- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S FCA503 FCA502 FCA501 Upper Accessory Shelf Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FCA501 / 502 / 503...
- Page 2 WARNING: Use this mounting system only for its intended Chief® is a registered trademark of Milestone AV Technologies. use as described in these instructions. Do not use All rights reserved. attachments not recommended by the manufacturer.
- Page 3 Installation Instructions FCA501 / 502 / 503 DIMENSIONS - continued FCA502 18.8 476.8 MAXIMUM EXTENSION OF MOUNT FCA503 OF MOUNT...
- Page 4 FCA501 / 502 / 503 Installation Instructions LEGEND Tighten Fastener Phillips Screwdriver Apretar elemento de fijación Destornillador Phillips Befestigungsteil festziehen Kreuzschlitzschraubendreher Apertar fixador Chave de fendas Phillips Serrare il fissaggio Cacciavite a stella Bevestiging vastdraaien Kruiskopschroevendraaier Serrez les fixations Tournevis à pointe cruciforme...
- Page 5 Installation Instructions FCA501 / 502 / 503 ASSEMBLY AND INSTALLATION Attach retaining bracket (B) to upright, pressing retaining bracket against mount extrusion and tightening, using four 10-24 lock nuts (D). (See Figure 3) Assembling Shelf to Upright Attach shelf (A) to upright (C) using three 1/4-20 x 1/2"...
- Page 6 Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components located on the FCA501/FCA502/FCA503 does not exceed 10 lbs (4.5 kg). NOTE: OPTIONAL: Slots are provided in shelf for strap (not included) to hold component in place.
- Page 7 Installation Instructions FCA501 / 502 / 503...
- Page 8 FCA501 / 502 / 503 Installation Instructions USA/International A 6436 City West Parkway, Eden Prairie, MN 55344 P 800.582.6480 / 952.225.6000 F 877.894.6918 / 952.894.6918 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845...
