- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Elite Roll Top Desk Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description ERT-ST...
-
Page 2: Important Safety Instructions
ACCESSORY: AN ACCESSORY is the secondary Chief product which is attached to a primary Chief product, and may have a component attached or setting on it. WARNING: Use this rack only for its intended use as... -
Page 3: Tools Required For Installation
Installation Instructions ERT-ST DIMENSIONS 1.98 50.4 2.06 52.4 1.38 34.9 0.50 12.7 DETAIL A 1.11 SCALE 1 : 8 28.2 0.88 22.2 NOTE: AREA UNDER THE ROLLTOP 9.38" X 20.00" X 45.25" WITH AN ADDITIONAL 6.00" UNDER THE FRONT ARC 48.00... - Page 4 ERT-ST Installation Instructions ASSEMBLY Set ERT desk (A) on its side. Use sixteen 1/4-20 x 1" hex head tapping bolts (C), sixteen 1/4" washers (E) and sixteen 1/4-20 lock nuts (D) to secure four casters (B) to ERT desk (A). (See Figure 2) Set ERT desk upright and install components as desired.
- Page 5 Installation Instructions ERT-ST...
- Page 6 ERT-ST Installation Instructions...
- Page 7 Installation Instructions ERT-ST...
