- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation TA100 TA250 TA200 Video Conferencing and Component Shelves Spanish Product Description German Product Description Portuguese Product Description...
-
Page 2: Installation Instructions
Chief® is a registered trademark of Milestone AV Technologies. Reinforce the structure as required before installing the All rights reserved. - Page 3 Installation Instructions TA100/200/250 DIMENSIONS (CONTINUED) TA200 203.2 8.00 101.6 4.00 SHELF CAN BE USED EITHER ABOVE OR BELOW 31.8 1.25 184.2 101.6 7.25 4.00 21.85 DISTANCE TO C/L OF THE TS3XXX SERIES 114.3 21.85 562.9 4.50 DISTANCE TO C/L OF 22.16...
- Page 4 TA100/200/250 Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/8" 5/32" (included) 1/8" (included) PARTS C (1) [TA200 8" video conferencing shelf] [TA100 component shelf] B (1) [extension bracket] A (1) [attachment bracket] [TA250 12" video conferencing shelf] D (1) E (4) F (6) [backing bracket] #10-24 x 3/8"... - Page 6 TA100/200/250 Installation Instructions Installation (TA200 shown) Shelf Assembly (F) x 3 Use three 1/4-20 x 5/8" button head cap screws (F) and three 1/4" washers (G) to connect shelf (C) to either extension bracket (B) or attachment bracket (A). (See...
- Page 7 Installation Instructions TA100/200/250 Reinstall display to faceplate. See swing arm installation instructions for details. (lower installation) NOTE: If also installing side speaker brackets (TA300), (display not shown for clarity) attachment bracket (A) should also be attached to TA300 horizontal brackets for additional support. Use hardware provided with TA300.
- Page 8 (A). (See Figure 9) installer’s responsibility to make sure the combined weight of all equipment and accessories mounted on the TA100/200/ Adjust height of shelf (C) as desired. 250 shelves does not exceed 10 lbs (4.54 kg) per shelf.
- Page 9 Installation Instructions TA100/200/250...
- Page 10 TA100/200/250 Installation Instructions...
- Page 11 Installation Instructions TA100/200/250...
- Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
