot Display After selecting other than “AUTO” on “Primary IGFX Boot Display”, the Secondary IGFX Boot...
  • Page 39 GOT315W-521-PCT User’s Manual LVDS Control Enable or disable LVDS Control. When installing Linux OS and if DP, HDMI or VGA display is connected to your system, make sure to set this option to Disabled. LVDS Panel Type Select the appropriate LVDS panel resolution; see the selection options in image above.
  • Page 40 GOT315W-521-PCT User’s Manual Memory Configuration This screen shows the system memory information. PCH-IO Configuration This screen allows you to set PCH parameters. PCH LAN Controller Enable or disable onboard PCH LAN controller. Wake on LAN Enable After enabling PCH LAN Controller, enabling or disabling integrated LAN to wake the system.

  • Page 41: Security Menu

    GOT315W-521-PCT User’s Manual Security Menu The Security menu allows users to change the security settings for the system.  Administrator Password Set administrator password.  User Password Set user password. Figure 3-15 Security Menu AMI BIOS Setup Utility...

  • Page 42: Boot Menu

    GOT315W-521-PCT User’s Manual Boot Menu  Setup Prompt Timeout Number of seconds to wait for setup activation key. 65535(0xFFFF) means indefinite waiting.  Bootup NumLock State Use this item to select the power-on state for the keyboard NumLock.  Quiet Boot Select to display either POST output messages or a splash screen during boot-up.
  • Page 43 GOT315W-521-PCT User’s Manual  Launch UEFI PXE OpROM policy Control the execution of UEFI PXE OpROM. When enabled, you may select I219, I211 or Disabled as PXE LAN port.  Boot Option Priorities These are settings for boot priority. Specify the boot device priority sequence from the available devices.

  • Page 44: Save & Exit Menu

    GOT315W-521-PCT User’s Manual Save & Exit Menu The Save & Exit menu allows users to load your system configuration with optimal or fail-safe default values. Figure 3-17 Save & Exit Menu  Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and return to Main Menu.
  • Page 45 GOT315W-521-PCT User’s Manual  Discard Changes Select this option to quit Setup without making any permanent changes to the system configuration. Select Discard Changes from the Save & Exit menu and press <Enter>. Select Yes to discard changes.  Restore Defaults It automatically sets all Setup options to a complete set of default settings when you select this option.
  • Page 46 GOT315W-521-PCT User’s Manual This page is intentionally left blank. AMI BIOS Setup Utility...

  • Page 47: Driver And Installation

    Section 4 Driver and Installation Operating System The GOT315W-521-PCT is compatible with operating systems Windows 10 and Windows 10 IoT Enterprise. To facilitate the installation of system drivers, please carefully read the instructions in this Section before any of such installation.

  • Page 48: Touch Screen

    GOT315W-521-PCT User’s Manual Touch Screen The GOT315W-521-PCT is designed based on the technology of projected capacitive multi-touch screen of which specifications are listed below. The touch driver will be installed automatically and can drive the touch panel to get two fingers touch function that based on the Windows 10 and Windows 10 IoT Enterprise support.

  • Page 49: Appendix A Watchdog Timer

    GOT315W-521-PCT User’s Manual Appendix A Watchdog Timer About Watchdog Timer Software stability is major issue in most application. Some embedded systems are not watched by human for 24 hours. It is usually too slow to wait for someone to reboot when computer hangs.
  • Page 50 GOT315W-521-PCT User’s Manual This page is intentionally left blank. Watchdog Timer...

  • Page 51: Appendix B Iamt Settings

    GOT315W-521-PCT User’s Manual Appendix B iAMT Settings Utilizing built-in platform capabilities and popular third-party management and security ® ® applications, the Intel Active Management Technology (Intel iAMT) has significantly lowered a major barrier to IT management efficiency, helping IT professionals discover, repair and better protect their networked computing assets.
  • Page 52 GOT315W-521-PCT User’s Manual You will be asked to change the password before setting ME. You must confirm your new password while revising. The new password must consist of eight characters, including at least:  One upper case  One lower case ...

  • Page 53: Iamt Settings

    GOT315W-521-PCT User’s Manual B.3 iAMT Settings ® Select Intel iAMT configuration and press <Enter>. Select Network Setup to configure iAMT. iAMT Settings...
  • Page 54 GOT315W-521-PCT User’s Manual Select TCP/IP to get into Network interface and set it to Enabled. Get into DHCP Mode and set it to Disabled. iAMT Settings...
  • Page 55 GOT315W-521-PCT User’s Manual If DHCP Mode is disabled, set the following settings:  IP address  Subnet mask ® Go back to Intel iAMT Configuration, then select Activate Network Access and press <Enter>. Exit from MEBx after completing the iAMT settings.

  • Page 56: Iamt Web Console

    GOT315W-521-PCT User’s Manual B.4 iAMT Web Console On a web browser, type http://(IP ADDRESS):16992, which connects to iAMT Web. Example: http://10.1.40.214:16992 To log on, you will be required to type in username and password for access to the Web. USER: admin (default value)
  • Page 57 GOT315W-521-PCT User’s Manual Enter the iAMT Web. Click Remote Control, and select commands on the right side. When you have finished using the iAMT Web console, close the Web browser. iAMT Settings...
  • Page 58 GOT315W-521-PCT User’s Manual This page is intentionally left blank. iAMT Settings...

  • Page 59: Appendix Ctpm Settings

    GOT315W-521-PCT User’s Manual Appendix C TPM Settings 1. Setup BitLocker Drive Encryption main storage. Press <Win + R> and type “Control Panel”, then select BitLocker Drive Encryption. TPM Settings...
  • Page 60 GOT315W-521-PCT User’s Manual 2. Insert an external storage device, for example USB Storage. Back up BitLocker recovery key in a new file and save it to the USB Storage. TPM Settings...
  • Page 61 GOT315W-521-PCT User’s Manual 3. Please follow the steps below to encrypt your storage device: TPM Settings...
  • Page 62 GOT315W-521-PCT User’s Manual Now, the system prompts that the operating system drive encryption is in progress, and the encryption progress is checked. TPM Settings...
  • Page 63 GOT315W-521-PCT User’s Manual Select and click the icon in the lower right corner to complete the encryption. TPM Settings...
  • Page 64 GOT315W-521-PCT User’s Manual 4. Confirm the completion of encryption. TPM Settings...
  • Page 65 GOT315W-521-PCT User’s Manual 5. Disable TPM function in BIOS Setup Utility. 6. When the system is powered on and you see the following screen, it means the TPM module function is working fine. Note that BitLocker cannot be executed if your system does not have TPM function.
  • Page 66 GOT315W-521-PCT User’s Manual NOTE: System with no TPM function support is as below: TPM information is not found in Device Manager. When trying to turn on Bitlocker, the following error message shows up. TPM Settings...
