I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Automated Dual Vertical Door System
This device complies with part 15 of the FCC rules. Operation is subject to the following 2 conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio or television
communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment to an outlet on a circuit other than that to which the receiver is connected
Consult the dealer or and experienced radio/TV technician for help
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
CM6DV SERIES

Advertisement

loading
Need help?

Need help?

Do you have a question about the CM6DV SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CHIEF CM6DV SERIES

  • Page 1 Increase the separation between the equipment and receiver • Connect the equipment to an outlet on a circuit other than that to which the receiver is connected Consult the dealer or and experienced radio/TV technician for help Istruzioni di installazione Installatie-instructies Instructions d´installation CM6DV SERIES...
  • Page 2: Important Warnings And Cautions

    CM6DV SERIES CSAV, Inc., and its affiliated corporations and subsidiaries (collectively, "CSAV"), intend to make this manual accurate and complete. However, CSAV makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product.
  • Page 3: Tools Required For Installation

    ..., when the doors are in motion. Installation Requirements • 115VAC power at installation site • Doors must be made of a non warping material. TOOLS REQUIRED FOR INSTALLATION PARTS (A) x1 (B) x1 (with motor) (C) x1 (D) x1 (E) x1 CM6DV SERIES (F) x2...
  • Page 4: Assembly And Installation

    CM6DV SERIES ASSEMBLY AND INSTALLATION Installation Scribe center line of cabinet opening on both front edges of cabinet sides. (See figure 1) Screw motor drive side track to left side of cabinet, keeping track even with front edge of cabinet, and aligning scribed center line on track with center line of cabinet.
  • Page 5 Installation Instructions CM6DV SERIES Figure 2...
  • Page 6 CM6DV SERIES Installation Instructions Figure 3...
  • Page 7 Insert plug from the power supply into the jack on the top of the motor box. 24VDC Input Top of Cabinet Front of Cabinet Figure 5 Plug Powercord into 115VAC outlet. IMPORTANT ! : A quality surge protection device is recommended. Make sure nothing is obstructing movement of doors, CM6DV SERIES...
  • Page 8 CM6DV SERIES Press and release the Activator Button on the front of the Motor Box or the "Close Door button on the Remote Control. (The doors should travel to the fully closed position) Activator Figure 6 Press the "Open Door" button on the Remote Control.
  • Page 9 Control Input on Front of Motor Box Control Input Figure 10 NOTE: Making a momentary dry contact closure between the common and the open, closed, stop, or sequence will activate the system in that mode. Control Input on Front of Motor Box Figure 11 CM6DV SERIES...
  • Page 10 CM6DV SERIES 8820-000020 2007 Chief Manufacturing www.chiefmfg.com 03/07 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 F +31 (0)40 2668615...
