- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Installationsanleitung Instruções de Instalação Istruzioni di installazione Installatie-instructies Instructions d´installation Medium Flat Panel Wall Mount Spanish Product Description German Product Description Portuguese Product Description...
-
Page 2: Important Warnings And Cautions
J-Series DISCLAIMER Milestone AV Technologies, Inc., and its affiliated corporations and subsidiaries, intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product. - Page 3 Installation Instructions DIMENSIONS 300.97 11.85 152.40 6.00 3.94 3.94 292.47 11.51 215.36 8.48 516.87 20.35 215.90 215.90 8.50 8.50 152.40 6.00 332.93 13.11 80.36 3.16 175.87 6.92 307.72 12.11 81.77 3.22 68.25 231.52 9.11 3.94 373.33 14.70 J-Series 81.77 3.22 139.62 5.50 120.65...
- Page 4 Installation Instructions LEGEND Tighten Fastener Apretar elemento de fijación Befestigungsteil festziehen Apertar fixador Serrare il fissaggio Bevestiging vastdraaien Serrez les fixations Loosen Fastener Aflojar elemento de fijación Befestigungsteil lösen Desapertar fixador Allentare il fissaggio Bevestiging losdraaien Desserrez les fixations Phillips Screwdriver Destornillador Phillips Kreuzschlitzschraubendreher Chave de fendas Phillips...
-
Page 5: Tools Required For Installation
J-Series TOOLS REQUIRED FOR INSTALLATION 1/8" PARTS Interface Bracket (Including Hardware) ITEM DESCRIPTION PIVOT PITCH WALL MOUNT SINGLE ARM WALL MOUNT DUAL ARM WALL MOUNT J-SERIES WALL PLATE CABLE MANAGEMENT COVER HEX HEAD LAG SCREW, 3/8" X 3" PHILLIPS FLAT MACHINE SCREW, 8-32 X 3/8" Table 1: Parts Installation Instructions QUANTITY By... - Page 6 J-Series INSTALLATION WARNING: FAILURE TO PROVIDE ADEQUATE STRUCTURAL STRENGTH FOR THIS MOUNT CAN RESULT IN SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! It is the installer’s responsibility to make sure the structure to which this mount is attached can support five times the combined weight of the mount and all equipment attached to it.
-
Page 7: Display Installation
Installation Instructions DISPLAY INSTALLATION Determine mounting pattern on display. WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY AND DAMAGE TO EQUIPMENT! DO NOT substitute hardware. Use only hardware supplied by manufacturer! WARNING: IMPROPER INSTALLATION CAN LEAD TO ELECTRIC SHOCK OR DAMAGE TO EQUIPMENT! Screw length must not exceed the depth of threaded mounting insert in display. -
Page 8: Cable Management
J-Series Figure 6 Tighten all hardware. CABLE MANAGEMENT Attach all cables to display. CAUTION: Ensure that adequate cable slack exists for movement of display, and that cables will not be pinched by installation of cable management cover(s) (E) or screws (G). Carefully insert cables in cavity located in lower portion of mount arm (See Figure 7). - Page 9 Installation Instructions J-Series...
- Page 10 J-Series Chief Manufacturing, a division of Milestone AV Technologies 8832-000253 2008 Milestone AV Technologies www.chiefmfg.com 06/08 USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 P 800.582.6480 / 952.894.6280 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands...
