I N S T A L L A T I O N I N S T R U C T I O N S
Instrucciones de instalación
Installationsanleitung
Instruções de Instalação
Small Shelf for Fusion™ Cart/Stand
Istruzioni di installazione
Installatie-instructies
Instructions d´installation
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
FCA611
Advertisement
Table of Contents
Related Manuals for CHIEF FCA611
Summary of Contents for CHIEF FCA611
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Small Shelf for Fusion™ Cart/Stand Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCA611...
-
Page 2: Installation Instructions
WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components located on the FCA611 does not exceed 25 lbs (11.34 kg). - Page 3 Installation Instructions FCA611 DIMENSIONS 14.14 359.3 17.24 437.9 15.21 386.4 24.36 618.7 6.00 152.4 2.24 56.9...
- Page 4 FCA611 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
Installation Instructions FCA611 TOOLS REQUIRED FOR INSTALLATION 5/32" (included) 1/8" (included) PARTS B (2) [accessory bracket] A (1) [small shelf] C (1) D (1) E (1) [center support bracket] [left shelf support] [right shelf support] G (4) F (4) #10-24 x 3/8"... -
Page 6: Assembly And Installation
The following procedure assumes the Fusion™ Cart/ Stand has already been completely assembled with the display attached. IMPORTANT ! : The FCA611 shelf has been designed specifically for Chief’s Fusion™ Series Carts and Stands. DO NOT attempt to install this shelf onto any other cart or stand! Remove back cover from cart/stand. - Page 7 Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components located on the FCA611 does not exceed 25 lbs (11.34 kg). Figure 6...
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
